- Page 1 LDC031 Series Trolley All-in-One Direct View LED Display Installation Guide 快速入門指南 Guide de démarrage rapide Schnellstartanleitung Guía rápida de inicio Model No. LDC031-120/LDC031-150/LDC031-180/LDC031-250...
- Page 2 Blank...
-
Page 3: Fcc Compliance Statement
European Technical Adaptation Committee (TAC). For EU users, please contact us for any safety/accident issue experienced with this product: ViewSonic Europe Limited Haaksbergweg 75 1101 BR Amsterdam Netherlands +31 (0) 650608655 EPREL@viewsoniceurope.com... - Page 4 Introduction The step-by-step instructions in this guide are a general reference for installing the LED Display. If any details in this document are unclear, please contact your reseller for more information. Before Building DO NOT move the trolley over cords or uneven, dirty, soft, or high incline surfaces. To avoid injury, KEEP AWAY from moving parts.
- Page 5 Building the Trolley 1. Install the Top and Bottom Cross Beams to the Left and Right Supports. Secure them together with the provided screws (M8 x 20 mm). Top Cross Beam Right Support Bottom Cross Beam Left Support Building the Trolley (Rear View) 2.
-
Page 6: Installing The Cabinets
Installing the Cabinets Before installing the Cabinets onto the trolley, please ensure all parts are accurately and securely held together. 1. Place each section of the Cabinet on stable furniture that can safely support them. Start with the Cabinets from the center, then move to the right and left sides of the Wall Mount Brackets (see Appendix B to identify Cabinet sections and installation sequence). - Page 7 8. Adjust the left Cabinet Bracket until it is aligned with the hole provided in the Cabinet. 9. Secure the left Cabinet Bracket to the Cabinet with the provided screw (M8 x 20 mm). 10. Install the right Cabinet Bracket in the same manner as the left Cabinet Bracket. NOTE: ...
- Page 8 Connecting and Installing the System Control Box The left and right sides of the System Control Box are pre-installed with its Covers in the factory. The main system control board is on the right. The safety wires are used to prevent the Right Cover from falling when accessing the System Control Box.
- Page 9 Remove the Left Cover by gripping the top edge of the Cover and pulling it toward you. The Left Cover should simply lift away. 4. Secure the System Control Box panel with the Connector Plate using the provided screws (M3 x 6 mm). Further secure the Connector Plate with the two provided screws (M3 x 6 mm).
- Page 10 6. Install the System Control Box to the bottom of the Cabinets with the provided screws (M8 x 20 mm). See Appendix B for the mounting points. Connect the Power and Network Cables from the System Control Box to each Cabinet.
- Page 11 Installing the LED Modules Please wear Anti-Static Gloves before handling the LED Modules. To avoid direct contact with the LED Modules, please remove watches, rings, bracelets, or other metal objects. Use caution when installing the LED Modules. 1. Starting from the LED Module labeled "1" in the top left corner, align each LED Module with the Cabinet, then carefully press the Module into place.
- Page 12 Power Indicator Light will be a steady red. This means the LED Display is in standby mode. Please refer to the User Guide for more details. Your LED Display is now ready to power on. LDC031 Series_Trolley_QSG_ENG_1a_20240527 Copyright © 2024 ViewSonic Corporation. All rights reserved.
