LD-SCB-023
LDC031 Series
All-in-One Direct View LED Display
Separate Installation
Installation Guide
快速入門指南
Guide de démarrage rapide
Schnellstartanleitung
Guía rápida de inicio
Model No. VS20448
P/N: LD-SCB-023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LDC031 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ViewSonic LDC031 Series

  • Page 1 LD-SCB-023 LDC031 Series All-in-One Direct View LED Display Separate Installation Installation Guide 快速入門指南 Guide de démarrage rapide Schnellstartanleitung Guía rápida de inicio Model No. VS20448 P/N: LD-SCB-023...
  • Page 2 Blank...
  • Page 3: Fcc Compliance Statement

    European Technical Adaptation Committee (TAC). For EU users, please contact us for any safety/accident issue experienced with this product: ViewSonic Europe Limited Haaksbergweg 75 1101 BR Amsterdam Netherlands +31 (0) 650608655 EPREL@viewsoniceurope.com...
  • Page 4: Before Installing

    Introduction The step-by-step instructions in this guide are a general reference for installing the LED Display. If any details in this document are unclear, please contact your reseller for more information. Before Installing Ensure there is no direct airflow from air conditioning or heating vents blowing on the LED Display.
  • Page 5: Installing The Cabinets

    4. After mounting the first and second Upper Wall Mount Brackets to the wall, secure them with the Wall Mount Connector Plate using the six provided screws (PM6 x 10 mm). 5. Repeat Step 2~4 for the remaining Upper Wall Mount Bracket(s). 6.
  • Page 6 3. Carefully lift the assembled Cabinet onto the center of the Upper Wall Mount Brackets. NOTE:  The illustration below is provided for reference only and may differ from the actual product appearance. 4. Ensure the Mounting Brackets sit securely on the Wall Mount Brackets as shown below.
  • Page 7 7. Check for unevenness of the Cabinets by rubbing the cross section between each Cabinet. If the cross section is not aligned, loosen the M8 screws slightly and tap the Cabinets until the cross section is flat. 8. Repeat Step 1~7 for the remaining Cabinets, ensuring that the Mounting Brackets sit securely on the Wall Mount Brackets, and that the Cabinets are properly secured together.
  • Page 8: Control Box

    Connecting and Installing the System Control Box The LD-SCB-023 control box comprises a Control Box and Power Module. Control Box Front View USB Type A Power Button & Indicator Light Rear View 1. RJ45 2. HDMI 2.0 Out 3. DisplayPort 1.2 Out 4.
  • Page 9: Power Module

    Power Module Front View Rear View 1. LAN Control 2. USB Type A (Service 3. RS232 (To Control 4. Power Sockets only) Box) 5. Power Socket (For 6. AC In Control Box) 1 - The System Control Box Power Cables are already pre-connected to the Power Module.
  • Page 10 IMPORTANT:  Make sure the directions below are followed before installing the System Control Box. • The power at the upstream circuit breaker is turned off. • The Control Box and Power Module are fully inserted into the rack, and the rack is securely situated. •...
  • Page 11 Strip insulation carefully from the wires of the System Control Box Power Cable(s), route it to the distribution box, and connect each wire (neutral, live, and ground) to its correct terminal. The meaning of wiring color may vary by country. Always follow your local or national wiring rules.
  • Page 12 Installing the Screen Bezels The Screen Bezels' plastic tabs are pre-installed onto the Bezels. Ensure all plastic tabs are properly mounted before installing the Screen Bezels onto the screen. Plastic tabs 1. Place the Screen Bezel to the correct side of the screen to attach. Start from the left and move to the right (See Appendix C for the location where each Screen Bezel should be installed).
  • Page 13 To power the System Control Box, turn on the upstream circuit breaker and Power Switch of the Control Box. Your LED Display is now ready to power on. For details, please refer to the User Guide. LD-SCB-023_LDC031 Series_IG_ENG_1a_20250117 Copyright © 2025 ViewSonic Corporation. All rights reserved.
