- Page 1 LDC031 Series Standard Installation All-in-One Direct View LED Display Installation Guide 快速入門指南 Guide de démarrage rapide Schnellstartanleitung Guía rápida de inicio Model No. LDC031-120/LDC031-150/LDC031-180/LDC031-250...
- Page 2 Blank...
-
Page 3: Fcc Compliance Statement
European Technical Adaptation Committee (TAC). For EU users, please contact us for any safety/accident issue experienced with this product: ViewSonic Europe Limited Haaksbergweg 75 1101 BR Amsterdam Netherlands +31 (0) 650608655 EPREL@viewsoniceurope.com... -
Page 4: Before Installing
Introduction The step-by-step instructions in this guide are a general reference for installing the LED Display. If any details in this document are unclear, please contact your reseller for more information. Before Installing Ensure there is no direct airflow from air conditioning or heating vents blowing on the LED Display. -
Page 5: Installing The Cabinets
4. After mounting the first and second Upper Wall Mount Brackets to the wall, secure them with the Wall Mount Connector Plate using the six provided screws (PM6 x 10 mm). 5. Repeat Step 2~4 for the remaining Upper Wall Mount Bracket(s). 6. - Page 6 3. Carefully lift the assembled Cabinet onto the center of the Upper Wall Mount Brackets. 4. Ensure the Mounting Brackets sit securely on the Wall Mount Brackets as shown below. Mounting Brackets Display Display Wall Mount Brackets 5. Repeat Step 1~2 for the second Cabinet. 6.
- Page 7 7. Check for unevenness of the Cabinets by rubbing the cross section between each Cabinet. If the cross section is not aligned, loosen the M8 screws slightly and tap the Cabinets until the cross section is flat. 8. Repeat Step 1~7 for the remaining Cabinets, ensuring that the Mounting Brackets sit securely on the Wall Mount Brackets, and that the Cabinets are properly secured together.
- Page 8 To open the Right Cover, slowly bring the supplied Maintenance Tool near the surface of the Right Cover where the steel plate is located. Then, the Right Cover should detach from the System Control Box magnetically. DO NOT try to remove or disconnect the safety wires. Please ensure that the safety wires are never removed.
- Page 9 4. Secure the System Control Box panel with the Connector Plate using the provided screws (M3 x 6 mm). Further secure the Connector Plate with the two provided screws (M3 x 5 mm).
- Page 10 6. Install the System Control Box to the bottom of the Cabinets with the provided screws (M8 x 20 mm). Connect the Power and Network Cables of the Cabinets from the System Control Box to each Cabinet. Start from the bottom and move to the top (see Appendix B for example system wiring diagrams, including wire colors and connection points).
- Page 11 11. After connecting all Cables and wires, hold the top edge of the Right Cover toward the System Control Box to replace it. Once the Right Cover is replaced, it will be held in place magnetically. NOTE: Ensure the Power Button cable is connected before securing the Right Cover.
- Page 12 2. Attach the remaining LED Modules onto the Cabinets. Install from top left and move to bottom right, ensuring to match the corresponding numbers on the Module to the Cabinet. See Appendix C for further guidance on the LED Modules. NOTE: ...
- Page 13 Power Indicator Light will be a steady red. This means the LED Display is in standby mode. Please refer to the User Guide for more details. 2. Your LED Display is now ready to power on. LDC031 Series_Standard Installation_QSG_ENG_1a_20240509 Copyright © 2024 ViewSonic Corporation. All rights reserved.
