Summary of Contents for ViewSonic LDS138-151
- Page 1 LDS138-151 All-in-One Direct View LED Display Solution Kit Quick Start Guide 快速入門指南 Guide de démarrage rapide Schnellstartanleitung Guía rápida de inicio...
-
Page 2: Fcc Compliance Statement
EU of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS2 Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC). ViewSonic Europe Limited Haaksbergweg 75 1101 BR Amsterdam Netherlands +31 (0) 650608655 EPREL@viewsoniceurope.com... -
Page 3: Package Contents
USB 3.0 USB 2.0 LED Display with Motorized Trolley Cart USB 3.0 USB 2.0 LDS138-151 All-in-One Direct View LED Display Quick Start Guide Guide de démarrage rapide Schnellstartanleitung Schnellstartanleitung Quick Start Guía rápida de inicio Hızlı Başlangıç Kılavuzu Aan de slag а... - Page 4 • This product is packed in a flight case. • Due to the size and weight, it is recommended that two or more people handle it. LDS138-151 All-in-One Direct View LED Display Quick Start Guide Guide de démarrage rapide Schnellstartanleitung Schnellstartanleitung Guía rápida de inicio...
- Page 5 Physical Dimensions for the Display 3064 2598 PRESS Physical Dimensions for the Flight Case 2070 1996...
-
Page 6: Product Overview
Product Overview Front View I/O Control Panel & Power Button Rear View Control Panel for HDMI & Audio Out Motorized Trolley Cart Power Switch & Power Socket... - Page 7 Control Panel for Motorized Trolley Cart • Use the "Up" (▲) key to lift the display. The lift will automatically stop upon reaching the height limit. Please note, the “Up” key is a “click to act” key, i.e., upon releasing the key the lift will not immediately stop. Instead, it will slow down for a short distance then stop.
- Page 8 Power Switch is in the “on“ position. If the normal operation of your LED Display does not resume or the Display temperature remains low after you followed the instructions, contact ViewSonic® for technical support.
- Page 9 Schematic Diagram of Components Back Cover of the Flight Case Front Cover of the Flight Case Movable Plate LED Display with Bottom Plate Motorized Trolley Cart of the Flight Case I. Handling and Moving Flight Cases IMPORTANT If your LED Display has been stored in a low temperature (below 0° C [32° F]) location, please visit our website to download the latest version of the User Guide for detailed directions to properly warm up the Display.
- Page 10 II. Unpacking Operation PRESS PRESS PRESS PRESS PRESS PRESS PRESS PRESS...
- Page 11 III. Packing and Handling Operation PRESS PRESS PRESS PRESS PRESS PRESS PRESS PRESS PRESS...
-
Page 12: Specifications
Specifications Item Category Specifications Model LDS138-151 Type Direct View LED Display Size 138” 3,050 mm x 1,715 mm Active Size (H x V) 120.08” x 67.52” Pitch Size 1.58 mm LED Screen Resolution FHD, 1920 x 1080 Refresh Frequency 3840 Hz... - Page 13 Item Category Specifications ≤ 5,000 m Altitude ≤ 16,404 ft Operating Relative 10%~80% non-condensing Conditions Humidity 0° C to 40° C Temperature 32° F to 104° F ≤ 5,000 m Altitude ≤ 16,404 ft Storage Relative 10%~85% non-condensing Conditions Humidity -10°...
