- Page 1 LDC027 Series Hidden Installation All-in-One Direct View LED Display Installation Guide 快速入門指南 Guide de démarrage rapide Schnellstartanleitung Guía rápida de inicio Model No. LDC027-120/LDC027-150/LDC027-180/LDC027-250...
- Page 2 Blank...
-
Page 3: Fcc Compliance Statement
European Technical Adaptation Committee (TAC). For EU users, please contact us for any safety/accident issue experienced with this product: ViewSonic Europe Limited Haaksbergweg 75 1101 BR Amsterdam Netherlands +31 (0) 650608655 EPREL@viewsoniceurope.com... -
Page 4: Before Installing
Introduction The step-by-step instructions in this guide are a general reference for installing the LED Display. If any details in this document are unclear, please contact your reseller for more information. Before Installing Ensure there is no direct airflow from air conditioning or heating vents blowing on the LED Display. -
Page 5: Installing The Cabinets
4. Repeat Step 2~3 for the remaining Upper Wall Mount Bracket(s). 5. Install the Lower Wall Mount Brackets in the same manner as the Upper Wall Mount Brackets. NOTE: You can also install the Upper Wall Mount Brackets, hang the screen, and then install the Lower Wall Mount Brackets for a more precise fit. - Page 6 8. Ensure the Mounting Brackets sit securely on the Wall Mount Brackets as shown below. Mounting Brackets Display Display Wall Mount Brackets 9. Repeat Step 2~3 for the second Cabinet, ensuring it sit securely on the Wall Mount Brackets. 10. Install the first and second Cabinets together with the provided screws (M8 x 20 mm).
- Page 7 Connecting and Installing the System Control Box The left and right sides of the System Control Box are pre-installed with its Covers in the factory. The main system control board is on the right. The safety wires are used to prevent the Right Cover from falling when accessing the System Control Box.
- Page 8 3. To open the Right Cover, slowly bring the supplied Maintenance Tool near the surface of the Right Cover where the steel plate is located. Then, the Right Cover should detach from the System Control Box magnetically. DO NOT try to remove or disconnect the safety wires. Please ensure that the safety wires are never removed.
- Page 9 4. Remove the Left Cover by gripping the top edge of the Cover and pulling it toward you. The Left Cover should simply lift away. 5. Secure the System Control Box panel with the Connector Plate using the provided screws (M3 x 6 mm). 6.
- Page 10 7. Install the short side of the Lower System Control Box Mount Bracket onto the top of the System Control Box with the provided screws (M3 x 6 mm). NOTE: • There are two Lower System Control Box Mount Brackets to install. •...
- Page 11 8. Install the provided screw (M8 x 16 mm) on the Lower System Control Box Mount Bracket. Thread the provided M8 nut onto the screw and fully tighten the nut. 9. Repeat Step 7 for the other Lower System Control Box Mount Bracket. 10.
- Page 12 14. Thread the Power Cables of the Cabinets through the hole provided in the System Control Box to the rear (see Appendix C for the position of the cable holes). Avoid sharp bends in the Cables. NOTE: • The rubber hole plugs must always be placed in the holes. •...
- Page 13 21. Thread the Power and Network Cables through the holes at the lowest row of the Cabinets to the front. NOTE: Ensure to match the corresponding letters on the Cables to the Cabinets (A to A, B to B, C to C, and so on). 22.
- Page 14 Installing the LED Modules Please wear Anti-Static Gloves before handling the LED Modules. To avoid direct contact with the LED Modules, please remove watches, rings, bracelets, or other metal objects. Use caution when installing the LED Modules. 1. Starting from the LED Module labeled "1", align each LED Module with the Cabinet, then carefully press the Module into place.
- Page 15 Installing the Screen Bezels The Screen Bezels' plastic tabs are pre-installed onto the Bezels. Ensure all plastic tabs are properly mounted before installing the Screen Bezels onto the screen. The label indicates the top of each Screen Bezel. To ensure the Bezels are installed in the correct position, please use the labels on the inside of the Bezels as a guide.
- Page 16 Power Indicator Light will be a steady red. This means the LED Display is in standby mode. Please refer to the User Guide for more details. 2. Your LED Display is now ready to power on. LDC027 Series_Hidden Installation_IG_ENG_1a_20240716 Copyright © 2024 ViewSonic Corporation. All rights reserved.
