MODEL : 3859-20 /22/29 and 3859NAT-20/22/29 COVE OCCASIONAL TABLE
Please read instructions carefully
Remove all wrapping materials, staples and packing straps from the carton. Refer to Parts List and Hardware List and ensure they are complete
before you start assembling. Place all wooden parts on a clean, flat and soft surface (e.g carpet or rug) to prevent parts from being scratched.
CAUTIONS: 1) DO NOT FULLY TIGHTEN BOLTS AND NUTS UNTIL ALL PARTS HAVE BEEN ASSEMBLED.
2) DO NOT OVER-TIGHTEN BOLTS AND NUTS .
3) KEEP ALL HARDWARE PARTS OUT OF REACH OF CHILDREN.
Carton
3859-20/22/29T and
3859NAT-20/22/29T
3859-20/22/29B and
3859NAT-20/22/29B
ASSEMBLY INSTRUCTIONS
Packed in 2 cartons
Designation
Table Top
Mounting Panel
Pedestal Leg
Part List
P1 x 1pc
P3 x 1pc
3859NAT-20/22/29B
P2 x 1pc
Hardware List
3859NAT-20/22/29T
M6x35 JCBC SCREW
Spring Washer
Flat Washer
Legs Adjustable Glide
Wood Dowel M8x30mm
Allen Key
COMPLETE ASSEMBLY
H1 x 8pc
H2 x 8pc
H3 x 4pc
H4 x 8pc
H5 x 4pc
H6 x 1pc
Page 1 of 2
