WHOLE-HOME CLEANING
TOUCHSCREEN SELECTOR
To select the cleaning mode, tap one of the
icons on the touchscreen on the handle:
Detect Mode: Select Detect mode
to activate Smart Detect technology.
In this mode, the vacuum will
automatically detect hidden dirt,
different types of floor surfaces,
and edges and corners, and will
adjust suction to maximize cleaning
performance.
Manual Surface Modes: Tap one of the
surface modes to clean specific surfaces
without Smart Detect Technology.
Hard Floor: Suction and brushroll
speed optimized for cleaning hard floor
surfaces and above-floor areas.
Carpet/Low Pile: Suction and brushroll
speed optimized for deep cleaning low-
pile carpets.
Thick Carpet/Area Rug: Suction and
brushroll speed optimized for cleaning
thick carpets and area rugs.
SMART DETECT TECHNOLOGY
FloorDetect™: Senses different surface types
and automatically adjusts brushroll speed
and suction power for optimized cleaning on
each surface.
DirtDetect: Senses hidden debris you can't
see and automatically boosts suction power.
The LED indicator light will turn purple,
and suction will increase for more cleaning
power. Continue cleaning until the light turns
white, indicating the surface is clean.
EdgeDetect: Focuses and maximizes suction
along corners and edges to target stubborn
dirt. When an edge is detected, the arrow
indicator on the top of the nozzle will turn on.
s h a r kc l e a n . c o m
SETTINGS
POWER BUTTON
Press power button to turn on vacuum.
Please note the brushrolls will not spin
unless the wand is reclined.
WHOLE-HOME CLEANING
DETECT INDICATORS
DIRTDETECT INDICATOR
DIRTDETECT INDICATOR
White: Cleaning.
Purple: Cleaning Boost. Surface is dirty,
suction will increase to pull in hidden debris.
Red: Sensors require cleaning. Reference
maintenance section.
NOTE: Detect Indicators will be off in manual
surface modes.
HEADLIGHT INDICATOR LIGHTS
HEADLIGHTS
The headlights will flash or turn red to
indicate issues that need attention.
Solid White Lights: The brushrolls are spinning and the unit is working as intended.
Solid Red Lights: There is a jam in the brushroll area. Turn off the vacuum and unplug it,
then remove any blockages in the nozzle.
Flashing Red Lights: The motorized floor nozzle is overheating. Turn off the vacuum,
unplug it, and remove any blockages. Let the vacuum cool down for at least 60 minutes
before restarting.
Flashing White Lights: The vacuum is operating in an environment that is either
too hot or too cold.
NOTE: For deep cleaning per ASTMF608 (embedded dirt in carpets), please set to Carpet/Low Pile mode.
NOTE: For maximum suction for above-floor cleaning per ASTM F558, set to Hard Floor mode.
EDGEDETECT INDICATORS
EDGEDETECT INDICATORS
When an edge is detected, the arrow
indicator closest to edge will turn on, and the
headlights closest to the edge will brighten
to illuminate hidden debris.
Blinking White Arrows: When the EdgeDetect
sensors are obstructed, the arrow indicator
lights will blink. Move the unit away from
the edge, turn off power, and restart. If the
arrows continue to blink, clean the sensors.
s h a r kc l e a n . c o m
