ODOR NEUTRALIZER TECHNOLOGY SETTINGS
ODOR DIAL
Flip up the dial handle and rotate the odor dial
to adjust Odor Neutralizer Technology intensity
or to unlock the dial for cartridge access.
Insertion/Removal: Rotate the odor dial to align the teal arrows. Remove the dial to access
the odor cartridge for removal or replacement.
Low: Rotate the dial toward the Low position to decrease the intensity to the lowest level
when the vacuum is in use.
High: Rotate the dial toward the High position for the highest intensity level when the
vacuum is in use. This position is the recommended setting for optimal performance.
ODOR NEUTRALIZER TECHNOLOGY TIPS
Odor Dial Must be Installed for Vacuum to Function Properly
• Remove odor cartridge from dial if you don't want the benefits of Odor Neutralizer Technology.
Maintenance Required
• Clean all filters as recommended under Cleaning Filters.
• Empty the dust cup before storing your vacuum.
• Replace the cartridge as recommended under odor cartridge replacement.
• Visit qr.sharkclean.com/odortech to learn more and purchase replacements.
• If wet pet messes are cleaned up, thoroughly clean the vacuum.
Fragrance Strength Over Time
• The intensity of the Odor Neutralizer Technology's fragrance may diminish over time. It may
also have no noticeable fragrance at all. This is natural and does not indicate the technology
isn't working. Follow replacement instructions to ensure continued performance.
NOTES: • The odor dial needs to be installed for the vacuum to function properly, with or without the odor cartridge.
• Odor Neutralizer Technology effectively deodorizes while interacting with odors from inanimate sources.
s h a r kc l e a n . c o m
ODOR NEUTRALIZER TECHNOLOGY
ODOR CARTRIDGE REPLACEMENT
1. REMOVE ODOR DIAL
FROM NOZZLE
Flip up the handle and rotate the dial clockwise
until the two teal arrows are aligned. Pull the
handle to remove the dial from the nozzle.
3.REMOVE NEW CARTRIDGE
FROM BAG
Remove the new odor cartridge from the
sealed packaging. To maintain the life of
the cartridge, keep it in the sealed
packaging until you are ready to install it.
5. INSTALL DIAL IN NOZZLE
Align the teal arrow on the dial cover with
the teal arrow on the nozzle, then reinsert
the dial into the nozzle. Rotate the dial
counterclockwise until it clicks into an
intensity setting to engage. Rotate further to
change the intensity setting.
2. REMOVE OLD ODOR
CARTRIDGE
Rotate the cartridge counterclockwise in the dial
housing and pull out the cartridge to remove it.
TURN UNTIL
CLICK TO LOCK
4. INSTALL NEW CARTRIDGE
IN DIAL
Align the yellow arrow on the side of the cartridge
with the yellow arrow on the side of the dial
cover, then insert the cartridge into the dial.
Rotate the cartridge clockwise to lock it in place.
6. USED CARTRIDGE
DISPOSAL
Dispose of the old cartridge by dropping it
into the trash.
NOTE: Odor cartridges should be replaced every
6 months for optimal Odor Neutralizer Technology
performance.
s h a r kc l e a n . c o m
