SELF-EMPTY BASE SETUP
1 ft.
1 ft.
2 ft.
• Find a permanent Location for the base in a central area. Ensure the base is not placed in area with
direct sunlight.
• Ensure the chosen location has a strong Wi-Fi signal.
• Remove any objects that are closer than 0.3m from either side of the base, or close than 0.6m
from the front.
• Plug in the base.
INSTALLING THE SIDE BRUSH
s h a r kc l e a n . c o m
Attach the side brush to the post on the
bottom of the robot.
Side brush design may vary.
NOTE:
ROBOT INDICATOR LIGHTS
When cleaning, the remaining battery level is
indicated by the number of LED lights illuminated.
At full battery power, 5 indicator lights will be
illuminated. At 80% battery, 4 indicator lights will
be illuminated, and so on.
Detects hidden debris and automatically boosts power until no more dirt is detected. When the robot detects
a mess, the lights on the robot will turn purple to indicate that DirtDetect is enabled.
The robot will deep-clean in a 3' x 3' pattern.
ACTIVE LIFT AND LOWER
The robot lifts itself over bumps, rugs, and low thresholds (less than 1") with ease.
The orange lights will illuminate when the robot moves over obstacles
SIDE BRUSH NOT SPINNING ON CARPET
The side brush will not spin on a carpeted area to prevent entanglement with carpet threads.
SELF-EMPTY BASE INDICATOR LIGHTS
• Base ON and Robot Charging – Solid Blue
• Base ON but Robot Not Charging – Solid Green
• Robot Evacuating into Self-Empty Base – Pulsing Green
Low Battery
LEFT NOTIFICATION BATTERY WI-FI RIGHT
LEFT LED pulsing RED
Charging
LEFT NOTIFICATION BATTERY WI-FI RIGHT
BATTERY LED pulsing RED for low, YELLOW for medium,
GREEN for high
If your robot is low on battery power, the left LED
light will pulse RED. Manually place the robot on the
base to begin charging. When the robot is charging,
the battery indicator light will pulse, based on the
current battery charge level: RED for low, YELLOW
for medium, GREEN for high.
DIRTDETECT
