Console (1/Unit) - Siemens SIMATIC NET RUGGEDCOM RS969 Equipment Manual

Accessories
6.2 Console (1/unit)
6.2

Console (1/unit)

M12 Console Port Mating Cable
Figure 6.3
M12 Console Port Mating Connector
Figure 6.4
34
M12 Console Port Mating
Cable
M12 Console Port Mating
Connector
Description
•
M12 8pin A-code male to DB9
female; unshielded, PUR jacket
cable, 30V/4A, 3m
• Order Code
99-43-0023-001
• Cable Specifications
M12 8pin A-code male to free end,
3m
Description
•
M12-straight plug, 8 pole, A-coded,
IP67 rated
• Order Code
99-60-0002
Equipment Manual, 10/2023, C79000-G8976-1038-05
RUGGEDCOM RS969
