Pulsar ARAS600N Quick Start Manual

Arad rails dedicated for rack19" cabinets

Advertisement

Quick Links

RACK 19" enclosures - accessories
CODE:
ARAS600N
ARAD rails dedicated for RACK19" cabinets - 600mm depth
NAME:
DESTINATION
ARAS600N rail is intended for mounting RACK enclosures, type: ARAD2N / ARAD3N / ARAD4N in a 600mm
deep RACK 19" cabinet.
TECHNICAL DATA
Mounting dimensions
Material
Destination
Net/gross weight
Notes
Warranty
Tel. +48-14-610-19-45
www.pulsar.pl
e-mail:
sales@pulsar.pl
v.1.0/I
H=1U, D=330 ÷ 449mm
- sheet steel DC01, thickness: 1.0 mm, protection anticorrosion, colour: RAL9005 (black)
- rails – fully extendable
inside
1.47 / 1.58 [kg]
- four-point fixing to the front RACK rails + supported on front and rear RACK profiles
- 4 M6 screws + cage nuts included
- 2 M4 screws included – to bolt the RACK enclosure
2 years
www.pulsar.pl
EN

Advertisement

loading
Need help?

Need help?

Do you have a question about the ARAS600N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pulsar ARAS600N

  • Page 1 ARAD rails dedicated for RACK19" cabinets - 600mm depth NAME: DESTINATION ARAS600N rail is intended for mounting RACK enclosures, type: ARAD2N / ARAD3N / ARAD4N in a 600mm deep RACK 19” cabinet. TECHNICAL DATA Mounting dimensions H=1U, D=330 ÷ 449mm - sheet steel DC01, thickness: 1.0 mm, protection anticorrosion, colour: RAL9005 (black)
  • Page 2 RACK 19" enclosures - accessories www.pulsar.pl Installation Mount the M6 cage nuts to the RACK cabinet, as shown in the picture below. Then, mount the ARAS rails. Take notice of the correct positioning of the horizontal rails. Adjust their length between the front and back RACK profiles.
