Pulsar RACK 3U Assembly Instruction

1. Product description.

Vertical surface-mounted RACK 3U enclosure is universal solution for organizing and protecting against unauthorized
access or theft of devices in RACK 19" standard with total height of up to 3U. It has special system for hanging devices with
possibility of choosing 3 mounting heights and convenient way to remove devices from enclosure. There are also special
holders for mounting straps for devices without RACK mounting standard. Inside is double ~ 230 V power socket with power
connector equipped with glass fuse.
Enclosures construction is compliant with requirements of General Data Protection Regulation (GDPR), as personal
data must be protected and stored securely (possibility of installing two locks with different codes).
Possibility of install inside:
Switche PoE – adapter RAPDS / RACK brackets

 Recorder – back enclosure – straps – ZPR / RACK bracket
 Power supply units: PS-12V10A, PS-12V15A, PS-48V3A, PSB-12V10A, PSB-12V15A, PSB-24V5A, PSB-24V7A,
PSB-48V3A.
 Batteries
 Mounting space: 530x380x155 [mm +/-2] (WxHxD)
Main features:
 Surface mounted construction - compact and convenient solution
 Removable door (convenient installation of wiring and other equipment)
RACK brackets – 3U, ith adjustable mounting height on 3 levels

Knock-outs and holes in back of enclosure .

 Enclosure screwed with M4 screws or closed with key locks (option)

2. Technical parameters

External dimensions of enclosure
External dimensions of front panel
Mounting space
Position of RACK 19" profiles
Fitting battery
Net/Gross weight
Operation conditions
Material
Antisabotage protection
Destination
Components
Declarations, warranty
Notes
Name: RACK 3U vertical withe housing
W=535, H=540, D+D
W =541 H
1
W =530 H
2
H =380 or 324 or 268 [-/+2mm]
3
o
Temperature: -10 C ÷ +40
without condensation
DC01 sheet, thickness: 1mm, colour: RAL9003 (white)
- anticorrosion protection
1 x microswitch: enclosure opening 0,5 A; 50 V DC max.
NC – normally closed contacts
Optionally: 1 x microswitch: detachment form wall, 0,5A;
50 V DC (required PKAZ067)
CE, 2 years from production date
Optional: possibility of installing two locks (MR008 - different code),
distance from wall (mounting sourface) – 14mm
1
ASSEMBLY INSTRUCTION
ENGLISH
v1.2
Code: AWO532W
Supersedes edition: 2 from 14.03.2022
=163+14 [-/+2mm]
1
=545 [-/+2mm]
1
=380, D =155 [-/+2mm]
2 2
4x7 Ah; 2x17 Ah
8,16 / 9,14 [kg]
o
C relative humidity 20%...90%,
Inside
2x bracket RACK 3U
RACK brackets – 3U
IM532W
Edition: 3 from 23.06.2022
