Application

Figure 1 shows a typical application example for an ECM-EX2-1 gas cooler unit.
IN
 
OPTION

Figure 1 Application example of the ECM-EX2-1

1 : Filter sample probe SP ...
2 : Heated sample line
3 : ECM-EX2 cooler
4 : 3-way ball valve
4a : Test gas
5 : Peristaltic pump (optional)
The sample gas enters the gas sample probe
 
. The gas cooler cools the sample gas down to a dew point of +5 °C [41 °F]. The super-fine filter
solid particles from the sample gas. To enhance the operating safety of the entire system, we recommend installing

a super-fine filter with a liquid alarm sensor. If required, an aerosol filter

flow meter . The conditioned gas can now enter the analyzer
Warning
14

ECM-EX2-1
+5°C
[+41 °F]


a
6 : Membrane pump
7 : Super fine filter FP ...
8 : Aerosol filter CLF-5
9 : Flow meter FM10
10 : Analyzer

, and via a heated sample line
Do not use the gas cooler to extract gases or gas compositions, which could be
potentially explosive without the presence of air. Do not use gases or gas
compositions which can alter the relevant safety-related material properties of the
cooler materials. The gas or gas composition needs to be free of particles which
could cause, in combination with the materials of the gas cooler, sparks by friction or
impact.
Inhalation hazard possible, if using toxic or asphyxiant gases!
Purge gas cooler with inert gas or air before opening!
If the gas cooler is used for toxic gas or asphyxiant (oxygen-displacing) gas, it needs
to be purged with inert gas or air before opening. Follow closely all relevant
occupational safety regulations during operation.
ECM-EX2 | 1.03.01
  



can be installed in-line, in front of the

.


it reaches the ECM-EX2 gas cooler

www.mc-techgroup.com
removes
