Page 1
Electric Gas Cooler Series EC ® ECM-EX2 II 3 G Ex nA nC IIC T4 Gc Instruction Manual Doc: M_ECM-EX_EN_ Version1.03.01...
Page 2
Dear customer, Thank you for buying our product. In this instruction manual you will find all necessary information about this M&C product. The information in the instruction manual is fast and easy to find, so you can start using your M&C product right after you have read the manual.
Content General information ............................5 Declaration of conformity ..........................5 Safety instructions ............................6 Intended use ..........................................6 Warranty ................................7 Warning signs and definitions ........................7 Information and safety instructions for using the cooler in hazardous areas ........9 Information and safety instructions for using the cooler ...............10 Introduction ..............................11 Serial number ..........................................
Page 4
List of illustrations Figure 1 Application example of the ECM-EX2-1 ............................14 Figure 2 ECM-EX2-1 ........................................15 Figure 3 Diagram of the heat exchanger function ..........................16 Figure 4 Position of the gas and condensate connections ........................ 18 Figure 5 Electrical connections, alarm contacts ............................
Head Office M&C TechGroup Germany GmbH Rehhecke 79 40885 Ratingen Germany Telephone: 02102 / 935 - 0 Fax: 02102 / 935 - 111 E - mail: info@mc-techgroup.com www.mc-techgroup.com General information The product described in this manual has been built and tested in our production facility. All M&C products are packed to be shipped safely.
Safety instructions Please follow these safety directions and instructions regarding installation, commissioning and operation of the equipment: • Read this manual before commissioning and operating the product. Please make sure to follow all safety instructions. • Attention must be paid to the Type Examination Certificate in the appendix: BVS 16 ATEX E 055 X. •...
Warranty In case of a device failure, please contact immediately M&C or your M&C authorized distributor. We have a warranty period of 12 months from the delivery date. The warranty covers only appropriately used products and does not cover the consumable parts. Please find the complete warranty conditions in our terms and conditions.
Page 8
Toxic! Acute toxicity (oral, dermal, inhalation)! Toxic when in contact with skin, swallowed or inhaled. Corrosive! These substances destroy living tissue and equipment upon contact. Do not breathe vapors; avoid contact with skin and eyes. Hot surface! Contact may cause burn! Do not touch! Caution, risk of being crushed due to rotating parts.
Information and safety instructions for using the cooler in hazardous areas The compressor cooler ECM-EX2 is suitable for using in hazardous area of zone 2 (see Type Examination Certificate). The explosion proof protection for both models is: 230 V / 115 V: II 3G Ex nA nC IIC T4 Gc (Type Examination Certificate Number: BVS 16 ATEX E 055 X) Certification was carried out by DEKRA EXAM BBG Prüf- und Zertifizier GmbH.
Information and safety instructions for using the cooler Inhalation hazard possible, if using toxic or asphyxiant gases! Warning Purge cooler with inert gas or air before opening! If the cooler is used for toxic gas or asphyxiant (oxygen-displacing) gas, it needs to be purged with inert gas or air before opening.
Introduction The M&C ECM-EX2 gas cooler unit is designed to operate whenever there is moisture interference in the sample gas. Lowering the sample gas temperature to a very low and stable dew point prevents condensate built-up in the analyzer and avoids unstable measurements, because of water vapour cross-sensitivity or volumetric errors. The ECM-EX2 is certified for appropriate use in the specified Ex zones noted in the Type Examination Certificate.
Technical Data For basic cooler ECM-EX2 without heat exchanger Version ECM-EX2-1 Version ECM-EX2-2 Gas cooler series EC Part No. for 230 V 50 Hz 02K7650X 02K7655X Part No. for 115 V 60 Hz 02K7650XA 02K7655XA Amount of possible heat 1 x HE 2 x HE exchangers (HE)
Options for basic cooler ECM-EX2 Standard sizes are highlighted in the table. Heat exchanger type ECM-1G ECM-1PV ECM-1SS ECM-2G ECM-2PV ECM-2SS Part No 93K0140 93K0170 93K0160 97K0100 97K0110 97K0115 Material of heat Borosilicate PVDF stainless Borosilicate PVDF stainless exchanger glass steel 316Ti glass steel 316Ti...
Application Figure 1 shows a typical application example for an ECM-EX2-1 gas cooler unit. ECM-EX2-1 +5°C [+41 °F] OPTION Figure 1 Application example of the ECM-EX2-1 1 : Filter sample probe SP ... 6 : Membrane pump 2 : Heated sample line 7 : Super fine filter FP ...
Description Figure 2 shows the ECM-EX2-2 cooler unit Figure 2 ECM-EX2-2 The cooler ECM-EX2 is also suitable for wall mounting. The depth of the cooler housing is 270 mm [≈ 10.63"] without, and 316 mm [≈ 12.44"] with optionally mounted peristaltic pumps. The cooler ECM-EX2 is conform to the system protection IP20 (EN 60529).
Function The M&C gas cooler type ECM-EX2 is a compressor cooler equipped with a status alarm for safe and continuous operation. Up to 2 Jet-stream heat exchangers made of Borosilicate glass, PVDF or stainless steel are located in a heat-insulated cooling block, where they are easy to access and to remove.
Receiving and storing of the device The ECM-EX2 gas cooler is a complete pre-installed unit. • Please remove the ECM-EX2 carefully from the packaging. Check the scope of the delivery specified on the delivery note. Please make sure that you have received all items stated on the delivery note. •...
Mounting Do not mount or carry out any work at the gas cooler while potentially explosive atmosphere is present. The process and the environment of the cooler needs to be explosion-free (explosion- free zone) during mounting. A zone is declared as explosion-free zone, if it is free of explosive atmosphere.
Page 19
• The sealing rings should be installed with the PTFE side facing the medium. PVDF- resp. stainless steel heat exchangers with G 1/4" female resp. G 3/8" female • The fitting tubing or hose couplings with threaded connections have to be screwed in with PTFE thread sealing tape.
Electrical connections Wrong supply voltage can destroy your cooler! When connecting the equipment, make sure that the supply voltage is identical Caution with the information provided on the model type plate! Only carry out work on live parts when the area has been proved to be “safe“. Only carry out work on the protective cover in front of the temperature controller, Warning when the area has been proved to be “safe“.
Follow these instructions to connect the status alarm and power cables: 1. release the screws (7 pcs.) from the cooler hood and remove the hood; 2. put the cables (6-12 mm) through one of the cable glands in the bottom plate, and connect them according to the electrical connections in Figure 5;...
Before starting up the gas cooler, it must be placed in its operating position for at least two hours. The liquid inside the system may have been redistributed, and this could cause problems during operating. Note The following steps should be carried out before initial start-up: 1.
Maintenance Qualified personnel The work described in this chapter can be carried out by qualified personnel. The following knowledge is at least required for the work: • Instructed person in EX-protection • Trained person in the electrotechnical field • Detailed knowledge of the manual and the applicable safety regulations The operator must ensure that all work on the ECM-EX2 is carried out only by authorized and qualified personnel.
20.1 Adding and replacing the heat exchangers Removal of the heat exchangers may be necessary to carry out any maintenance or repair work. The cooler does not need to be switched off while replacing the heat exchangers. We recommend the following procedure to replace the heat exchangers: 1.
20.2 Cleaning the fins of the condenser Dust on the fins of the condenser reduces the cooling capacity. Therefore, it is necessary to clean the fins frequently. The following steps are recommended: 1. Shut off the gas flow; 2. Disconnect the power supply. 3.
Pump head (outside the cooler housing) Cooler front panel Recommended mounting distance Pump motor (inside the cooler housing) Figure 6 SR25.2: Mounting distance between front panel and pump motor For detailed mounting instructions, see the SR25.2 instruction manual. The manual is available on our website www.mc-techgroup.com.
1 Conveying belt 2 S-bolt 3 Pump tubing with connectors 4 Contact pulley 5 Springs Figure 7 Replacing the pump tubing For changing the pump tubing please proceed as follows: 1. Unplug the pump from the mains voltage. The device needs to be voltage free. Open tube connections at the pump;...
Figure 8 Different pump tube sizes 20.3.3 Replacing contact pulleys and springs While mounting, make sure that the center of rotation and the driver are aligned. Use genuine spare parts only! Note Follow these instructions to change the contact pulley and springs: 1.
6. Dismount roller axes and change contact pulleys. Take care that axes are not worn out by the springs and have damaged the dent at the axes front end. In case of abrasion the axes have to be changed (see Figure 10).
20.3.5 Cleaning the pump head When changing flexible tubing or other parts, inspect all parts for contaminations before assembling the pump head. Clean contaminated parts if necessary. We recommend cleaning the parts with a dry cloth. Solvent should not be used, because it can damage the plastics and synthetic rubber parts.
Operating of the built-in electronic temperature controller A new electronic temperature controller was installed in the housing of the ECM-EX2 cooler starting in June 2024. All built-in temperature controllers are factory set to the following values: Gas outlet dew point 5 °C, alarm window 3 °C and hysteresis 1 °C.
21.1.1 Changing the setpoint The temperature controller needs to be unlocked, before changing the setpoint. To unlock the device, first press the OK key for about 3 seconds. The display changes to a flashing "000". Then enter the PIN code "017" with the arrow keys and confirm the entry with OK. The display jumps back to the temperature view.
Trouble shooting The following table gives an overview of possible errors and instructions for checking and repairing the unit (Applies only to the start-up period of the cooler). Error Possible reason Check/Repair Condensate in the gas outlet Ambient temperature < 5 °C [41 °F] Heat up the components downstream;...
Spare parts list The replacement interval for spare parts and consumables depends on the specific operating condition of the analyzer. The quantities recommended in the following table are based on experience. Your replacement intervals will be based on your operating conditions. Electric gas cooler ECM-ExII (C) Consumable parts (R) Recommended spare parts...
Peristaltic pump SR25.2 (C) Consumable parts (R) Recommended spare parts (S) Spare parts Recommended quantity being in operation [years] Part No. Indication C/R/S 90P1007 Hose set SR25.1 with PVDF-tube connectors 4/6 mm, standard 90P1020 Driver SR25, complete 90P1010 1 set (4 pcs) contact springs SR25 for driver 90P1045 Contact pulleys SR25 PVDF ...
Risk rank or required Risk value performance level Low risk Starting point High risk Severity of injury: S1 = 1 = minor (reversible injury) S2 = 2 = serious (irreversible injury, death) Frequency and duration: F1 = 1 = infrequent or short exposure to hazard F2 = 2 = frequent (more than once per hour/shift) Possibility of preventing or limiting the damage P1 = 1 = possible...
Page 37
Caution glass Risk rank - group A The product contains glass components. In general, for electrical and mechanical work on the product, wear personal protective equipment (PPE) in accordance with the risk assessment. Caution hot surfaces Risk rank group A The temperature inside the product can be higher than >...
Caution crushing hazard Risk rank group A The work must be performed by trained personnel only. This applies to products weighing less than < 40 kg [≈ 88.2 lbs]: The product can be transported by 1 to 2 person(s). The instructions for appropriate personal protective equipment (PPE) must be observed.
