Summary of Contents for Asko HI3CTA07
- Page 1 Instructions for use Induction hob HI1345G / HI3CTA07...
-
Page 2: Table Of Contents
CONTENTS Your induction hob Introduction Control panel Safety instructions Temperature safety Cooking-time limiter Operation of the touch-sensitive buttons Induction cooking How induction works Pans for induction cooking Induction noises Operation Switching on and setting the power Residual heat indicator Boost Switching off Stand-by modus Eco stand-by modus... -
Page 3: Your Induction Hob
YOUR INDUCTION HOB Introduction This induction hob is designed for the true lover of cooking. The cooking zone has a high capacity and responds fast and effectively. The cooking zone is designed especially for the wok and does not only heat the base of the pan, but also a large part of the pan itself, making you experience maximum cooking comfort. -
Page 4: Control Panel
YOUR INDUCTION HOB Control panel 10 11 12 1. Pauze button 2. Pauze indicator 3. Childproof lock/Eco stand-by button 4. Childproof lock indicator/Eco stand-by indicator 5. Level indicator in cubes 6. On/off button 7. Reduce the power quickly 8. Reduce the power 9. -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS Before use, read the separate safety instructions first! Temperature safety • The cooking zone is equipped with a sensor that measures the temperature of the bottom of the pan to avoid any risk of overheating when a pan boils dry. In case of temperatures rising too high, the power is reduced or shut off automatically. -
Page 6: Use
It is important to use the wok that is included, as this wok is fully in contact with the cooking zone. Suitable pans are available via the website ‘www.asko.com’. Attention • Grains of sand may cause scratches which cannot be removed. -
Page 7: How Induction Works
How induction works A magnetic field is generated in the appliance. By placing a pan with an iron base on a cooking zone, a current is induced in the pan base. This induced current generates heat in the base of the pan. Easy The electronic controls are accurate and easy to set. -
Page 8: Pans For Induction Cooking
The best are pans with the ‘Class Induction’ quality mark. • Suitable pans are available via the website ‘www.asko.com’. Not all pans are suitable for induction cooking. Therefore it is important to know whether the pan is of the appropriate material. With a magnet, you can check if the pan is suitable. -
Page 9: Induction Noises
How to use the wok • Carefully place the pan on the cooking zone. When handling the pan carelessly, the handle may hit and damage the glass. • Do not shake the pan while on the cooking zone. This may cause scratches on the glass, or the glass can get damaged by the handle. -
Page 10: Operation
OPERATION Switching on and setting the power The cooking zones have 12 levels. Beside it there is a level ‘boost’. 1. Put a pan into the cooking zone. 2. Press the childproof lock button. You will hear a signal. 3. Press the on/off button of the cooking zone concerned. In the display ‘-’... -
Page 11: Boost
OPERATION Boost You can use the ‘boost’ function to cook at the highest power level during a short period of time (max.10 minutes). After the maximum boost time the power will be reduced to setting 12. Switching on ‘boost’ 1. Put a pan into the cooking zone. 2. -
Page 12: Stand-By Modus
OPERATION Stand-by modus In stand-by modus the induction hob is switched off. You can switch to the stand-by mode from the eco stand-by mode, or by switching off the cooking zone. From the stand-by mode you can directly start cooking by pressing the on/off button. -
Page 13: Childproof Lock
OPERATION Childproof lock Your induction hob is equipped with a childproof lock that lets you lock the appliance. It prevents unintended switching on. Switching on the childproof lock 1. Press the child lock button for at least 2 seconds. A double beep will be heard. All buttons are inactive now, except for the childproof lock button. -
Page 14: Recognizing A Mode
OPERATION If you press the pause button again within 5 minutes, the paused cooking process will be resumed. A double beep will be heard, the hob resumes the settings as they were set before the pause. If you do not undertake any further action within 5 minutes: The active cooking zone will be switched off automatically. - Page 15 OPERATION Attention • The timer-/kitchen timer function can also be used without activating the cooking zone. Switching on the timer 1. Press the timer/alarmclock button of the cooking zone once. Three flashing zeroes and + and - appear in the display. If you do not set a time with the + or - button, the timer will start running automatically after 3 seconds.
-
Page 16: Switching On And Off The Beep
OPERATION Setting the cooking time Switch the kitchen timer on. Button Steps of x per Time button contact x = 1 minute 0.00 to... – x = 10 seconds 5.00 - 0.00 – x = 30 seconds 9.00 - 5.00 –... -
Page 17: Automatic Pan Detection
OPERATION Switching on/off the automatic pan detection If, after the hob has been turned on, a pan is placed in an inactive cooking zone, the operating controls light up and this can be used immediately (without operating the on/off switch). If the cooking zone is not activated within 10 seconds, the light will go out. -
Page 18: The Ideal Wok Setting
Healthy cooking Burning point of different types of oil Burning point of separate kinds of oil ASKO advises to choose an oil based on the baking temperature to bake in a healthy way. Every kind of oil has a different burning point at which toxic gases are released. -
Page 19: Maintenance
MAINTENANCE Cleaning Activate the childproof lock before you start cleaning the hob. Daily cleaning • Although food spills cannot burn into the glass, we nevertheless recommend you clean the hob immediately after use. Best for daily cleaning is a damp cloth with a mild cleaning agent. •... -
Page 20: Faults
General The service department telephone number can be found on the guarantee card provided or on ‘www.asko.com’. If you notice a crack in the glass top (however small), switch the hob off immediately, unplug the hob, turn off the (automatic) fuse switch(es) in the meter cupboard or, in the event of a permanent connection, set the switch in the power supply lead to zero.) Contact the service... - Page 21 Make sure the venting holes under the cooking plate are open. Fault code E6 Wrong pan. Suitable pans are available via the website ‘www.asko.com’. Hardware / software error. Contact the service department. Other fault codes. Defective generator. Contact the service department.
-
Page 22: Installation Instructions
INSTALLATION INSTRUCTIONS Safety instructions for the installation • The connection must comply with national and local regulations. • The appliance must always be earthed. • This appliance may only be connected by a competent electrical installer. • Always connect the appliance to an earthed socket. •... -
Page 23: Attachment Points For Mounting Brackets
INSTALLATION INSTRUCTIONS Attachment points for mounting brackets Do not remove or twist Thick worktops Thin worktops the nut! Front EN 24... -
Page 24: Installation Dimensions
INSTALLATION INSTRUCTIONS Installation dimensions The dimensions and recesses are shown in the illustration beneath. min.40 Ventilation hi3271w The electronics in the appliance need cooling. The appliance will automatically switch off if there is insufficient air circulation. There are ventilation openings at the bottom of the appliance. It must be possible for cool air to be drawn in through these openings. -
Page 25: Constructing Above An Oven Or Fixed Pannel
INSTALLATION INSTRUCTIONS Constructing above an oven or fixed pannel Ventilation occurs through the plinth (A) and the back of the cupboard (B). Saw out the ventilation openings (min. 100 cm ). Air supply A is superfluous when, together with opening B, there’s an opening somewhere else where air can be drawn in. -
Page 26: Fitted-Unit Situation With Space
INSTALLATION INSTRUCTIONS Fitted-unit situation with space X mm min. 10 mm min.50 X mm +50 mm 50 mm Coupling examples with a coupling profile HG1365G HI1345G HG1355G HT1334S HF1334S HG1365G HG1355G HI1345G HT1334S HF1334S Coupling profile for making certain that appliances are mounted tightly next to each other EN 27... -
Page 27: Building In
INSTALLATION INSTRUCTIONS Building in Check that the cabinet and the cut-out meet the dimension and ventilation requirements Treat the sawn ends of wooden or synthetic worktops with sealing varnish if necessary, to prevent moisture causing the worktop to swell. Lay the hob upside down on the worktop. Remove the protective layer from the sealing tape and apply the tape in the groove of the aluminium profile or on the edge of the glass plate. -
Page 28: Technical Details
TECHNICAL DETAILS Capacity and dimensions table This appliance complies with all relevant CE directives. Hob type HI1345G Induction Connection 220-240V 50/60Hz Phases Maximum capacity cooking zone 3 kW (Ø 300) Total connected load 3 kW (Building in) dimensions Appliance width x depth 384 x 522 mm Build-in height from top of worktop 125 mm... -
Page 29: Environmental Aspects
ENVIRONMENTAL ASPECTS Disposal of packaging and appliance In the manufacturing of this appliance durable materials were used. Make sure to dispose of this equipment responsibly at the end of its lifecycle. Ask the authorities for more information regarding this. The appliance packaging is recyclable. The following may have been used: •... - Page 30 EN 31...
- Page 31 *614172* 614172...
