- Page 1 INSTRUCTIONS FOR USE HI5320Fxx1 HI5632Fxx1 Induction hob HI5642Fxx1 HI5643Fxx1 HI5842Fxx1 HI5952Fxx1 HI5954Fxx1...
-
Page 2: Table Of Contents
Contents Pictograms used ........Time functions ..........Safety ............Operation of the linked extraction hood ..Safe use ............Wi-Fi ............Your induction hob ........Switching Wi-Fi on and off ......Dear customer! ..........Firmware Update ......... Description ........... Settings ............Control panel .......... -
Page 3: Pictograms Used
Pictograms used The following symbols are used throughout the manual, and they have the following meanings: INFORMATION! Information, advice, tip or recommendation WARNING! Warning general danger ELECTRIC SHOCK! Warning danger of electric shock HOT SURFACE! Warning danger of hot surface DANGER OF FIRE! Warning danger of fire... -
Page 4: Safety
Safety IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP IT FOR FUTURE REFERENCE! General The manufacturer cannot be held liable for any damage resulting from failure to follow the safety instructions and warnings. Damage caused by incorrect connection, incorrect fitting, or incorrect use is not covered by the warranty. - Page 5 Safety NEVER try to extinguish a fire with water. Instead, switch the appliance off and then cover the flames with, for example, a lid or a fire blanket. If a drawer underneath the appliance is permitted (see the installation instructions), without an intermediate bottom, this should not be used to store highly flammable objects/materials.
-
Page 6: Safe Use
Safety Ceramic glass plate broke Shut immediately off all burners and any electrical heating element and isolate the appliance from the power supply. Do not touch the appliance surface. Do not use the appliance. The cooking zones heat up during use and stay hot for a while afterwards. -
Page 7: Cooking Time Limiter
Safety Temperature safety induction zones The hob is fitted with a cooling fan which cools the electronic components during cooking. The fan may operate for a while, even after the end of the cooking process. The induction cooking hob is also fitted with an overheating protector which protects the electronic components from damage. -
Page 8: Your Induction Hob
Your induction hob Dear customer! Welcome to our growing ASKO family! We are proud of our appliances. We hope that this appliance will be an appreciated and dependable aid for many years to come. Please read the operating instructions before use. They include general tips, information about the settings and adjustments you can make, and the best way to take care of your appliance. -
Page 9: Description
Your induction hob Description Since the appliances for which these instructions were drawn up may have different equipment, some functions or equipment may be described in the manual that may not be present in your appliance. 1. Cooking zone ø 260 mm - 2.3 kW (3.6 kW (boost) 2. -
Page 10: Control Panel
Your induction hob Control panel 1. On/Off and Child lock touch key 2. Pause/Start touch key 3. Wi-Fi/connectivity touch key 4. Kitchen timer touch key 5. Controls for front left cooking zone a. Cooking zone timer touch key + indication b. -
Page 11: Explanation Of The Touch Keys Function
Your induction hob Explanation of the touch keys function Touch key/slider Description Switching the hob on/off The appliance can be switched on and off with the on/off key. On/Off Child lock The hob can be locked and unlocked to prevent it from being accidentally switched on. -
Page 12: Program Function Explanation
This function is exclusively for Bridge Induction cooking zones, that are combined to a larger cooking zone. Grilling is optimised for the ASKO induction accessories: grill plate and teppanyaki. This function also works with other cookware, but perhaps less accurately. -
Page 13: Indications In The Display
Your induction hob Hob recall function This feature allows you to recall all the settings of the cooking zones if the hob was accidentally switched off. The hob should be switched on again within 6 seconds. Pressing the Pause/Start key within 6 seconds will recall all settings before the appliance was last switched off. -
Page 14: Use
Induction cooking Induction cooking is fast To start with, you will be surprised by the speed of induction cooking. Especially at higher settings, foods and liquids will come to a boil very rapidly. It is best not to leave pans unattended to avoid them boiling over or boiling dry. -
Page 15: Pans For Induction Cooking
Safe The heat is generated in the pan itself. The glass top does not get any hotter than the pan. This means that the cooking zone is considerably cooler than a ceramic hob, for example. Once a pan has been removed, the cooking zone cools down quickly. Capacity distribution of cooking zones Depending on the hob model, the cooking zones can affect each other. - Page 16 WARNING! Be careful with enamelled sheet-steel pans: the enamel may chip (the enamel comes loose from the steel) if you switch the hob on at a high setting when the pan is (too) dry; the base of the pan may warp - for example: Due to overheating; heat enamelled pans slowly.
-
Page 17: Induction Sounds
Induction sounds Ticking sound This sound can be caused at lower power level settings or by the automatic pot detection. Pan makes sounds Pans can make some noise during cooking. This is caused by the energy flowing from the hob to the pan. -
Page 18: Cooking Settings
Cooking settings Because the settings depend on the quantity and composition of the pan and its contents, the table below is intended as a guideline only. Level Purpose simmer bouillon, Use settings 1 - 5 to: stew meats, simmer vegetables, melt chocolate, poach, melt cheese. -
Page 19: Operation
Operation Start Preparing Two cooking modes are available: 1. Standard cooking with power levels. 2. Cooking with the PLUS menu. Standard cooking 1. Place a pan on a cooking zone. Make sure the bottom of the pan and the surface of the cooking zone are clean and dry. 2. -
Page 20: Bridge Induction Zone
Operation Boost You can use the ‘boost’ function for cooking at the highest power level during a short time (max. 10 minutes). After the maximum boost time has passed, the power will be reduced to setting 12. 1. Place a pan on a cooking zone. 2. -
Page 21: Induction Cooking Zone
Operation 3. Use the slider of the front cooking zone to set the desired cooking setting for the linked cooking zones. 4. Touch both cooking zone keys again to unlink the cooking zones. Induction cooking zone The '5 + Induction' cooking zone can be used as a single or extended cooking zone when a large (oval) pan is placed on it. -
Page 22: Pause
Operation NOTE! Always add water, oil or butter before starting a program; do not use an empty pan or pot. Keeping warm and Heating up Temperature (°C) melt chocolate heating up/keeping warm simmer vegetables bring food or liquid to the boil quickly NOTE! If the cooking zone is hot, 'keep warm' and 'heating up' programs are unavailable. -
Page 23: Child Lock
Operation You will hear a short beep. The settings on all active cooking zones are reduced to setting 1 to keep food warm. All timer functions are paused. The pause key and slider flash. All keys are inactive except the pause and on/off-key. If no key is touched within 10 minutes, all active hobs automatically turn off. - Page 24 Operation Touch the cooking zone timer button to select the stopwatch timer. After a short delay, it starts counting. If ‘Auto-Stopwatch Timer’ is on, the stopwatch timer will start counting immediately when a power level is set. The current value will not be visible until the stopwatch timer is selected. If ‘Auto-Stopwatch Timer’...
-
Page 25: Operation Of The Linked Extraction Hood
Operation Deactivating the cooking zone timer 1. Long touch the cooking zone timer key of the desired active cooking zone. The timer is switched off. Kitchen timer The kitchen timer is not connected to a cooking zone. The kitchen timer does not switch off the cooking zone. - Page 26 Operation Switching the light on and off 1. Touch the lighting key. The light switches on at maximum strength. 2. Long touch the lighting key to set the lighting strength. 3. Short touch the lighting key to turn off the light. Automatic extraction The extraction module has three automatic extraction settings (see chapter ‘Settings’): Synchro Start (Settings)
-
Page 27: Wi-Fi
Wi-Fi Switching Wi-Fi on and off The hob is equipped with a Wi-Fi module that allows the appliance to connect to the internet via your home network. You will first connect your mobile device directly to the appliance via Bluetooth, and then use this connection to share the data of your Wi-Fi home network. -
Page 28: Firmware Update
Wi-Fi NOTE! Already connected users can add additional users in the ConnectLife application by sharing the device. Unpair all users This option requires that the connection setup has been performed successfully and the hob is connected to the cloud (Wi-Fi key is constantly full lit). 1. -
Page 29: Settings
Settings You can tailor the behaviour of this induction hob to suit your cooking style! There are various settings available for adjustment. 1. Make sure all cooking zones are switched off. 2. Touch the pause button for 2 seconds. 2 sec. The settings menu opens. - Page 30 Settings Table continued from last page brd - Auto bridge While on, when a new pan is detected on two connected Bridge Induction cooking zones, the cooking zones are automatically connected into one Automatic coupling big cooking zone. While off, connecting must be done manually by pressing on the sliders of two Bridge Induction cooking zones at the same time.
- Page 31 Settings Table continued from last page Snd - Sound volume Sound volume has 4 different options. L3 (high), L2 (medium), L1 (low), off (only error and alarm sounds). Sound volume SEn - Key sensitiveness Key responsiveness has 3 different speed options. L3 (quick), L2 (medium), L1 (slow).
- Page 32 Settings Table continued from last page Con - Connection WARNING! power Current limiter A registered and qualified installer must set the current limiter to match (connection to power your connection and circuit breakers. Please read the safety regulations grid) and the installation instructions carefully. If your electrical wiring or circuit breakers do not meet the specified current draw on the rating plate, the current limiter can be activated by reducing the value of this setting.
-
Page 33: Maintenance
Maintenance Cleaning glass top After each use, wait for the glass ceramic surface to cool down and clean it. Otherwise, all remaining impurities will burn onto the hot surface the next time you use the hob. For regular maintenance of the glass ceramic hob, use special care products that create a protective film on the surface to prevent the dirt from sticking onto it. - Page 34 Maintenance TIP! Activate the child lock before cleaning the hob. Daily cleaning Although food spills cannot burn into the glass, we nevertheless recommend you clean the hob immediately after use. For daily cleaning, a damp cloth with a mild cleaning agent is best. Dry off with kitchen paper or a dry tea towel.
-
Page 35: Troubleshooting
Troubleshooting General NOTE! If you see a crack or tear (however small) in the glass plate, immediately switch off the hob and disconnect it from the power supply (unplug it from the socket-if any). Then contact the Service Department. Troubleshooting table If your hob does not work properly, it does not always mean that it is defective. - Page 36 Troubleshooting Table continued from last page Symptom Possible cause Solution Zone stops unintended and Zone is overheated. After the hob has cooled down, residual heat indicator is shown. cooking can be continued. A fuse blows when the hob is The appliance is incorrectly Check the electrical connected to the electrical connected.
- Page 37 Troubleshooting Troubleshooting Wi-Fi Symptom Possible cause Solution Wi-Fi icon not shown. Wi-Fi turned off. The hob must be switched off, then touch the on/off key and hold it for 5 seconds. Wi-Fi setup failed. Home network issues. Check that your home network signal is strong and internet connection is working.
-
Page 38: Technical Data
Technical data Compliance information Radio equipment type HL3215STG HLW3215-TG HLW3215-TG01 Wi-Fi Operating frequency range 2.412GHz - 2.472GHz Maximum output power ≤10 dBm/MHz ( EIRP) (Antenna gain 10 dBi) Maximum antenna gain Gain: 0 dBi Bluetooth Operating frequency range 2.402 GHz - 2.4800 GHz Carrier Output 6 dBm (≤10 dBm) Emission type... -
Page 39: Installation
Installation If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. Safety If the safety instructions and warnings are not followed, the manufacturer cannot be held responsible for any resulting damage. - Page 40 Installation Service Disconnect the appliance from the mains supply before starting any repair work. Faulty parts may only be replaced by original parts. The manufacturer can only guarantee that original parts meet safety requirements.
-
Page 41: Preparations For Installation
Installation Preparations for installation Free space around the appliance A (>mm) B (>mm) C (>mm) D (>mm) = 650 = 900 = 450 = 50 Accessibility Accessibility Oven Air vents in the lower kitchen cabinet Normal operation of the induction cooking hob electronic components requires sufficient air circulation. Lower cabinet with a drawer In the cabinet's rear wall, there must be an opening with a height of at least 140... -
Page 42: Flush-Mount
Installation Lower cabinet with an oven Only install ovens with a cooling fan under the induction hob. Before installing the oven, the kitchen cabinet rear wall has to be removed in the area of the opening for installation. If other appliances are installed under the induction cooking hob, we cannot guarantee their correct operation. -
Page 43: Built-In
Installation Stone countertop 1. Countertop 2. Appliance 3. Slot Given the margin of error (tolerance) for the glass ceramic plate of the appliance, and the cutout in the countertop, the slot is adjustable (min. 2 mm). Ceramic, wooden, or glass countertop 1. - Page 44 Installation A (mm) B (mm) C (mm) D (mm) E (mm) HI53xxx Min. 600 Min. 40 Min. 60 HI56xxx Min. 600 Min. 40 Min. 60 HI58xxx Min. 600 Min. 40 Min. 60 HI59xxx Min. 600 Min. 40 Min. 60 Cut-out in the worktop (flush) A1 (mm) A2 (mm) B (mm)
-
Page 45: Electrical Connection
Installation Sealing tape Glass drip tray Sealing tape Electrical connection Determining the existing electrical connection Check the voltage. Before connecting the appliance, make sure the voltage specified on the rating plate conforms to the voltage of your power mains. The voltage of your power mains (220–240 V between L and N) should be checked by an expert using an appropriate measuring device. - Page 46 Installation Power limiter See chapter ‘Settings’, under Con - power limiter to set the parameter. This parameter must be set before placing a pan on the hob or activating a cooking zone. WARNING! Setting the power limiter should only be carried out by a registered and qualified installer. Please read the safety regulations and the installation instructions carefully.
-
Page 47: Connecting & Testing
Installation Power cord core cross sectional area should be at least 1,5 mm² for the following power limiter settings which should be adjusted to your circuit breakers: Power limiter Connection type Power cord Number and cross configuration Type section of Power cord wires 3x16 A / 3x13 A / 3 phases - 1 neutral... -
Page 48: Environmental Aspects
Environmental aspects Disposal of the appliance and packaging Sustainable materials have been used during the manufacture of this appliance. This appliance must be disposed of responsibly at the end of its service life. Ask your local authorities for more information about how to do this. -
Page 49: Your Notes
Your notes... - Page 50 Your notes...
- Page 51 Your notes...
- Page 52 The appliance identification card is located on the bottom of the appliance. Stick the appliance identification card here. www.asko.com 941104 We reserve the right to make changes.
