- Page 1 TS series USER MANUAL V. 20.06...
- Page 2 Lynx Pro Audio S.L. shall not be liable to the purchaser of this product or to third parties for any damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of an accident, misuse, or abuse of this product, nor for any modifications, repairs, or alterations to it, or for failing to strictly adhere to the operating and maintenance instructions of Lynx Pro Audio S.L.
-
Page 3: Table Of Contents
CONTENTS 1. INTRODUCTION TS Description.........................6 Description of the TS front panel ................7 Description of the TS back panel................7 TS Characteristics......................9 Output power........................9 TS Dimensions........................9 2. TECHNICAL SPECIFICATIONS........................10 3. TROUBLESHOOTING............................11 LYNX PRO AUDIO GUARANTEE........................13... - Page 4 WELCOME Just contact the new generation of digital amplifiers, designed and manufactured by Lynx Pro Audio S.L. Before working with the amplifier we recommend that you read this manual, in its pages you will find instructions for use, programming examples and practical advice that will be of great help.
- Page 5 Before unpacking your new amplifier, verify that the box does not show any damage or deformation. If this happens, please claim the damage to your fordwarder. Once unpacked and verified its correct operation, keep the original box in case you need to ship it back to your provider. TS Series | User Manual...
-
Page 6: Introduction
Phoenix input and output connectors and allow output levels to be controlled through the rear panel potentiometers. The design includes Lynx Pro Audio’s advanced Power Control Management system, which allocates power across the channels according to the user’s needs, even enabling maximum power to be delivered through a single channel. -
Page 7: Description Of The Ts Front Panel
These LEDs are used to provide visual information about the status of the clip, faults and signals. 02. POWER SUPPLY INDICATION The LED indicates that the amplifier is receiving power and is switched on. 03. POWER ON SWITCH TS back panel description TS Series | User Manual... - Page 8 Bridge mode: Low impedance bridge mode. 200V/140V high impedance mode. 11. SIGNAL INPUTS - Input Link: Linking of input signals in consecutive channels. - Output Levels: Hidden potentiometers on the rear for adjusting output levels. TS Series | User Manual...
-
Page 9: Ts Characteristics
1 x 2500W Hi -Z 70 V 4 x 625 W 4 x 1250 W 4 x 2500 W 1 x 900 W 1 x 1800 W 1 x 2500 W TS Dimensions (in mm) TS Series | User Manual... -
Page 10: Technical Specifications
Weight Net (kg - lbs) 7 - 15.4 Soft-start, Turn-on Turn-off transients, Over-heating, DC, RF, Short-circuit, Open or Protections mismatched loads, Overloaded power supply, ICL™, PMS™ and SSP™ *IEC filtered pink noise signal (40Hz-5kHz, 12dB crest factor). TS Series | User Manual... -
Page 11: Troubleshooting
4 – One of the cabinets ( with the same signal ) sounds less than the others Check that the joining cable from the amplifier to the cabinet is well balanced otherwise the output signal will fall 6 dB. TS Series | User Manual... - Page 12 DECLARATION OF CONFORMITY Lynx Pro Audio S.L. declares that ionic series are in conformity with the following EC directives: Low Voltage Directive 2006/95/EC Electromagnetic Compatibility EMC 2004/108/EC RoHS Directive 2002/95/EC In accordance with Harmonized European Norms: EN 60065:2002 Audio, video and similar electronic apparatus. Safety requirements EN 55103-1:1996 Electromagnetic compatibility.
-
Page 13: Lynx Pro Audio Guarantee
Lynx Pro Audio S.L. In the case that the product could not be returned to the factory for checking and repairing, Lynx Pro Audio S.L. - Page 14 LYNX Pro Audio S.L. Calle 1. Pol. Ind. Picassent, Picassent, Valencia 46220 España +34 961 109 601 www.lynxproaudio.com...
