AURATON Pictor DS
User manual ver.
The document presents collected information on safety, assembly and use of AURATON Pictor DS.
Weekly Wired Temperature Controller (with two-sensors)
AURATON Pictor DS is a weekly, wired temperature controller with additional, external temperature
sensor, designed to work with a gas or electric heating system.
é
Six independent temperature measurements per day
AURATON Pictor DS allows setting up of up-to six independent temperature measurements
during the day scheduled with interval accuracy of one minute. Intervals of measurements
are freely selectable by the user.
Calibration of temperature measurements (offset)
It allows temperature adjustment within a tolerance of ±3 °C.
LED display
LED
Thanks to the backlit display, operation of the controller may be monitored even in a poorly
lit room.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pictor DS and is the answer not in the manual?

Questions and answers

Related Manuals for AURATON Pictor DS

Summary of Contents for AURATON Pictor DS

  • Page 1 AURATON Pictor DS User manual ver. The document presents collected information on safety, assembly and use of AURATON Pictor DS. Weekly Wired Temperature Controller (with two-sensors) AURATON Pictor DS is a weekly, wired temperature controller with additional, external temperature sensor, designed to work with a gas or electric heating system.
  • Page 2 Description of AURATON Pictor DS Weekly Wired Temperature Controller A LED display and five touch-sensitive function keys are located on the front side of the controller housing. Display Function keys...
  • Page 3 Day of week (1-7) – indicates the current weekday. Each day has its own number assigned. Scheduling of program operation (programming). Program temperature – indicates the currently set temperature to maintain. Î ) icon – indicates key lock function is enabled. Temperature – In the normal operation mode, AURATON Pictor DS displays the temperature of...

  • Page 4: Function Keys

    ç Controller power ON indicator ( ) – informs about the operation status of AURATON Pictor DS, and appears once the controlled equipment has been switched on. Ö Manual control indicator ( ) – appears once the automatic mode of operation has been disabled (see the chapter: “Manual control mode”).
  • Page 5 ë menu ( press and release the key to switch between manual and automatic mode of operation press and hold down for about 5 s when the controller is off to proceed to advanced settings press and hold down for about 5 s when the controller is switched on to set the programs É...
  • Page 6 â power ON/OFF of the controller ( power on – press and hold down for 2 s power off – press and hold down for 5 s Á DOWN key ( ) – press and hold down to decrease quickly temperature or time Â...

  • Page 7: Connection Of Cables

    Proper operation of AURATON Pictor DS depends to considerable extent on its location. Do not install the controller in a place with restricted air circulation or in direct sunlight as it may interfere with its proper operation. Install AURATON Pictor DS on internal (partition) wall in a place with unconstrained air circulation.
  • Page 8 1-2 – terminals of control input (COM-NO/NC) 3-4 – terminals of 230 V AC power supply (N, L) 5-6 – terminals of external temperature sensor...
  • Page 9 Mounting of AURATON Pictor DS weekly, wired temperature controller Remove the housing as shown below. Tighten rear part of the controller housing to standard junction box Ø 60 mm using the supplied screws. Insert the housing.

  • Page 10: First Start-Up

    First start-up When the power is properly connected, the LED display shows all indicator’s segments for a while.
  • Page 11 Then the controller waits for first start-up or time setting (off mode) Setting clock time and day of week To set the clock time, switch off the controller.
  • Page 12 É Press and hold down ( ). for 5 s. The “minutes” indicator starts blinking. ÁÂ É Use ( ) function keys to set the desired number of minutes and confirm with ( ÁÂ É Use ( ) function keys to set the desired number of hours and confirm with (...
  • Page 13 ÁÂ A blinking day of week symbol appears in the upper left corner of the display. Use ( ) function É keys to set the desired day of week and confirm with (...
  • Page 14 NOTE: When setting any function, failure to press any key for 10 s is deemed the entered data have been confirmed. NOTE: When you press any function key once, always all data are displayed at the beginning, and twice – the function of respective key is enabled.
  • Page 15 Setting the schedule of controller program operation – see section Advanced settings. When working with three schedules, AURATON Pictor DS enables saving of up to six programs. This allows exceptionally precise scheduling of the temperature in the house depending on the time of day.
  • Page 16 To start programming: NOTE: Switch on the controller. ë Press and hold down the ( ) key for about 5 s to display flashing hour indicator.
  • Page 17 ÁÂ Use the ( ) keys to set the start time (hours) of the program and then move on to setting the ë minutes by pressing the ( ) key again. ÁÂ Use the ( ) keys to set the start time (minutes) of the program and then move on to setting the ë...
  • Page 18 ÁÂ Use the ( ) keys to set the programmed temperature, and then move on to setting the next ë program by pressing the ( ) key.
  • Page 19 Set all other programs up to the total of six in the same way. Now, all programs Monday through Friday (5 days) have been set. To set six other programs for Saturday and Sunday (two days) follow the same procedure as for weekdays; the display shows “2”, which means Saturday and Sunday.
  • Page 20 NOTE: Once the program setting has been completed, the controller automatically saves the settings and starts normal operation. NOTE: Upon setting the 2nd schedule (2:7 days), it is enough to set six programs, one for each day of the week.

  • Page 21: Manual Control

    Ç To interrupt the program running for a longer time, use the holiday mode. When this option is active, AURATON Pictor DS keeps only the “holiday temperature” The maximum duration of the holiday mode is 30 days. To activate the holiday mode, switch on the controller and: É...
  • Page 22 ÁÂ É Change to ON using the ( ) keys and confirm with ( ) key. ÁÂ É Now, using the ( ) keys, select the desired number of days and confirm with (...
  • Page 23 ÁÂ Use the ( ) keys to set the desired temperature.
  • Page 24 É Confirm the above settings with the ( Ç During the holiday mode, the ( ) icon is displayed on the screen. É ÁÂ To exit the holiday mode at any time – press and hold down the ( ) key for about 5 s and the ( ) key É...

  • Page 25: Advanced Settings

    Advanced settings ë Switch off the AURATON Pictor DS controller and press and hold down the ( ) key for about 5 s to enable the advanced settings menu. Select any item A1 through A16 by short pressing and release ë...
  • Page 26 The calibration function allows fine tuning of the temperature indication within the tolerance range of ± 3 °C. -e.g. AURATON Pictor DS indicates the room temperature is 23 °C, while an ordinary thermometer placed nearby indicates 24 °C. Upon completed calibration by +1 °C, AURATON...
  • Page 27 A3 Parental control Allows restriction of access to strangers. A4 In case of power failure This function allows setting the behavior of the AURATON Pictor DS controller in the event of power failure and return. A5 Display brightness Allows setting the display brightness during operation.
  • Page 28 A6 Program operation schedule Allows setting the way of programming the Auraton Pictor DS controller. Three programming schedules are available, namely: Schedule „0” (5+2) enables programming the controller from Monday through Friday (six programs) and separately, Saturday and Sunday (six programs).
  • Page 29 When N1 is set, the controller operates only with the internal (built-in) sensor. If N2 is set, AURATON Pictor DS controller operates only with the external sensor (connected by cable). Setting N3 – both sensors work simultaneously. In this case, heating goes OFF once the required temperature has been reached at either sensor.

  • Page 30: Wiring Diagram

    ) symbol. A15 Relay operation The AURATON Pictor DS controller enables equipment switch-on by closing or opening the relay circuit. In most cases, the former option is used. To enable reverse relay operation, make changes in the advanced settings. Default setting – relay contacts are closed during operation of the heating/ air conditioning equipment.
  • Page 31 External temperature sensor Control Heating device, e.g. gas boiler Connections to electrical equipment – voltage control...
  • Page 32 Control Electric heating or air conditioning equipment (max. 230 V AC 16 A) NOTE: During installing AURATON Pictor DS, switch off the power supply. It is recommended to hire qualified service technician to install the controller. NOTE: Internal building electrical system shall be equipped with main switch and overcurrent protection.

  • Page 33: Cleaning And Maintenance

    Cleaning and maintenance The outside part the device should be cleaned with a dry cloth. Do not use solvents (such as benzene, thinner or alcohol). Do not touch the device when your hands are wet. It may cause electric shock or serious damage to the device.
  • Page 34 The user shall return it to a collection point for electrical and electronic waste. Contact and address of the manufacturer: LARS, ul. Świerkowa 14 64-320 Niepruszewo www.auraton.pl Download User manual Declaration of conformity...
