현대통신(주)
4. Technical Specification
4.1 Power Adaptor - ANY122A5C-NIH POWER
- This is a power supply for a lobby phone, HLPC-9006 series, and get AC110~240V free
Voltage input and outputs DC12V/2.5A voltage and supply DC12V to a lobby phone.
- It is an SMPS type and has an efficiency of more than 70% and built in a fuse to protect
the device in case of overvoltage input and also built in the overcurrent protection circuit
which down the output voltage when using overcurrent at the output stage.
- (Precaution) Appropriate SMPS shall be used per a site.
- (Precaution) The protected ground terminal shall be connected to the ground connection
permanently when you install a power.
HSA-0705-01-04(Φ)
년월일
문서번호:
2020. 11. 05.
Item
Power
Power Consumption
Signal
Size
Weight
Environment
Installation
Operation
Screen
Accessibility Signal
Camera
Angle of View
RFID Reading Distance
Microwave Reading Distance
A4(210×297 ㎜)
AA35MIxxxx
DC12V Adaptor
Adaptor Input:
AC 220V, 50/60Hz
Max 30W
TCP / IP
270W× 344.9H× 17D
1.76 Kg
Temp.
-20°C ~ 50°C
Humidity
20% ~ 70%
Flush mounting
13 KEY Touch Button
10.1" TFT LCD
Contact
Sensor
1/3" CMOS 520K
92°
3cm
5M
HYUNDAI TELECOM CO., LTD.
페이지
변경코드
4/12
REV.00
