- Page 1 EN GUIDE FOR INSTALLATION AND USE COOKING HOB COOKING GAS HOB - DPG7341BS -...
-
Page 3: Table Of Contents
Contents Using your hob in complete safety ........ page 4 Whats’your hob looks like ..........Installation your hob in all simplicity ....... ● Fitting recommendations ..............● Electrical connections ................. ● Connecting the gas supply ..............● Changing the type of gas (LPG) ............Using your hob in all simplicity ........... -
Page 4: Using Your Hob In Complete Safety
Your hob in complete safety IMPORTANT SAFETY INSTRUCTIONS - READ CAREFULLY AND RETAIN FOR FUTURE USE. This guide can be downloaded from the brand web site. o WARNING : this appliance may be used by children aged 8 years and older, and by persons with impaired physical sensorial or mental capacities, or without experience or knowledge, if they are supervised or have received priorinstructions on how to use the appliance safely and have understood... - Page 5 Your hob in complete safety o The use of a gas hob produces both heat and humidity in a room. Ensure that the kitchen is well ventilated: keep mechanical ventilators open. Prolonged, intensive use of the hob may require additional ventilation, by opening a window, for example, or ventilating the room more effi...
- Page 6 Your hob in complete safety o The conformity CE mark is applied to all these hobs. o This appliance should be installed by a qualifi ed technician / installer. o Never use aluminium foil for cooking. Never place products wrapped in aluminium foil or in aluminium trays on your hob.
-
Page 7: Whats'your Hob Looks Like
What your hob looks like ? DPG7341BS Extra-fast burner 3kW* Semi-fast burner 1,5kW* (*Powers in Hong Kong Town gas) Installing your hob in all simplicity Fitting recommendation Width Depth Height Standard cutout 26.5 cm 48 cm 5.1 cm Outside dimensions above... -
Page 8: Fitting Recommendations
Fitting recommendations (cont’d) The hob must be built into the worktop of a support cupboard. This worktop must be at least 3 cm thick and heat-resistant or else coated with a heat resistant material. Please check that there is provision for ventilation at the cabinet to ensure proper operation of the gas hob. - Page 9 Fitting recommendations (cont’d) - Place the hob in position in the cutout Fixing on the worktop, pulling it forward as far as Worktop lugs possible. - Put the bumers, caps and pan grates back in position. - Connect the hob power supply cable to the electrical installation of the kitchen.
-
Page 10: Electrical Connections
Electrical connections ROSS SECTION OF CABLE TO BE USED Your hob is delivered with a three- 220-240 V ~ - 50 HZ CROSS SECTION OF THE CABLE 3 conductors TO USE conductor (phase + ground + Câble H05V2V2F - T90 including 1 ground neutral) H05WF- T105 or H05V2V2F - T90 1mm2 section cable, which must be... -
Page 11: Connecting The Gas Supply
Connecting the gas supply Preliminary remarks ● Warning Your appliance is sold pre-set for TOWNGAS. If the hob is installed above an oven or if the proximity of other heat generating elements threatens to cause the connection to heat up, it is vital that the connection be made using a rigid pipe and the appliance should be properly mounted. - Page 12 Connecting the gas supply (cont’d) Gas rating ● Appliance designed for installation in Towngas Towngas HONG KONG - SINGAPORE Hourly input - see below at 15°C at HONG KONG SINGAPORE 10 mbar 10 mbar 1013 mbar EXTRA FAST BURNER Indicator marked on injector Nominal heat rating (kW) Low heat rating...
-
Page 13: Changing The Type Of Gas (Lpg)
Changing the type of gas SWITCHING FROM TOWN GAS TO LPG GAS Connecting the gas supply ● FOR HONG KONG LPG CONNECTION Gas supplied by tank or cylinder. For your safety, you must choose this connection : Connection with a reinforced rubber hose with screw-on mechanical connectors. - Page 14 Burner power DJUST THE RETARDER ON THE TAPS adjustment screw • Using a small fl at-head screwdriver, screw in the brass burner-power screws (yellow) all the way, (fi g. 1) screwing them in a clockwise direction. • Replace the gaskets and the knobs, paying careful attention to their direction and ensuring that the knobs are pushed in all the way.
-
Page 15: Using Your Hob In All Simplicity
Using your hob in all simplicity How to use your gas burner • To ignite a burner, press down and turn the knob anti-clockwise .until it is ● L IGHTING A HOB FITTED WITH A SAFETY pointing to the maximum position DEVICE •... -
Page 16: Pans To Use
Which pans are best adapted for use on the gas burner ? ● Recommended pan sizes : Extra burner Small burner Extra-fast Auxiliary 18-28 cm 12-16 cm Adjust the fl ames so that they do not lick up the side of your pan. -
Page 17: How To Look After Your Hob
How to look after your hob? Keeping your hob in good condition is easy if you clean it before it is completely cold. Even so, never clean it when it is in use. Put all the electric and gas control knobs at zero. -
Page 18: Minor Troubleshooting
Minor troubleshooting You have doubts about whether your hob is working correctly. This does not necessarily mean there is a breakdown. Nevertheless, check the following points. IF YOU REALIZE THAT WHAT SHOULD YOU DO Lighting the burners: - Check the electrical connections on the hob. - Check that the sparkers are clean. -
Page 19: Gas Cooking Guide
Gas-cooking guide DISHES TIME EXTRA- SEMI-FAST FAST Broths 8-10 minutes SOUPS thick soups Court-bouillon 8-10 minutes FISH Grilled 8-10 minutes Hollandaise, béarnaise SAUCES Béchamel, aurore 10 minutes Endives, spinachs VEGETABLES Peas in sauce 25-30 minutes Provence tomaotes 15-20 minutes Fried potatoes Pasta Steak MEAT... -
Page 20: After Sales Service
After Sales Service Any maintenance on your equipment should be undertaken by: - either your dealer, - or another qualifi ed mechanic who is an authorised agent for the brand appliances. When making an appointment, state the full reference of your equipment (model, ty pe and serial number).
