Summary of Contents for DeDietrich DPG7388B
- Page 1 EN GUIDE FOR INSTALLATION AND USE COOKING HOB COOKING GAS HOB - DPG7388B -...
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS ..............3 1 / DESCRIPTION OF YOUR APPLIANCE .........8 2 / INSTALLING YOUR APPLIANCE • Choice of location ................9 • Fitting ...................9 • Fitting tips ...................10 • Case of fl ush fi tting above a drawer, of a cabinet with a door or drawer ..................10 •... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS – READ CAREFULLY AND RETAIN FOR FUTURE USE. This guide can be downloaded from the brand web site. • WARNING : this appliance may be used by children aged 8 years and older, and by persons with impaired physical sensorial or mental capacities, or without experience or knowledge, if they are supervised or have received prior instructions on how to use the appliance safely and have understood the risks... - Page 5 SAFETY INSTRUCTIONS • Prior to installation, ensure that the local distribution conditions (type of gas and gas pressure) and the appliance’s settings are compatible. • The conditions for setting this appliance are described on the rating plate or on label stuck on the appliance. •...
- Page 6 SAFETY INSTRUCTIONS - shut immediately off all burners and any electrical heating element and isolate the appliance from the power supply. - do not touch the appliance surface, - do not use the appliance. •WARNING: If a crack appears in the surface of the glass, disconnect your appliance from the power supply to avoid electric shock.
- Page 7 SAFETY INSTRUCTIONS • This appliance should be installed by a qualifi ed technician / installer. • If a knob is diffi cult to turn, call your installer immediately. • This hob complies with standard EN 60335-2-6, as it applies to heat build-up in class 3 appliances and the implications for their installation (in compliance with standard EN 30-1-1).
-
Page 8: Description Of Your Appliance
• DESCRIPTION OF YOUR APPLIANCE •DESCRIPTION OF YOUR HOB Model: High power hob with knobs Pan support Burner cover Spark igniter Gasket Burner head Thermocouple Injector Knob This Guide to Installation and Use is valid for several models. There may be minor differences in details or fi... -
Page 9: Installing Your Appliance
• INSTALLING YOUR APPLIANCE APPLIANCE Width Depth Thickness Standard depending 27 cm 49 cm cabinet cut-out on cabinet Total dimension above the work 5 cm 30 cm 51,5 cm surface Total dimension below the work 5,1 cm 26,3 cm 48 cm surface Fig. -
Page 10: Fitting Tips
• INSTALLING YOUR APPLIANCE • FITTING TIPS Underside view of the housing — If you wish, you can immobilise the hobusing the four mounting brackets delivered with their screws, fi xed to the four corners of the casing. You must use the holes provided for this purpose, according to the diagram above (Fig. -
Page 11: Electric Connection
• INSTALLING YOUR APPLIANCE •ELECTRIC CONNECTION Your hob is supplied with a power cable (type H05VVF cross-section 1 mm2) with 3 conductors (including 1 ground: Cross-section of cable to be used green/yellow). These conductors must be connected to the grid via a standardised 220-240 V ˜... -
Page 12: Gas Connection
• INSTALLING YOUR APPLIANCE •GAS CONNECTION PRELIMINARY REMARKS Warning Your appliance is sold pre-set for TOWNGAS. If the hob is installed above an oven or if the proximity of other heat generating elements threatens to cause the connection to heat up, it is vital that the connection be made using a rigid pipe and the appliance should be properly mounted. -
Page 13: Markings On The Injectors
• INSTALLING YOUR APPLIANCE Markings on the injectors Example : The table below shows where the injector reference 205B 205B injectors are positioned on your appliance according to the type of gas used. Each number is marked on the injector. Town Gas 205B 115B... -
Page 14: Changing The Type Of Gas
• INSTALLING YOUR APPLIANCE •CHANGING THE TYPE OF GAS SWITCHING FROM TOWN GAS TO LPG GAS Connecting the gas supply LPG connection - gas supplied by tank or cylinder. Warning Your appliance is sold pre-set for TOWNGAS. The injectors required for adapting it to LPG can be found in the Seal (not provided) plastic bag containing this guide. - Page 15 • INSTALLING YOUR APPLIANCE Apply the spanner to the injector. Change the injectors, proceeding as follows: Turn the spanner clockwise. — Remove the an support, the burner cover, and the burner head. Warning — Using a No.10 spanner, unscrew the Screw on the adaptor with a torque central injector located at the base of not exceeding 4 N.m.
-
Page 16: Markings On The Injectors
• INSTALLING YOUR APPLIANCE Adjust the retarder on the taps Burner power adjustment screw — Using a small fl at-head screwdriver, screw in the brass burner-power screws (yellow) all the way, (fi g. 1) screwing them in a clockwise direction. —... -
Page 17: Using Your Appliance
• USING YOUR APPLIANCE Model 1 burner with control knobs DPG7388B High-power burner 4.1kW (*) (*) Power obtained with Town gas... - Page 18 • USING YOUR APPLIANCE • SWITCHING ON THE GAS BURNERS Each burner is supplied by a tap which can be opened by pressing it and turning it in in a counterclockwise motion. The point “O” corresponds to a closed tap. —...
-
Page 19: Cookware To Be Used With Gas Burners
• USING YOUR APPLIANCE • COOKWARE TO BE USED WITH GAS BURNERS • Which burner should you use depending on your cookware? Burner high-power fl ame External ring Central burner 20 to 30 cm 20 to 30 cm 8 to 14 cm Frying, Boiling Gentle simmer —... -
Page 20: Daily Care Of Your Appliance
• DAILY CARE OF YOUR APPLIANCE •MAINTAINING YOUR APPLIANCE PRODUCTS/ACCESSORIES MAINTENANCE WHAT TO DO TO BE USED En cas d’encrassement des bougies In the event that the spark plugs become soiled, clean them using a small, hard-bristled brush (non- metallic). - Small, hard-bristled brush. -
Page 21: Special Messages, Incidents
• SPECIAL MESSAGES, INCIDENTS • DURING USE YOU OBSERVE THAT: WHAT SHOULD YOU DO ? - Check the electrical connection of your appliance - Check that the spark plugs are clean. • Lighting of burners: - Check that the burners are clean and properly assembled There are no sparks when - If the hob is attached to the work surface, check that the you press the knobs.. -
Page 22: Some Tips
• SOME TIPS . Hold the knob completely pressed down for a few seconds after the fl ame appears to trigger the safety Lighting with gas safety system. feature . If there is a power failure, the burner may be lit by bringing a match to the burner and at the same time pressing the corresponding knob Always use stable cookware, that has a flat bottom and does... -
Page 23: Environment
• ENVIRONMENT CARING FOR THE ENVIRONMENT This appliance’s packing materials are recyclable. Recycle them and help to protect the environment by disposing of them in the council receptacles provided for this purpose.Your appliance also contains various recyclable materials. It is therefore marked with this logo to indicate that, in European Union... -
Page 24: After Sales Service
• AFTER SALES SERVICE Any maintenance on your equipment should be undertaken by: - either your dealer, - or another qualifi ed mechanic who is an authorised agent for the brand appliances. When making an appointment, state the full reference of your equipment (model, ty pe and serial number).
