Project Source B12R Assembly Instruction Manual page 8

ASSEMBLY INSTRUCTIONS
7. Place the bumper pad on the drawer front as shown.
Hardware Used
KK Bumper 2MM
8. Using a phillips head screwdriver, secure the
drawer box with csk screws 1 ½" as shown in the
illustration. Be careful not to over-tighten as this
may damage the product.
Hardware Used
II CSK screw 1 1/2"
9. Using a phillips head screwdriver, secure the epoxy
bottom runner to the underside of the drawer
box with the csk screws 5/8" as shown in the
illustration. Be careful not to over-tighten as this
may damage the product.
Hardware Used
CSK screw 5/8"
HH
7
x 2
8
x 8
9
x 6
8
KK
II
HH
