ASSEMBLY INSTRUCTIONS
4. Place the epoxy runner in the correct position as
per the illustration. Use the euro and csk screws
as shown. Ensure the left & right hardware slides
are placed on the correct panels.
Hardware Used
CC
Epoxy runner
LL Euro screw 1/2"
HH CSK screw 5/8"
5. Using a phillips head screwdriver, attach the
mounting plate as shown in the illustration.
Hardware Used
FF Hinge mounting plate
6. Insert the hinge in the bore hole. Using a phillips
head screwdriver, turn the pre-installed screws
clockwise to lock into place.
Place the bumper on the door as shown.
Hardware Used
GG 105 o Hinge
KK Bumper 2MM
