  • Page 1 Multi-Functional Video Center User Manual...
  • Page 2 Document, which may include licenses obtained from third parties. ● Any part of the Document, including text, pictures, graphics, etc., belongs to Hikvision. No part of this Document may be excerpted, copied, translated, or modified in whole or in part by any means without written permission.
  • Page 3 ● YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS;...
  • Page 4 Multi-Functional Video Center • User Manual Preface Applicable Models This manual is applicable to the DS-B30 series multi-functional video center. Default Parameters Type Default Parameter  Device Login user name: admin  IP address: 192.0.0.64 SSH connection To improve system security, it is highly recommended to change password regularly. In order to protect your privacy and corporate data and avoid network security issues, it is recommended to set strong password that meets security requirements.
  • Page 5 Multi-Functional Video Center • User Manual Safety Instructions In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region.  Provide a surge suppressor at the inlet opening of the device under special conditions such as the mountain top, iron tower, and forest.

  • Page 6: Table Of Contents

    Multi-Functional Video Center • User Manual TABLE OF CONTENTS Chapter 1 Introduction ....................... 1 Overview ................................1 First-Time Configuration Process .......................... 2 Chapter 2 Device Activation ....................... 3 Activate the Device via SADP Client ........................3 Activate the Device via Web Browser ........................4 Chapter 3 Device Configuration ....................

  • Page 7: Chapter 1 Introduction

    Multi-Functional Video Center • User Manual Chapter 1 Introduction Overview Designed with reference to the Advanced Telecommunications Computing Architecture (ATCA), the Multi-Functional Video Center (hereinafter referred to as the MVC or the device) supports matrix switching of analog and digital videos, video encoding and decoding, and network real-time preview.

  • Page 8: First-Time Configuration Process

    Multi-Functional Video Center • User Manual First-Time Configuration Process Activate the device Log in to the device Set the device network address Set the video wall scale Bind outputs with video walls Bind signal sources with video walls Operate video walls (Optional) Configure (Optional) Configure (Optional) Maintain the...

  • Page 9: Chapter 2 Device Activation

    Connect the device and the computer to the same LAN. Visit https://www.hikvision.com/en/support/tools/hitools/clea8b3e4ea7da90a9/ download the SADP client from the Hikvision website and install the SADP client on the computer. Open the SADP client. Select the device that is not activated, enter the activation password and confirm it, and click Activate.

  • Page 10: Activate The Device Via Web Browser

    Multi-Functional Video Center • User Manual Activate the Device via Web Browser Use a network cable to connect a computer to the device. Set an IP address for the computer. To ensure the normal communication between the computer and device, the IP address of the computer should be in the range of 192.0.0.2 to 192.0.0.253 (excluding 192.0.0.64).

  • Page 11: Configure The Network Address

    Multi-Functional Video Center • User Manual Login Page Click Log In. Configure the Network Address Go to Configuration → Network → Network Configuration → TCP/IP. Configure the Device IPv4 Address Select the NIC type. Set the IPv4 address, IPv4 subnet mask, and IPv4 gateway. If you use the domain name to access the device, set the preferred and alternative DNS server.

  • Page 12: Configure Nat

    Multi-Functional Video Center • User Manual Remove the network cable that connects the device and computer, and use the network cable to connect the device to the same network as the computer. Make sure the computer and device are in the same network segment. Enter the configured device IP address in the web browser of the computer to log in to the web page of the device.

  • Page 13: Configure A Video Wall

    Multi-Functional Video Center • User Manual Click Save. Configure a Video Wall Go to Video Wall Configuration, select a video wall in the upper left corner and click Configure. Video Wall Configuration Page According to the actual screen type and quantity, select the video wall type, set the video wall scale, select the decoding output resolution, and click Save.

  • Page 14: Bind Output Ports With Video Wall

    Multi-Functional Video Center • User Manual After setting the video wall scale, you can click Edit Video Wall Scale to change the video wall scale. Edit the Video Wall Scale A video wall can contain one screen or multiple screens. At a time, one screen can join only one video wall, and one output port can be bound with only one screen.
  • Page 15 Multi-Functional Video Center • User Manual  Customize the name.  Set the output mode of the device according to the actual connection between the device and the screen. You can select HDMI or DVI. The DVI mode has better compatibility and the HDMI mode supports embedded audio output.

  • Page 16: Configure Audio

    Multi-Functional Video Center • User Manual  Click Unlink All Output Ports at the top of the Video Wall Configuration page, then click OK on the pop-up window.  Click Display Output No. at the top of the Video Wall Configuration page to display the output port number on the screen.
  • Page 17 Multi-Functional Video Center • User Manual Edit Audio Channel Table  Click Unlink All to unlink all audio linkage. Click Save. Link to Audio On the Video Wall Configuration page, click Audio Configuration and select Link to Audio. Link to Audio Click at the upper right corner of an output audio to set it as the output audio of the video wall.

  • Page 18: Add A Network Signal Source

    Multi-Functional Video Center • User Manual Set Output Audio  After setting the output audio of the video wall, you need to go to the Video Wall Operation page to enable audio. Thus, the audio output is allowed.  One video wall can be linked with only one output audio. Add a Network Signal Source via IP Address Go to Video Wall Operation →...
  • Page 19 Multi-Functional Video Center • User Manual Add a Network Signal Source via IP Address Click Save. Add a Network Signal Source via DDNS Go to Video Wall Operation → Signal Source, click , and select DDNS. Before adding network signal sources via DDNS, you should configure DNS servers on the TCP/IP page.
  • Page 20 Multi-Functional Video Center • User Manual − If you want to add a Network Video Recorder (NVR), the number of channels should start from 33. The first 32 channels are reserved. For example, if you want to add a 32-channel NVR, the number of channels should be 64. ...

  • Page 21: Bind Signal Sources With Video Wall

    − rtsp://stream media IP address:554/network camera IP address: port number:HIKDS8000HC: channel number: main steam: username: password/av_stream?linkmode=tcp?smversion=2 − rtsp://stream media IP address:554/hikvision://network camera IP address: port number: channel number: main stream?username=user name?password=password?linkmode=tcp?smversion=4 − rtsp://network camera IP address:554/ch01/main/av_stream − rtsp://username: username password@front-end device IP address:554/ch01 ...

  • Page 22: Operate A Video Wall

    Multi-Functional Video Center • User Manual Drag Signal Sources to Video Wall  Drag a signal source folder to the video wall to batch bind multiple signal sources with the video wall. Drag a Signal Source Folder to Video Wall Operate a Video Wall Go to Video Wall Operation and perform the following operations as required: ...
  • Page 23 Multi-Functional Video Center • User Manual − Select a signal source window, and enter the specific X and Y values in the pop-up window. Adjust Position of a Signal Source Window  Divide a signal source window: Select a signal source window, and click the window division icon.
  • Page 24 Multi-Functional Video Center • User Manual Configure Audio for Local Signal Source − Select a network signal source to configure the decoding status, audio status, decoding delay, and smart decoding. With smart decoding enabled, the device can decode the network camera information. Configure Audio for Network Signal Source ...
  • Page 25 Multi-Functional Video Center • User Manual Set Auto-Switch  Click at the upper right corner of a signal source window to preview the signal source. Click to cancel the live view. Preview Signal Source  Click Clear Window at the top of the Video Wall Operation page to clear all bound signal source windows.

  • Page 26: Configure Subtitles

    Multi-Functional Video Center • User Manual Live View Go to Video Wall Operation, click Subtitle, press and hold the left mouse button to drag subtitles to screens bound with output ports. Add a Subtitle To add multiple subtitles, you can drag the remaining subtitles.
  • Page 27 Multi-Functional Video Center • User Manual Configure a Text Subtitle Select Text for the subtitle type and enter the subtitle content. Adjust the subtitle position and size. Adjust the font size, font color, font direction, alignment, background color, and background transparency.

  • Page 28: Manage Scenes

    Multi-Functional Video Center • User Manual Configure a Time Subtitle Up to 128 scenes are supported. Go to Video Wall Operation to manage scenes.  Click Save Scene to save the current video wall configuration as a new scene or overwrite the existing scene.

  • Page 29: Manage Plans

    Multi-Functional Video Center • User Manual  Click Scene and hover over a scene name. Click to delete the scene. Manage Scene You can add multiple scenes and set the scene schedule in a plan. Go to Video Wall Operation and click Plan to manage plans.
  • Page 30 Multi-Functional Video Center • User Manual Add a Plan  Click a plan and then click to edit the plan.  Click a plan and then click to call the plan. Call a Plan  Click a plan and then click to delete the plan.
  • Page 31 Multi-Functional Video Center • User Manual Configure Serial Port The serial port also supports the keyboard control working mode. If you need to use the serial port for keyboard control, select Keyboard Control as the working mode, and set the baud rate of the device same as the baud rate of the keyboard.
  • Page 32 Multi-Functional Video Center • User Manual Screen Maintenance Page Select an input source type. Select an image mode and adjust the backlight. Adjust the image position. (Optional) You can perform the following operations as required:  Click to power on the screen or click to power off the screen.

  • Page 33: Maintain Screens

    Multi-Functional Video Center • User Manual Maintain Screens Configure Screen Display Effect Go to Video Wall Operation, hover over a local signal source and then click to configure the following parameters.
  • Page 34 Multi-Functional Video Center • User Manual Configure Signal Source Parameters  On the Signal Source Name page, edit the signal source name.  Click Video Param, select a color mode and adjust the brightness. Set Video Parameters  Click Source Clipping, set the clipping value at top, bottom, left, and right edges.
  • Page 35 Multi-Functional Video Center • User Manual Clip a Signal Source The clipping value ranges from 0 to 200. The clipping value at the top and bottom edges should be a multiple of 2, and the clipping value at the left and right edges should be a multiple of 4. ...
  • Page 36 Multi-Functional Video Center • User Manual  You can add multiple OSDs (On-Screen Displays) to the input signal image. 1) Click OSD. 2) Overlay the date and time to the input signal image. Select the format and adjust the OSD position. You can directly drag the OSD to adjust its position. 3) Overlay the text to the input signal image.

  • Page 37: Splice Signal Source

    Multi-Functional Video Center • User Manual 3) Enter an I-frame interval. The larger the I-frame interval, the smaller the stream fluctuation, and the lower the image quality. 4) Select a resolution. The higher resolution, the higher the bandwidth requirement. 5) Select a frame rate. 6) Select a video encoding type and video type.

  • Page 38: Set Other Parameters

    Multi-Functional Video Center • User Manual  Only UHD signal sources support splicing.  All spliced signal sources should use the same resolution and frame rate to avoid affecting the display effect.  The joint signal source will be displayed in one signal source window on the video wall. ...
  • Page 39 Multi-Functional Video Center • User Manual to get the images. In low bandwidth networks, you can use sub-stream to get relatively smooth images with a small bandwidth footprint. Set Sub-Stream Auto-Switch  Click Display Settings to configure the content displayed when streaming fails and when the decoding resource is insufficient.

  • Page 40: Configure The Device

    Multi-Functional Video Center • User Manual  Click Decoding Delay and select a default decoding delay level. Set Decoding Delay Configure the Device Go to Configuration → System to configure the following parameters:  Go to System Settings → Basic Information to view the device information and edit the device name as required.
  • Page 41 Multi-Functional Video Center • User Manual − Set the address and port number of the NTP server. − Set the synchronization interval. Select NTP Sync  On the Time Settings page, if you select Manual Time Sync, you can click Sync with Computer to make the device time same as the computer time.
  • Page 42 Multi-Functional Video Center • User Manual  Go to System Settings → Font Settings to set the font of OSDs and subtitles. You can use the default font, or click Add to import a new font. Set Font  Go to User Management → User Management to add users, edit the user name or password, or delete the users.

  • Page 43: Configure Http(S) Parameters

    Multi-Functional Video Center • User Manual Configure HTTP (S) Parameters Go to Configuration → Event to configure the audible warning and alarm reporting to the platform when the following exceptional events occur:  The IP address of the device is the same as that of other devices in the network. ...

  • Page 44: Maintain The System

    Multi-Functional Video Center • User Manual Maintain the System Go to Maintenance and Security → System Maintenance to configure the following parameters:  Click Restart to restart the device.  Click to select an upgrade file, and click Upgrade. You need to get the upgrade file in advance and save it locally.
  • Page 45 Multi-Functional Video Center • User Manual Backup and Reset Device Parameters  Search logs: Click Log to set the search condition and click Search. You can view the searched logs in the list below. You can click Export CSV File to export the found logs. Search Logs ...
  • Page 46 Multi-Functional Video Center • User Manual Enable SSH − Format the USB flash drive before inserting into the device. Only the USB flash drives in FAT32 format are supported. Insert a USB flash drive into the device, and click Start Exporting to export the logs to the USB flash drive.

  • Page 47: Maintain The Device Security

    Multi-Functional Video Center • User Manual Send Shell Command Maintain the Device Security Go to Maintenance and Security → Security Management to configure the following parameters:  On the IP Address Filter page, configure the IP addresses that are allowed to or forbidden to access the device.

  • Page 48: View Device Status

    Multi-Functional Video Center • User Manual Import HTTPS Certificate and Secret Key  Click SADP, and then enable SADP as required. With SADP enabled, you can use the SADP software to search the device when it is in the same network segment with the computer. ...
  • Page 49 Multi-Functional Video Center • User Manual View Device Status...
