- Page 1 Assembly Instructions max. 150 kg ~ 45 Min. 38 kg L 153 | W 92 | H 92 FSTFB850PRO.01.01 Art. No. TF-B850-PRO Backtrainer B850 Pro...
- Page 2 B850 PRO...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly STORAGE AND TRANSPORT General Instructions TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Maintenance and Inspection Calendar DISPOSAL RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing... - Page 4 B850 PRO...
- Page 5 European VAT Number: DE813211547 Disclaimer © TAURUS is a registered brand of the company Fitshop GmbH. All rights reserved. Any use of this trademark without the explicit written permission of Fitshop is prohibited. Product and manual are subject to change. Technical data can be changed without advance notice.
- Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and fi rst use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
- Page 7 Please pay close attention to the safety and maintenance instructions given here. The contract partner cannot be held liable for damage to health, accidents or damage to the equipment when it is not used in accordance with these instructions. The following safety instructions may appear in this manual: ATTENTION This notice indicates potentially hazardous situations which, if not avoided, may result in property damage.
-
Page 8: General Information
GENERAL INFORMATION Technical Data Weight and Dimensions Article weight (gross, incl. packaging): 39 kg Article weight (net, without packaging): 38 kg Packaging dimensions (L x W x H) approx.: 116 cm x 87 cm x 19 cm Set-up dimensions (L x W x H) approx.: 153 cm x 92 cm x 92 cm Maximum user weight: 150 kg... -
Page 9: Personal Safety
Personal Safety ⚠ DANGER Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly aff ected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 10: Set-Up Place
Set-Up Place ⚠ WARNING Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 11: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suff ocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. -
Page 12: Scope Of Delivery
Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. ⚠... - Page 13 BEND SUPPORT Bend support CUSHION SUPPORT Cushion support LEG SUPPORT Leg support REINFORCEMENT Reinforcement plate PLATE IRON BUSHING Iron bushing BIG SHEATHING Big sheating CUSHION Cushion FOAM ROLLER Foam roller...
- Page 14 FAST PIN Fast pin M8*25 SOCKET M8*25 Socket screw SCREW M8*25 SOCKET CAP M8*25 Socket cap SCREW screw M10*20 SOCKET CAP M10*20 Socket cap SCREW screw M10*75 SOCKET CAP M10*75 Socket cap SCREW screw M10*85 SOCKET CAP M10*85 Socket cap SCREW screw M10*105 SOCKET CAP...
-
Page 15: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fi t properly. Tighten the screws using the tool only when you are instructed to do so. - Page 16 Step 2: Assembly of the Cushion Support and Bend Support Mount the cushion support (8) to the main frame (1) with one iron bushing (11), two screws (28) and two washers (33). Mount the bend support (7) to the cushion support (8) with two screws (30), four washers (33) and two lock nuts (34).
- Page 17 Step 3: Assembly of the Cushions Mount the cushions (14) to the cushion support (8) with a total of four screws (27) and four washers (32). Mount the leg support (9) to the up tube (6) with two screws (29), four washers (33) and two lock nuts (34).
-
Page 18: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ATTENTION Make sure that the equipment is protected from moisture, dust and dirt in the selected storage location. -
Page 19: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specifi ed intervals: Part Weekly Monthly Screw connections Cushions Legend: C = clean;... -
Page 20: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more effi cient and pleasant, we recommend that you add suiting accessories to your fi tness equipment. This could be a fl oor mat, for example, which makes your fi tness equipment stand more securely and also protects the fl oor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape. -
Page 21: Ordering Spare Parts
The serial number of your equipment is unique. It's located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate fi eld. Serial number: Brand / Category: Taurus / back trainer Model Name: B850 Pro Article Number: TF-B850-PRO... -
Page 22: Parts List
Parts List Name Qty. MAIN FRAME BEND BASE FLATE BASE DOWN TUBE MIDDLE TUBE UP TUBE BEND SUPPORT CUSHION SUPPORT LEG SUPPORT REINFORCEMENT PLATE IRON BUSHING SHEATHING BIG SHEATHING CUSHION FOAM ROLLER FOAM COVER ROUND PLUG-25 ROUND PLUG-50 SQUARE PLUG-50 SQUARE PLUG-60 RECTANGULAR PLUG BUSHING... -
Page 23: Exploded Drawing
8MM WASHER 10MM WASHER M10 LOCK NUT FAST PIN Exploded Drawing... -
Page 24: Warranty
WARRANTY Products from TAURUS® are subject to strict quality control. However, if a fi tness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 25 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
-
Page 26: Contact
CONTACT TECHNIK TEKNIK OG SERVICE CUSTOMER SUPPORT �� �� �� +49 4621 4210-900 80 90 16 50 00800 2020 2772 +494621 4210 944 +49 4621 4210-945 �� +49 4621 4210-698 �� �� info@fi tshop.dk info@fi tshop.co.uk �� technik@fi tshop.de �� ��... - Page 27 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Fitshop is Europe’s largest specialist store for www.fi tshop.co.uk home fi tness equipment with currently over 70 www.fi tshop.de/blog stores and one of the world’s most renowned online mail order companies for fi tness equipment.
- Page 28 Notes B850 PRO...
- Page 29 Notes...
- Page 30 Notes B850 PRO...
- Page 32 Backtrainer B850 Pro...
