Summary of Contents for Taurus B450
- Page 1 Assembly Instructions max. 200 kg ~ 30 Min. 20 kg L 130 | W 59 | H 43 TFB450.02.01 Art. No. TF-B450-2 Multi Position Bench B450...
- Page 2 B450...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly STORAGE AND TRANSPORT General Instructions Transportation Wheels TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Maintenance and Inspection Calendar DISPOSAL RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List... - Page 4 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
- Page 5 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
-
Page 6: General Information
Weight (net, without packaging) approx.: 20 kg Maximum total load: 200 kg (user + weights) Cushion dimensions: Seat cushion: L 32 cm | W 29 cm | H 5 cm Back cushion: L 80 cm | W 29 cm | H 5 cm B450... -
Page 7: Personal Safety
Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 8: Set-Up Place
(over 70%) like swimming pools. A floor protective mat/equipment underlay can help to protect high-quality floor coverings (parquet, laminate, cork, carpets) from dents and sweat and can help to level out slight unevenness. B450... -
Page 9: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. -
Page 10: Scope Of Delivery
In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠ If parts of the scope of delivery are missing or damaged, the assembly must not be carried out. B450... - Page 11 Hardware...
-
Page 12: Assembly
Step 1: Connection of Main Frame to Rear Base Assemble the main frame (1) to the rear base (2) by using two bolts (31) one splint (13), four washers (36) and two lock nuts (40). B450... - Page 13 Step 2: Assembly of Seat Supports, Backrest Supports, Front Support und Rear Support Attach the seat supports (3&4) with axis (9) to the main frame (1). Assemble both backrest supports (7) to the seat supports (3&4) by using one bolt (29) and one big washer (37) on each side.
- Page 14 Assembly of Seat Cushion and Back Cushion Assemble the seat cushion (14) to the seat supports (3&4) with four bolts (28) and four washers (35). Assemble the back cushion (15) to both backrest supports (7) with six bolts (28) and six washers (35) in total. B450...
-
Page 15: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑... -
Page 16: Troubleshooting, Care And Maintenance
Please refer to the following overview for the most common errors and how to correct them. If the equipment still does not function properly, contact your contract partner. Fault Cause Solution Squeaking & cracking Screw connections loosened Check screw connections noises or too tight B450... -
Page 17: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Quarterly Screw connections Cushions Legend: C = clean;... -
Page 18: Recommended Accessories
Of course, you can also contact our customer service: by telephone, e-mail, in one of our branches or via our social media channels. We will be happy to advise you! chest strap floor mat chest strap contact gel silicone spray towels B450... -
Page 19: Ordering Spare Parts
The serial number of your equipment is unique. It's located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / weight bench Model Name: Multi Position Bench B450 Article Number: TF-B450-2... -
Page 20: Parts List
Nylon Tube Ø20*75 Nylon Tube Ø20*93 Splint Seat Cushion Back Cushion Handle Oval Pad Round Pad Round Plug Logo Pad Handle Cap Rectangle Plug Wheel Bushing Angle Stickers "Hexagon Socket Bolt M8*16" Bolt M8*45 Bolt M8*65 Bolt M10*16 Bolt M10*35 B450... - Page 21 Bolt M10*70 Bolt M10*150 Bolt M12*95 Bolt M12*115 Washer 8 Washer 10 Big Washer 10 Washer 12 Lock Nut M8 Lock Nut M10 Lock Nut M12...
-
Page 22: Exploded Drawing
Exploded Drawing EXPLODED DIAGRAM B450... -
Page 23: Warranty
WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 24 For that reason, we also want to resolve your queries quickly and in a straightforward manner. Thus, please always keep your customer number and the serial number of the faulty equipment handy. B450...
-
Page 25: Contact
CONTACT TECHNICAL SUPPORT TECHNICAL SUPPORT & SERVICE TECHNICAL SUPPORT & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 172 770033 +49 4621 4210-945 +49 4621 4210-933 �� +49 4621 4210-698 �� �� info@fitshop.dk service-france@fitshop.fr �� technik@sport-tiedje.de ��... - Page 26 The company employs numerous sports scientists, fitness trainers and competitive athletes. Visit us also on our social media platforms or our blog! B450...
- Page 28 Multi Position Bench B450...
