- Page 1 XSF series PLC User manual【Hardware】 Wuxi Xinje Electric Co., Ltd. Data No. PF 01 20230801 1.0...
- Page 2 Thank you for purchasing the XINJE XSF series programmable controller. This manual mainly introduces the hardware features of XSF series programmable controllers. Before using the product, please read this manual carefully and conduct wiring on the premise of fully ...
- Page 3 Safety precautions Before using this product, please read this part carefully and operate after fully understanding the use, safety, precautions, etc. of the product. Please correctly conduct product wiring under the premise of paying great attention to safety. The problems that may arise during the use of the product are basically included in the safety precautions, which are indicated in two levels of attention and danger.
- Page 4 2. Do not directly touch the conductive part of the product. It may cause malfunction and fault. 3. Please use DIN46277 guide rail, M3 screw or Xinje XG-EB to fix the product and install it on a flat surface. Incorrect installation may cause malfunction and product damage.
- Page 5 cover. May cause malfunction, fault, etc. 5. When using wires to connect terminals, be sure to tighten them, and do not make conductive parts contact other wires or terminals. It may cause malfunction and product damage. Operation and maintenance of products Danger 1.
- Page 6 This manual is convenient for users to understand and use the necessary precautions, specifications, functions, and other contents of XSF-CPU units. Before use, one should thoroughly read this manual and related manuals, and correctly use this product based on a thorough understanding of the functions/performance of the XSF series programmable controller.
-
Page 7: Table Of Contents
Catalog SAFETY PRECAUTIONS ............... II 1. DOCUMENT GUIDE ..............1 1-1. R ................................1 ELATED MANUAL 1-2. R ......................... 1 EADING METHOD OF THE MANUAL 2. TERMINOLOGY ................. 2 3. PRODUCT SYSTEM CONFIGURATION ............. 3 3-1. O ............................3 VERALL CONFIGURATION 3-2. -
Page 8: Document Guide
Manual name Main content It mainly records the hardware specifications and hardware XSF series hardware user manual maintenance information of XSF series CPU units. XS series PLCopen controller instruction It mainly records XS series instruction section. manual (XS Studio) I/O unit... -
Page 9: Terminology
In this manual, unless otherwise specified, the following terms will be used for explanation. Terminology Instructions CPU unit General term for XF/XSF series CPU units Power module unit General term for XF series power modules Protection level according to DIN 40050: protection against finger contact and intrusion... -
Page 10: Product System Configuration
3. Product System Configuration In this chapter, the overall configuration, precautions during configuration, and peripheral device related content are explained. 3-1. Overall configuration 3-2. Major event Different CPU units are used, and the corresponding expandable IO units are also different. ... -
Page 11: Installation&Wiring
4. Installation&Wiring 4-1. CPU installation method (1) Installation requirements The host is installed using DIN rails, which must comply with the IEC 60715 standard (35mm wide and 1mm thick). The size information is shown in the following figure, in millimeters (mm). When installing this product on non recommended DIN rails (especially when the thickness of the DIN rail is not 1.0mm), it Attention... -
Page 12: Network Cable Installation Method
4-2. Network cable installation method (1) Network cable requirements To improve the reliability of device communication, the Ethernet cable must be shielded twisted pair cables with iron injection molding wires. Connection: Hold the RJ45 connector with the cable and insert it into the Ethernet port (RJ45 port) until the sound clicks. - Page 13 (2) Battery replacement procedure 1. Please complete the following steps before replacing: Record RTC data. Set the power supply of the CPU module to ON for 10 minutes or more. 2. Open the side cover of the CPU unit (battery box) 3.
-
Page 14: Naming Convention
5. Naming convention CPU unit XF series Series Name ① XSF: XSF series Basic type Ethernet type Serial number Entry level motion control type ② Motion control type Advanced motion control type 4 channels 8 channels Input channel ③ 16 channels... -
Page 15: Names Of Each Part
6. Names of each part XSF5-A32 & XSF5-A64 Number Name Purpose Extended Connection Used for connecting to XF-IO units. On: With power input PWR(green) Off: No power input On: User program running RUN(green) Off: User program stopping On: System critical error ERR(red) Off: System normal On: SD card pending access status... - Page 16 (11) 1 channel isolated CAN port (reserved) (12) 1 channel isolated 485 port (13) Power module connection port Connect and use with the XF power module. The effective time of RTC can be increased by adding standard (14) Battery holder CR2032 batteries.
-
Page 17: Cpu Unit Specifications
7. CPU unit specifications 7-1. General specifications General specifications Project Content Max temperature 55℃ Operating temperature Min temperature -20℃ Transportation/storage Max temperature 70℃ temperature Min temperature -40℃ Upper limit Environmental humidity (including operation/storage) lower limit Protection grade IP20 Accord with IEC61131-2 Under intermittent vibration (frequency 5-9Hz, constant amplitude 3.5mm peak displacement) and (frequency 9-150Hz, constant acceleration 1.0g peak acceleration) - Page 18 monitoring on PLC USB drive connection, download program (supported in Q3 of 2023) Internal I/O function in the body None Extension quantity Power outage hold Non battery retention type Super capacitors ensure RTC availability for at least 14 days Clock Hold Optional CR2032 battery module for RTC clock only Year, month, day, hour, minute, second, week (automatically Clock...
-
Page 19: Functional Specifications
3. EtherNet/IP Explicit, EtherNet/IP Implicit Implicit (I/O) message communication supports scanners and adapters. Supports 128 devices and 256 connections. Minimum release cycle 1ms. Single connection supports a maximum of 1448 bytes. 4. OPC UA Supports a minimum of 8 client connections. Support sampling period of 50ms to 10s. - Page 20 Use CAN terminal resistor Use 485 and CAN terminal resistor (2) System dialing specifications Dial Function Description Dial to RUN, PLC switches to running state STOP Dial to STOP, PLC switches to stop state Dial to RESET and hold for 11s-20s, immediately restore the default IP and RESET release the corresponding connection (ENET0:192.168.6.6, ENET1: Automatically obtain IP address).
-
Page 21: Apparent Dimension
7-4. Apparent dimension (1) XSF5-A32: unit: mm 75.5 87.83 (2) XSF5-A64: unit: mm 75.5 87.83... - Page 22 WUXI XINJE ELECTRIC CO., LTD. No.816, Jianzhu West Road, Binhu District, Wuxi City, Jiangsu Province, China 214072 Tel: 400-885-0136 Fax: (510) 85111290 www.xinje.com...
