Bedienungsanleitung Kindersitz

User Manual Child Seat

1.0 Sicherheits und Warnhinweise

2.0 Produktbübersicht

3.0 Verwendung im KFZ

4.0 Verwendung von Sicherheitssitzen

4.1 Montage des Kindersitzes

4.2 Verwendung des Innenkissens

4.2.1 Das Innenkissen entfernen

4.2.2 Das Innenkissen installieren

4.3 Befestigung und Ausbau des Sitzes

4.3.1 Installation des Sitzes mittels der

ISOFIX-Verankerungspunkte

4.3.2 Entfernung des Sitzes von den

ISOFIX-Verankerungspunkten

4.4 Verwendung des Top-Tether

4.5 Verwendung des 5-Punkt Gurtes

4.5.1 Entriegelung der 5-Punkt-Gurtschnalle

4.5.2 Einstellen des 5-Punkt-Gurtes

4.5.3 Schließen des 5-Punkt-Gurtes

4.5.4 Straffen des 5-Punkt-Gurtes

4.5.5 Verstauen des 5-Punkt-Gurtes

4.6 Verstellen der Kopfstütze und Schultergurte

5.0 So bauen Sie den Kindersitz ein

5.1 Einbauweise für 76 - 105 cm

5.2 Einbauweise für 100 - 150 cm

5.2.1 Einbau mit ISOFIX + 3-Punkt-Gurt

5.2.2 Einbau mit 3-Punkt-Gurt

6. Pflege und Instandhaltung

Geeignet für Kinder mit einer Körpergröße von

Suitable for children with body-height from

www.petex.de

1.0 Safety and warnings

2.0 Product features

3.0 Usage in vehicle

4.0 Use of safety seats

4.1 Seat assembly

4.2 Use of the inner seat cushion

4.2.1 Remove the inner seat cushion

4.2.2 Install teh inner seat cushion

4.3 Seat fixing and removal

4.3.1 Fitting the seat to ISOFIX

4.3.2 Removing the seat from ISOFIX

4.4 Using the Top-Tether

4.5 Using the 5-point seat-belt

4.5.1 Unlock the 5-point safety buckle

4.5.2 Adjusting the 5-point seat-belt

4.5.3 Closing the 5-point seat-belt

4.5.4 Tightening the 5-point seat-belt

4.5.5 How to hide the 5-point seat-belt

4.6 Adjust headrest and shoulder belts

5.0 How to install the children-seat

5.1 Installation way for 76 - 105 cm

5.2 Installation way for 100 - 150 cm

5.2.1 Installation way with ISOFIX + 3-point seat-belt

5.2.2 Installation way with 3-point seat-belt

6. Care and maintenance

76 - 150 cm

Supreme PLUS

anchor-points

v20240104

Table of Contents

Need help?

Do you have a question about the Supreme PLUS and is the answer not in the manual?

Questions and answers

Summary of Contents for PETEX Supreme PLUS

Page 1 Bedienungsanleitung Kindersitz Supreme PLUS User Manual Child Seat Supreme PLUS 1.0 Sicherheits und Warnhinweise 1.0 Safety and warnings 2.0 Produktbübersicht 2.0 Product features 3.0 Verwendung im KFZ 3.0 Usage in vehicle 4.0 Verwendung von Sicherheitssitzen 4.0 Use of safety seats 4.1 Montage des Kindersitzes...
Page 2 Do not fit your child-restraint system onto a vehicle seat that has an airbag, unless it can be and is deactivated. Death or serious injuries can be caused by an activated airbag system. *siehe Produktetikett / refer to product label www.petex.de...
Page 3: Safety And Warnings
Do not make any modifications to the child restraint system. That can affect the safety characteristics of the product in a negative way. Keep corrosive substances from the child seat. The manufacturer guarantees the quality of the new product, but not for used items. www.petex.de...
Page 4: Product Features
Sicherheitsschnalle safety buckle Sitzkissen booster cushion Verstellriemen Adjuster strap Einstellgriff adjusting handle Einstellknopf Schultergurthalterung adjusting knob shoulder belt holder Schultergurte shoulder belts Top Tether Verbindungsplatte joint plate ISOFIX-Konnektoren Top Tether Gurtstraffer ISOFIX connectors Top Tether safety brake www.petex.de...
Page 5 Not to be used on this seat, if the fixation of your child in the passenger seat with active front airbag is prohibited by the vehicle manufacturer. Nur auf diesem Sitz befestigen, wenn ein Becken und Schultergurt vorhanden ist. Only use on this seat if a lap- and shoulder belt is available. www.petex.de...
Page 6 Picture 1: Hook the backrest into the base and pull it forward until it is secured into an upright position Picture 2: Combine the two buckle pieces together as shown Picture 3: Insert the buckle ends into the buckle Picture 4: Assembled seat www.petex.de...
Page 7 15 month up to 2 years approx. 2 up to 4 years Use the 3-point seat belt in Use a 5-point seat belt Use a 5-point seat belt the vehicle or ISOFIX + 3-point (need a seat cushion) (no seat cushion needed) seat belt www.petex.de...
Page 8 3. Pull the seat belt and shoulder pads to the armrests on both sides, put the seat cushion on the seat and ensure that the seat belt buckle is on the seat cushion 4. Put the seat belt and shoulder pads back on the inside of the seat cushion, close the 5-point seat belt. www.petex.de...
Page 9 In such case, if possible, use the headrest of the backseat. Bring the headrest into the lowest possible position. This way the child seat will be contacting with the backrest at two points at least, which adds and enhances stabilisation of the child seat. www.petex.de...
Page 10 6. Once you have removed the seat from the car, you will need to push the ISOFIX release button, with the other hand push the arm back towards the child seat. You will need to do this for both sides individually www.petex.de...
Page 11 „Top-Tether“ in die Seitentasche stecken, wie in der Abbildung links dargestellt. When using the 3-point seat belt, you need to hide the „top-tether“ and put the „top-tether“ into the side pocket as shown on the left. www.petex.de...
Page 12 With the headrest adjustment switch in the horizontal position, squeeze and pull/push the lever behind the headrest upwards or downwards to the desired location. Make sure the headrest is locked into a position www.petex.de...
Page 13 You will hear and audible ‚click‘ when it secured. To tighten the harness traps, pull the harness adjuster strap at the base of the seat until the straps are sitting close to your child chest. Please ensure you do not over tighten them. www.petex.de...
Page 14 3. To remove the shoulder belt, oben the hook an loop fasteners on the shoulder pads. 4. Unfasten the to fasteners on the side of the backrest, put the shoulder pads into thne side small bags. Hide bothe sides of the shoulder straps. Fasten the snap buttons again. www.petex.de...
Page 15 Insert the 5-point safety buckle together with the padding through the cover of the base. Insert the buckle and the padding into the recess. Fasten the snap-buttons again. 6. Hook the backrest into the base again. Push it and secure it into an upright position. www.petex.de...
Page 16 The headrest can be adjusted in 13 positions, please make sure the childs´ head is in the middle position of the headrest, the top shoulder straps´ position needs to be a little higher than shoulder height before using the children-seat in order to provide effective protection in case of a collision. www.petex.de...
Page 17 ‚click‘ when its secured. To tighten the harness straps, pull the harness adjuster strap at the base of the seat until the straps are sitting close to your child chest. Please ensure you do not overtighten them. Refer to pic. 10. www.petex.de...
Page 18 The headrest is in the correct position when the diagonal belt section of the 3-point seat-belt is positioned on the child‘s shoulders. The lower edge of the headrest should be at two fingers distance from the childs shoulder. www.petex.de...
Page 19 The headrest is in the correct position when the diagonal belt section of the 3-point vehicle belt sits on the child‘s shoulders. The lower edge of the headrest should be at two fingers distance from the childs shoulder. www.petex.de...
Page 20: Care Instructions
Seitenaufprallschutz und das Gurtsystem system this is one of the most strict handelt es sich um eine der strengsten standards in the world. Normen der Welt. PETEX Auto-Ausstattungs-GmbH Lauterbachstraße 44 D-84307 Eggenfelden E-Mail: service@petex.de www.petex.de...
