Model BCC-100
POULTRY PROCESSING MACHINE
Parts List, Installation and Operating Instructions
Applicable from Serial No. 500 On
BIRO Designed
BIRO Built
IMPORTANT NOTICE
This Manual contains important
safety instructions which must
be strictly followed when using
this equipment.
PTCT
BCC-100
096-2-17-27 B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BCC-100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BIRO BCC-100

Summary of Contents for BIRO BCC-100

  • Page 1 Model BCC-100 POULTRY PROCESSING MACHINE Parts List, Installation and Operating Instructions Applicable from Serial No. 500 On BIRO Designed BIRO Built IMPORTANT NOTICE This Manual contains important safety instructions which must be strictly followed when using this equipment. PTCT BCC-100...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS: PAGE NOTICE TO OWNERS AND OPERATORS ..........SAFETY TIPS .

  • Page 3: Notice To Owners And Operators

    Manual. Even so, BIRO cannot anticipate every circumstance or environment in which its products will be used. You, the owner and operator, must remain alert to the hazards posed by the function of this equipment particularly the SHARP ROTATING BLADE.

  • Page 4: Safety Tips

    ALWAYS Turn Off and Unplug Machine From Power Source and Perform Lockout/Tagout Procedures BEFORE Cleaning, Servicing, or Attempting to Unjam or Unclog. • NEVER Leave Machine Unattended While Operating. • PROMPTLY REPLACE Any Worn or Illegible Warning Labels. • USE ONLY BIRO Parts and Accessories Properly Installed.

  • Page 5: Installation

    11. Turn toggle switch to “OFF” position. 12. Check placement of all warning labels. Machine is ready for trained operators to process product. 13. Contact your local distributor or BIRO directly if you have any questions or problems with the installation or operation of this machine.

  • Page 6: Operation

    OPERATION SHARP ROTATING BLADE TO AVOID SERIOUS PERSONAL INJURY • ONLY Properly Trained Personnel Should Use This Equipment. • ALWAYS Keep Hands Clear of Blade and Other Moving Parts. • NEVER Operate With Knife Cover in Raised Position or Removed. Knife Cover Must be Down During Operation.
  • Page 7 MACHINE INSTALLATION The machine should be installed so that the machine is at a height that allows the operator to operate the machine comfortably with his or her hands slightly above the crook of the elbow and below the guide bar. PROCESSING FRYER AND BROILER FOR TRAY DISPLAY - SELF SERVE 2.
  • Page 8 PROCESSING FRYER AND BROILER FOR TRAY DISPLAY - SELF SERVE 6. A forward stroke removes the left thigh and drum- 5. Position left thigh and drumstick over apex guide bar stick without entering the breast area. exposing the rump knuckle while keeping both hands below the guide bar as shown.

  • Page 9: Cleaning

    DO NOT Tamper With, Bypass, or Remove Knife Cover, Finger Guard, Interlock Switch or Toggle Switch. • PROMPTLY REPLACE Any Worn or Illegible Warning Labels. • USE ONLY GENUINE BIRO Parts and Accessories Properly Installed. • ALWAYS Wear wire Mesh Safety Gloves When Touching or Handling Blade. •...

  • Page 10: Blade Removal And Installation

    A. BLADE REMOVAL Turn off and unplug the machine from the power source and perform lockout/tagout procedure before performing any maintenance. Always wear wire mesh safety gloves when touching or handling the blade. Raise the knife cover assembly out of the way. Loosen back guard assembly thumb screw.

  • Page 11: Finger Guard Return Spring Installation

    KEEP HANDS CLEAR OF SHARP ROTATING BLADE e. Raise knife cover to check safety interlock switch - machine should turn off. f. Lower knife cover - machine should resume operating. g. Turn toggle switch to OFF position. Unplug machine from power source. DO NOT USE THIS MACHINE IF ANY SWITCH FAILS TO FUNCTION PROPERLY D.

  • Page 12: Parts List/Ordering

    IMPORTANT: Must have Serial Number when ordering parts PARTS LIST MODEL BCC-100 APPLICABLE FROM SERIAL NO. 500 ON Item No. Description Item No. Description BCC47 Electrical lock nut BCC4-10 Knife cover assembly BCC4-7-10 BCC50 Knife cover finger guard assembly Solderless terminal...

  • Page 13: Parts Diagram

    BIRO Model BCC-100 Poultry Processing Machine BCC4 -10 BCC5-1 BCC4-7-10 MISCELLANEOUS BCC33 PARTS WN20S PHS033S BCC67-5 BCC67-6 BCC9-1 BCC53-1 BCC27-1 T3059-3-2 BCC50 BCC8-1 2566 BCC78-10 BCC78-10 BCC51-1 BCC25 BCC25-1 BCC25-2 HN10S BCC53-1 BCC37-2 BCC7-2 T3108-1 BCC37-4 BCC9-1 T3108-4 BCC7-4 BCC24-1A...

  • Page 14: Wiring Diagram

    WIRING DIAGRAM 115 VOLT/ 1 PHASE VOLT/ 1 PHASE VOLT/ 3 PHASE...

  • Page 15: Operator's Signature Page

    OPERATOR’S SIGNATURE PAGE WARNING READ AND UNDERSTAND THIS ENTIRE MANUAL BEFORE SIGNING BELOW MY SIGNATURE ATTESTS THAT I HAVE COMPLETELY READ AND UNDERSTAND THIS MANUAL. I REALIZE THAT THIS MACHINE, IF OPERATED CARELESSLY, CAN CAUSE SERIOUS INJURY TO MYSELF AND OTHERS. NAME (PRINT) SIGNATURE SUPERVISOR’S...

  • Page 16: Limited Warranty

    The warranty card must be returned to The BIRO Manufacturing Company for proper registra- tion. If no warranty card is returned to BIRO, the warranty period will begin from the date the machine was originally shipped from the factory.
