Summary of Contents for Deye SUN-5K-SG01HP3-EU-AM2

Page 1 Inwerter hybrydowy SUN-�K-SG��HP�-EU-AM� SUN-�K-SG��HP�-EU-AM� SUN-�K-SG��HP�-EU-AM� SUN-��K-SG��HP�-EU-AM� SUN-��K-SG��HP�-EU-AM� SUN-��K-SG��HP�-EU-AM� SUN-��K-SG��HP�-EU-AM� SUN-��K-SG��HP�-EU-AM� Instrukcja obsługi...
Page 2 Zawartość �� 1. Wprowadzenie dotyczące bezpieczeństwa 01-02 �� 2. Wprowadzenie do produktu 02-06 2.1 Przegląd produktu 2.2 Rozmiary produktu 2.3 Cechy produktu 2.4 Podstawowa architektura systemu 2.5 Wymagania dotyczące obsługi produktu 3. Instalacja �� 06-29 3.1 Lista części 3.2 Instrukcja montażu 3.3 Function port deﬁnition 3.4 Battery connection 3.5 Grid connection and backup load connection...
Page 3: About This Manual
Please be aware that the contents of this manual may undergo periodic updates or revisions as a result of ongoing product development. Consequently, the information contained herein is subject to change without prior notice. The latest manual can be acquired via service@deye.com.cn 1. Safety Introductions...
Page 4: Product Introductions
· This chapter contains important safety and operating instructions. Read and keep this manual for future reference. · Before using the inverter, please read the instructions and warning signs of the battery and corresponding sections in the instruction manual. · Do not disassemble the inverter. If you need maintenance or repair, take it to a professional service center.
Page 5: Product Overview
2.1 Product Overview SUN-5/6K-SG01HP3-EU-AM2 SUN-8/10K-SG01HP3-EU-AM2 SUN-12/15K-SG01HP3-EU-AM2 SUN-20/25K-SG01HP3-EU-AM2 1: Inverter indicators 7: Parallel port 13: Load 2: LCD display 8: CAN port 14: Function port 3: Function buttons 9: DRM port 15: Grid 4: DC switch 10: BMS port 16: PV input with two MPPT 5: Power on/oﬀ...
Page 6: Product Size
2.2 Product Size SUN-5/6K-SG01HP3-EU-AM2 SUN-8/10K-SG01HP3-EU-AM2 SUN-12/15K-SG01HP3-EU-AM2 Inverter Size SUN-20/25K-SG01HP3-EU-AM2 - �� -...
Page 7: Product Features
2.3 Product Features - 230V/400V Three phase Pure sine wave inverter. - Self-consumption and feed-in to the grid. - Auto restart while AC is recovering. - Programmable supply priority for battery or grid. - Programmable multiple operation modes: On grid, oﬀ grid and UPS. - Conﬁgurable battery charging current/voltage based on applications by LCD setting.
Page 8: Installation
2.5 Product handling requirements Lift the inverter out of the packaging box and transport it to the designated installation location. transport CAUTION: Improper handling may cause personal injury! · Arrange an appropriate number of personnel to carry the inverter according to its weight, and installation personnel should wear protective equipment such as anti-impact shoes and gloves.
Page 9 *1,2 Battery Plug connectors DC+/DC- Plug connectors Magnetic ring for BMS including metal terminal including metal terminal and Meter communication xN(blue) xN(black) Sensor Clamp cable x2 *4,5 Solar Photovoltaic Connector Special Magne�c ring for AC Magne�c ring x1 Spanner x1 wires *1,2: 33×23×15 mm *3: 25.9×28×13 mm...
Page 10 Installations Tools Installation tools can refer to the following recommended ones. Also, use other auxiliary tools on site. Protective goggles Anti-dust mask Earplugs Work gloves Work shoes Utlity Knife Slotted screwdriver Cross screwdriver Percussion drill Pliers Marker Level Rubber hammer socket wrenches set Anti-static wrist strap Wire stripper...
Page 11: Mounting The Inverter
≥500mm ≥500mm For a proper ventilation of the inverter and avoid overheating, allow a clearance of approximately 50 cm around the inverter and at least 100 cm to the front as shown in the above ﬁgure. Mounting the inverter Remember that this inverter is heavy! Please be careful when lifting out from the package. Choose the recommend drill head(as shown in below pic) to drill 4 holes on the wall, 62-70mm deep.
Page 12 3.3 Function port deﬁnition Inverter Meter Parallel_1 Parallel_2 BMS1 BMS2 RS485 1 2 3 4 5 6 7 8 9 10 1112 1 2 3 4 5 6 7 8 9 10 1112 SHUT DOWN Meter: for energy meter communication. Parallel_1: Parallel communication port 1.
Page 13 Thread the end of the CT's wires through the magnetic ring � and wrap the wires around it one lap. Fix the magnetic ring near the wiring terminals, as shown in the above diagram. Repeat this operation for the other two CTs. - ��...
Page 14: Battery Connection
3.4 Battery connection For safe operation and compliance, a separate DC over-current protector or disconnect device is required between the battery and the inverter. In certain applications, a disconnect switch may not be necessary, but it is always essential to have DC overcurrent protection in place. Refer to the typical amperage in the page 27 for the required fuse or circuit breaker size.
Page 15 b) Crimping metal terminals with crimping pliers as shown in picture 3.4. Hydraulic pliers Pic 3.4 Crimp the contact pin to the wire c) Insert the contact pin to the top part of the connector and screw up the cap nut to the top part of the connector completely, as shown in Pic 3.5.
Page 16 3.5 Grid connection and backup load connection · Before connecting to the grid, a separate AC breaker must be installed between the inverter and the grid, and also between the backup load and the inverter. This will ensure the inverter can be securely disconnected during maintenance and fully protected from over current.
Page 17 Please follow below steps to implement Grid, load and Gen port connection: 1. Before making Grid, load and Gen port connection, be sure to turn oﬀ AC breaker or disconnector ﬁrst. 2. Strip the insulation of AC wires by about 10mm, insert AC wires according to polarities indicated on the terminal block and tighten the terminals.
Page 18: Inverter Model
3.6.1 PV Module Selection: When selecting proper PV modules, please be sure to consider below parameters: 1) Open circuit Voltage (Voc) of PV modules can not exceed max. PV Input Voltage of inverter. 2) Open circuit Voltage (Voc) of PV modules should be higher than min.PV Input Voltage of inverter.
Page 19 Safety Hint: Please use approved DC cable for PV system. Cross section（mm ） Cable type Range Recommended value Industry generic PV cable 2.5-4 4(10AWG) (model: PV1-F) (12-10AWG) Chart 3-6 The steps to assemble the PV connectors are listed as follows: a) Strip the insulation of the PV wire by 7 mm, disassemble the cap nut of the MC4 connetc- tor, thread one PV wire through the cap nut of the connector (see Pic 6.3).
Page 20 The Isc current of PV modules should not exceed the Max.PV Isc current of this model inverters. If exceeds, it may damage the inverter and is not covered by Deye's warranty. - �� -...
Page 21 100 A, the default three CTs also need to be replaced with smart meters or larger CTs. Please contact the Deye support team to conﬁrm which speciﬁcation of CT or smart meter to use.
Page 22 Deye, otherwise it may not be able to be used due to communication mismatch. The deﬁnition of the "Meter" port can be found in the Appendix part which is in the end of this user manual.
Page 23 3.7.3 Meter connection with CTs GRID Inverter Meter Parallel_1 Parallel_2 AC Breaker RS485A RS485B Home Load AC Breaker Three-Phase Smart Meter Grid Blue line White line Blue line White line Blue line Note: the arrow direction towards the inverter White line 6 9 10 13 14 16 17 19 21...
Page 24 GRID Inverter Meter Parallel_1 Parallel_2 AC Breaker Home Load AC Breaker NA LA L1 L2 L3 N Grid S1 S2 S1 S2 S1 S2 Black line Red line Black line Red line Black line Note: the arrow direction Red line towards the inverter 9 1 0 11 1 2 1 3 1 4 1 5 1 6 1 7 1 8 1 9 2 0 Eastron...
Page 25: Meter Connection
Meter connection Thread the end of the communication cable of meter through the magnetic ring 2, then wrap the cable one lap around it as the diagram above. - �� -...
Page 26: Earth Connection(Mandatory)
3.8 Earth Connection(mandatory) Ground cable shall be connected to ground plate on grid side, this prevents electric shock if the original protective conductor fails. (Copper wires) (bypass) Earth Connec�on Model Wire Size Cross section(mm ) Torque value(max) 5/6/8/10kW 8AWG 3.4Nm 12/15/20/25kW 4AWG 4.0Nm...
Page 27 3.10 Wiring diagram with neutral line grounded - �� -...
Page 28 3.11 Wiring diagram with neutral line ungrounded - �� -...
Page 29: Backup Load
3.12 Typical application diagram of on-grid system NOTE： This model inverter only has one battery input, if you want to use more than one set batteries, you need to connect these battery sets in parallel ﬁrstly, then connect the master BMS with BMS1 port of inverter via communication cable. L wire N wire PE wire...
Page 30 3.13 Typical application diagram of diesel generator L wire N wire PE wire Remotely control signal line coil relay open contact Generator ③AC Breaker GS (diesel generator startup signal) G-start (1,2): dry contact signal for startup the diesel generator. 1 2 3 4 5 6 7 8 9 10 1112 SHUT DOWN BMS1 BMS2...
Page 31 Note: For the parallel system, the lead-acid battery and 'No Batt' mode are not supported. All inverters connected in parallel must be the same model. Please use lithium battery which is on the "Deye Approved Battery list". Each inverter should have its own separate battery set.
Page 32: Operation And Display Panel
4. OPERATION 4.1 Power ON/OFF Once the system has been properly installed and the battery is connected to the inverter, follow the steps below to turn on the inverter: 1. Turn all the breakers of the installation on. 2. Turn on the DC switch of the inverter and the power button of battery (If there is one battery installed at the system), no matter the order.
Page 33 5. LCD Display Icons 5.1 Main Screen The LCD is touchscreen, below screen shows the overall information of the inverter. 01/19/2024 19:34:40 -3.2 -2.0 1.The icon at the center of the screen indicates whether the system is under normal operation or not, displaying "ON"...
Page 34: Battery Setting
5.1.1 LCD operation ﬂow chart Solar Page Solar Graph Grid Page Grid Graph Inverter Page Main Screen Battery Page BMS Page Load Page Load Graph Battery Setting System Work Mode Grid Setting System Setup Gen Port Use Basic Setting Advanced Function Device info - ��...
Page 35 5.2 Detail pages Click the icons on main screen of LCD display, you can enter the detail pages of "Solar","Inverter", "Load","Grid" and "Batt". Solar This is Solar Panel detail page. ① Solar Panel Generation. ② Voltage, Current, Power for each MPPT. ②...
Page 36 0.00 0.01 Power: -1490W Temp:27.0C Li-BMS 100% Li-BMS -1.47 -1.67 LiBms1: Deye-HV Battery Voltage: 329.9V Battery capacity :40AH Battery Current: -4.5A Battery Charge Voltage :345.6V This is Battery detail page. Battery Temp: 27.0C Charge current limit :5A BATTERY DETAIL PAGE...
Page 37: System Setup Menu
System Solar Power:Year System Solar Power:Total 2022 TOTAL 2000KWh 2000 1600 1200 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 CANCEL Month Year...
Page 38: Basic Setting Menu
5.5 Basic Setting Menu Basic Setting Time Syncs: Enable the inverter to automatically synchronize cloud platform time. Time Syncs Beep Auto Dim Beep: Used to turn on or oﬀ the beep sound in inverter's alarm status. Year Month Basic Auto Dim: Used to automatically adjust the brightness of Set1 2019 the LCD display screen.
Page 39 5.6 Battery Setting Menu Batt Capacity: Reserved. Battery Setting Use Batt V: Use battery voltage for all battery related settings. Batt Mode Max. A charge/discharge: Max battery charge/discharge Lithium Batt Capacity current(0-30A for 5/6kW model, 0-37A for 8/10/12/15/ Batt Mode 20kW model, 0-50A for 25kW model ).
Page 40: Absorption Stage
Battery Setting page is shown in the ﬁgure on the left. Lithium Mode: This is the BMS communication protocol code which can be conﬁrmed on the "Deye Approved Battery list" based on the battery model you are using. Lithium Mode Shutdown：Be valid in Oﬀ-grid mode, battery can discharge to this...
Page 41 5.7 System Work Mode Setup Menu Work Mode System Work Mode Selling First: This Mode allows hybrid inverter to sell back any excess power produced by the solar panels to the grid. If time of use is active, the battery energy also 12000 Selling First Max Solar Power...
Page 42 Time of use: it is used to program when to use grid or generator to charge the battery, and when to discharge the battery to power the load. Only tick "Time Of Use" then the follow items (Grid, charge, time, power etc.) will take eﬀect. Time Of Use Note: when in selling ﬁrst mode and click time of use, the battery Time...
Page 43 5.8 Grid Setting Menu Grid Mode: Grid Setting/Grid code selection General Standard、UL1741 & IEEE1547、CPUC RULE21、 SRD-UL-1741、CEI_0_21_Internal、EN50549_CZ-PPDS(>16A)、 Grid Mode General Standard 0/23 Australia_A、Australia_B、Australia_C、AS4777_NewZealand、 VDE4105、OVE-Directive R25、EN50549_CZ_PPDS_L16A、 Phase Type Grid Frequency 50HZ Grid NRS097、G98、G99、EN50549_1_Norway_133V、 Set1 0/120/240 60HZ EN50549_1_Norway_230V、Japan_200VAC_3P3W、 CEI_0_21_External、CEI_0_21_Areti、Japan_400VAC_3P3W、 0/240/120 Japan_415VAC_3P4W、EN50549_1_Switzerland. Please follow the local grid code and then choose the Grid Level LN:220V/LL:380V(AC) corresponding grid standard.
Page 44 F(W): It's used to adjust the output active power of inverter Grid Setting/F(W) according to the grid frequency. F(W) Droop F: percentage of nominal power per Hz For example, "Start freq F=50.2Hz, Stop freq F=51.5, Over frequency Droop F %PE/Hz Droop F=40%PE/Hz"...
Page 45 5.9 Generator Port Use Setup Menu Generator input rated power: allowed Max. power from diesel GEN PORT USE generator. GEN connect to grid input: connect the diesel generator to the grid input port. Mode Smart Load Output: Use the GEN port as an AC output port, and Generator Input GEN connect to Grid input the load connected to this port can be controlled on/oﬀ...
Page 46 5.10 Advanced Function Setup Menu Advanced Function Solar Arc Fault ON: This function is only applicable to the US market and customized customers. System selfcheck: Disable. this is only for factory. Solar Arc Fault ON Backup Delay Gen Peak-shaving: Limit the maximum output power of the generator to the set rated power on "GEN PORT USE"...
Page 47: Device Info Menu
5.11 Device Info Menu Li-BMS Li-BMS Device Info. This page show Inverter ID, Firmware version and alarm codes. Inverter ID: 2102199870 Flash Charge Charge Volt Volt Curr Curr Temp Temp Energy Energy Fault Fault HMI: Ver 1001-8010 MAIN:Ver2002-1046-1707 Volt Volt Curr Curr 50.38V 19.70A...
Page 48: Warranty
The last power backup will be the Generator if it is available. 7. Warranty As to Warranty terms, please refer to 《General Warranty Agreement - DEYE》. Under the guidance of our company, customers return our products so that our company can provide service of maintenance or replacement of products of the same value.
Page 49: Troubleshooting
· Damage during transportation of equipment； · Damage caused by incorrect installation or commissioning； · Damage caused by failure to comply with operation instructions, installation instructions or maintenance instructions； · Damage caused by attempts to modify, alter or repair products； ·...
Page 50 Error code Description Solutions W�� Reserved �. Check the operating status of the fan. �. If the fan is running abnormally, open the cover of the W�� FAN_IN_Warn inverter to check the connection of the fan. �. Check the phase sequence connection of the power grid. �.
Page 51 Error code Description Solutions F�� GFDI_Ground_Failure Check whether the PV is grounded. F�� EEPROM_Read_Failure Restart the inverter � times and restore the factory settings. F�� EEPROM_Write_Failure Restart the inverter � times and restore the factory settings The BUS voltage can’t be reached by PV or battery. F��...
Page 52 Error code Description Solutions DC side over current fault �. Check PV module connection and battery connection; �. When in the oﬀ-grid mode, starting the inverter under a high F�� Tz_Dc_OverCurr_Fault power load may report F��. Please reduce the load power connected.
Page 53 Error code Description Solutions Check the grid voltage and frequency, whether the connection F�� AC_NoUtility_Fault of the power grid is normal. F�� Reserved F�� Reserved F�� Reserved F�� INT_AC_OverCurr_Fault Inverter AC overcurrent, restart the inverter. F�� INT_DC_OverCurr_Fault Inverter DC overcurrent, restart the inverter. Check the hybrid inverter work status.
Page 54 Error code Description Solutions F�� Battery_Temp_High_Fault Check wether the temperature data of BMS is too high. BUS voltage is too high �. Check whether battery voltage is too high. F�� DC_VoltHigh_Fault �. check the PV input voltage, make sure it is within the allowed range.
Page 55: Data Sheet
9. Datasheet Model SUN-5K-SG01HP3- SUN-6K-SG01HP3- SUN-8K-SG01HP3- SUN-10K-SG01HP3- EU-AM2 EU-AM2 EU-AM2 EU-AM2 Battery Input Data Battery Type Lithium-ion Battery Voltage Range(V) 160-700 Max. Charging Current(A) Max. Discharging Current(A) Charging Strategy for Li-ion Battery Self-adaption to BMS Number of Battery Input PV String Input Data Max.
Page 56 DC Component Monitoring Ground Fault Current Monitoring Power Network Monitoring Island Protection Monitoring Earth Fault Detection DC Input Switch Overvoltage Load Drop Protection Residual Current (RCD) Detection Surge Protection Level TYPE II(DC), TYPE II(AC) Interface Display LCD+LED Communication Interface RS232, RS485, CAN Monitor Mode GPRS/WIFI/Bluetooth/4G/LAN (optional) General Data...
Page 57 Model SUN-12K-SG01HP3- SUN-15K-SG01HP3- SUN-20K-SG01HP3- SUN-25K-SG01HP3- EU-AM2 EU-AM2 EU-AM2 EU-AM2 Battery Input Data Battery Type Lithium-ion Battery Voltage Range(V) 160-700 Max. Charging Current(A) Max. Discharging Current(A) Charging Strategy for Li-ion Battery Self-adaption to BMS Number of Battery Input PV String Input Data Max.
Page 58 DC Component Monitoring Ground Fault Current Monitoring Power Network Monitoring Island Protection Monitoring Earth Fault Detection DC Input Switch Overvoltage Load Drop Protection Residual Current (RCD) Detection Surge Protection Level TYPE II(DC), TYPE II(AC) Interface Display LCD+LED Communication Interface RS232, RS485, CAN Monitor Mode GPRS/WIFI/Bluetooth/4G/LAN (optional) General Data...
Page 59 RS232 WIFI/RS232 D-GND WIFI/RS232 This RS232 port is used to connect the datalogger 12Vdc - �� -...
Page 60 11. Appendix II �. Split Core Current Transformer (CT) dimension: (mm) �. Secondary output cable length is �m. Lead Outside - �� -...
Page 61 · Low Voltage Directive ��/��/EU (LVD) · Restriction of the use of certain hazardous substances ��/��/EU (RoHS) NINGBO DEYE INVERTER TECHNOLOGY CO., LTD. conﬁrms herewith that the products described in this document are in compliance with the fundamental requirements and other relevant provisions of the above mentioned directives.
Page 62: Eu Declaration Of Conformity
Models: SUN-5K-SG01HP3-EU-AM2;SUN-6K-SG01HP3-EU-AM2;SUN-8K-SG01HP3-EU-AM2; SUN-10K-SG01HP3-EU-AM2;SUN-12K-SG01HP3-EU-AM2;SUN-15K-SG01HP3-EU-AM2; SUN-20K-SG01HP3-EU-AM2;SUN-25K-SG01HP3-EU-AM2; Name and address of the manufacturer: Ningbo Deye Inverter Technology Co., Ltd. No. 26 South YongJiang Road, Daqi, Beilun, NingBo, China This declaration of conformity is issued under the sole responsibility of the manufacturer. Also this product is under manufacturer’s warranty.
Page 63 Add.: No.26 South YongJiang Road, Daqi, Beilun, NingBo, China. Tel.: +86 (0) 574 8622 8957 Fax.: +86 (0) 574 8622 8852 E-mail: service@deye.com.cn Web.: www.deyeinverter.com...
