- Page 1 Network Camera Operation Manual DC-T4517WRXP DC-T4517WRX DC-T4517WRXP-A DC-T4517WRX-A Powered by...
- Page 2 Before reading this manual This is a basic operation manual for use of an IDIS network camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.
- Page 3 Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1.
- Page 4 IDIS Co., Ltd. reserves all rights concerning this manual. Use or duplication of this manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this manual are subject to change without prior notice for reasons such as functionality enhancements.
-
Page 5: Table Of Contents
Table of Contents Part 1 - Remote Setup ........7 Remote Setup . - Page 6 Part 2 - IDIS Web ........
-
Page 7: Part 1 - Remote Setup
Configure basic network camera settings and all other system settings. Screen images may vary depending on the model. Launch the IDIS Discovery program and then from the main screen, select a network camera whose settings you wish to change. Click on the Setup icon. -
Page 8: Quick Setup
Change the camera’s system information, add users/ changed, too. If you want to change those settings, groups, and/or import/export settings. connect to the camera by using the IDIS Discovery program. - ONVIF Event Type • Normal: This is the usual way the camera delivers events. -
Page 9: Date/Time
Part 1 - Remote Setup • Setup Date/Time - Load Default Setup: Restores all settings other than Date/Time to their factory defaults. Select Include Network Setup to load default network settings as well. For more information on network setup, refer to the Network on page 10. - Import Setup: Open a setup file and apply its settings to the camera. -
Page 10: User/Group
Part 1 - Remote Setup Network User/Group Change the network settings, enable FEN and security • User/Group: Change remote camera control features, and control network bandwidth use. permission settings for users and user groups. - Add Group: Add a new user group. Designate a name for the group and then specify control authorities. -
Page 11: Ip Address
Part 1 - Remote Setup IP Address IPv6 IPv4 • Check Use to activate IPv6. • Type: Select the type of network you are using. If this option has been changed, click Save to apply the • Type: Select the type of network you are using. If this current settings, and then restart Remote Setup. -
Page 12: Fen
Web browser. (If you can not access special characters, you can access by changing the encoding.) The FEN Server operated by IDIS is a service to its clients and may go offline without notice for server update purposes or due to an unexpected failure. -
Page 13: Port/Qos
Web / HTTP ports are enabled by default and cannot be disabled. By enabling IDIS Web and RTSP ports, you will be able to use the IDIS Web program or a media player that supports RTSP (Real-Time Streaming Click Apply to use the recommended port numbers. -
Page 14: Bandwidth Control
Part 1 - Remote Setup Bandwidth Control • Port numbers of the remote program must be updated whenever the camera's port numbers are changed. Regulates the camera’s network bandwidth use based • ONVIF protocol may not function if using HTTPS. on network traffic fluctuations. -
Page 15: Security
Part 1 - Remote Setup Security IEEE 802.1X Select the IEEE 802.1X option to enable IEEE 802.1X network connection authentication. • IP Filtering: Select this option to enable IP Filtering. IP Filtering allows camera access from certain IP addresses and blocks access from others. •... -
Page 16: Video
Part 1 - Remote Setup Video Camera Image Sensor Configure Image Sensor settings. Configure Camera, Streaming, MAT, Privacy Masking and OSD options. • Mode: Choose resolution(16:9 for 4M and 4:3 for 5M). When changing sensor mode, some settings will be reset to default. - Page 17 Part 1 - Remote Setup White Balance Exposure Configure White Balance settings.Preset: Use Configure Exposure settings. preconfigured white balance settings. • AE Target Gain: Specify exposure compensation’s • Preset: Use preconfigured white balance settings. target gain. Exposure is compensated automatically based on the specified target gain.
- Page 18 Part 1 - Remote Setup - Manual: Use the slider to select the desired shutter Day & Night speed and gain. Select the most suitable minimum Configure Day & Night settings. and maximum shutter speeds and gains for the lighting conditions in the area where the camera is located.
- Page 19 Part 1 - Remote Setup • Switching Level: Sets up the switching level between Miscellaneous daytime and nighttime modes. For example, if the Configure Miscellaneous settings. darkness level is set to 3 and the brightness level to 5, the system switches to nighttime mode when in lighting conditions of level 3 or below and to daytime mode when in lighting conditions of level 5 or over.
-
Page 20: Streaming
Part 1 - Remote Setup Streaming • Intelligent Codec: Analyze real-time video intelligently to minimize bitrate while maintaining frame rate and image quality. In environments where there are many video changes, image quality can be reduced. • Multi-View Streaming: Designate a specific area of the screen and stream images from that area only. -
Page 21: Mat
• Sensitivity: Set the motion detection sensitivity. Higher values will result in more sensitive motion detection. DC-T4517WRXP(-A) model • Inactivity Period: Set the Inactivity Period. If motion is not detected for the duration of time specified, video is transmitted and recorded using the frame rate designated below until movement is detected again. -
Page 22: Osd
Part 1 - Remote Setup DC-T4517WRX(-A) model Select OSD to indicate texts and Date/Time information. (Draw)/ (Erase): Set or remove a privacy mask. Click on the button and drag & drop using the mouse to set up a privacy mask. - No./Name: Displays a list of active privacy masks. -
Page 23: Event Action
Part 1 - Remote Setup Event Action Email Select Email to send out emails. Designate event detection alert actions. • SMTP Server/Port: Enter the SMTP server’s IP address (or domain name) and port number you received from the network administrator. If a DNS server has been set up during network configuration, you can enter a domain name instead of an IP address. -
Page 24: Remote Callback
Select FTP Upload to upload .jpg image of the event remote system. detected to an FTP server. • Not supported from the IDIS Web program. • The camera must be registered to the remote system in order to use the Remote Callback feature. - Page 25 Part 1 - Remote Setup • When specifying the Upload Path or Base File Name, you cannot use special characters such as \, /, #, *, |, :, ", <, >, and ?. • The resolution of FTP upload image can change depending on the resolution setting applied under Video >...
-
Page 26: Event
Part 1 - Remote Setup Event Motion Detection Configure event detection settings. Select Motion Detection to configure motion detection event settings. With motion detection event enabled, motion detections within the designated area will be assumed as events. • Sensitivity: Select daytime and nighttime motion detection sensitivity levels. -
Page 27: Trip-Zone
• Not supported from the IDIS Web program. • The camera must be registered to the remote system in order to use the Remote Callback feature. -
Page 28: Tampering
• Not supported from the IDIS Web program. • The camera must be registered to the remote system in order to use the Remote Callback feature. -
Page 29: System Event
Action must be configured correctly in order to send out emails and messages. • Remote Callback is not supported on IDIS Web. • The camera must be registered to the remote system in order to use the Remote Callback feature. -
Page 30: Part 2 - Idis Web
– Tools → Internet Options → Advanced → Security → Use TLS 1.0 (select) • If connecting by entering an IP address and a port number, you can connect by entering just the IP address if IDIS Web connection port number has been set to 80 (443 when entering https). - Page 31 Run as administrator option. Otherwise, certain IDIS Web functions might not be available. • When running IDIS Web, the bottom section of the screen may get cut off if the address bar or the status bar is shown.
-
Page 32: Web Live Mode
A remote web monitoring program that allows you to monitor images from remote locales in real-time. & Press to terminate IDIS Web. Place the mouse pointer on the logo to check IDIS Web's version. TYPE 1 Displays the current time. Click to view the video in full screen. - Page 33 Part 2 - IDIS Web Event status window at the bottom of the screen displays a list of events detected at remote locales. Trip zone Tampering Motion Detection Right-click on the screen to display the pop-up menu. Click to enable or disable each function.
-
Page 34: Part 3 - Appendix
Part 3 - Appendix Setup Menu Tree (Remote Setup) Remote Setup Quick Setup System Network Video System General Date/Time User/Group Network IP Address Port/QoS Bandwidth Control Security IEEE 802.1X Video Camera Streaming Privacy Masking Event Action Email Remote Callback FTP Upload Event Motion Detection Trip zone... -
Page 35: Index
Part 3 - Appendix Index Quality Bitrate Control Remote Port Resolution RTSP Port Camera Name Compression Date/Time DSCP Time Sync FEN Name Use FEN FEN Server Use HTTPS Frame Rate User/Group Use UPnP IDIS Web port IPFiltering Network Bandwidth Limit ONVIF Protocol V1.1... - Page 36 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
