- Page 1 UV Bill Validator, CX7 Kit Instructions 7772-K157 Issue B © 2024 NCR Voyix. All rights reserved. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 2 NCR Voyix, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR Voyix in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR Voyix representative or NCR Voyix office for information that is applicable and current.
- Page 3 Table of Contents Copyright Side Mount UV Bill Validator, CX7 Kit Contents Installation Procedure Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 4 Revision Record Issue Date Remarks Dec 2020 First Issue Dec 2021 Added Warning statement Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 5 Side Mount UV Bill Validator, CX7 This kit provides a UV Bill Validator for Port B of NCR CX7 All-in-One POS (7772). Kit Contents Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 6 Remove the two (2) screws that secure the Cable Cover to the Back Cover. b. Rotate and unhook the Cable Cover from the Back Cover. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 7 Remove the Ethernet Cable from the Cable Management Hook then disconnect the Cable. 4. Loosen the two (2) captive screws that secure the Back Cover to the Display. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 8 5. Rotate the Back Cover away from the Display and unhook the Back Cover Tabs. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 9 6. Insert a flat screw driver in the slot of Port B to unsnap the Plate from the display housing. 7. Hook the UV Bill Validator Front Housing into the display housing and snap into place. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 10 8. Secure the Bill Validator Front Housing with a screw. 9. Route the Bill Validator Cable and the Ground Cable through the Port opening. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 11 10. Route and secure the Bill Validator Cable under the Cable Management Hooks as shown. 11. Connect the Bill Validator Cable to the Motherboard. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 12 Bill Validator Cable under the Bill Validator Front Housing, then install the Bill Validator on the Bill Validator Front Housing (2 screws). 13. Secure the Ground Cable under the corner Motherboard Screw. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 13 14. Reinstall the Display Back Cover. 15. Reconnect the 180-degree USB-C Cable and Ethernet Cable. 16. Reinstall the Cable Cover. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
