- Page 1 NCR Encrypted MSR Kit Instructions 7772-K141 Issue C © 2024 NCR Voyix. All rights reserved. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 2 NCR Voyix, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR Voyix in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR Voyix representative or NCR Voyix office for information that is applicable and current.
- Page 3 Table of Contents Copyright NCR Encrypted MSR Kit Contents Installation Procedure Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 4 Date Remarks Jul 2019 First Issue Jun 2020 Added CX5 (7773) to introduction Updated illustrations for steps 4 and 5 Dec 2021 Added Warning statement Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 5 NCR Encrypted MSR This kit provides an NCR Encrypted MSR for the NCR CX7 All-in-One POS (7772) or NCR CX5 All-in-One POS (7773). Kit Contents Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 6 Remove the two (2) screws that secure the Cable Cover to the Back Cover. b. Rotate and unhook the Cable Cover from the Back Cover. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 7 Remove the Ethernet Cable from the Cable Management Hook then disconnect the Cable. 4. Loosen the two (2) captive screws that secure the Back Cover to the Display. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 8 5. Rotate the Back Cover away from the Display and unhook the Back Cover Tabs. 6. Connect the MSR Cable to the Extension Cable. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 9 7. Route the Extension Cable through the Port opening. 8. Route and secure the Cable under the Cable Management Hooks as shown, then connect the Cable to the Motherboard. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
- Page 10 11. Secure the MSR with a screw. 12. Reinstall the Display Back Cover. 13. Reconnect the 180-degree USB-C Cable and Ethernet Cable. 14. Reinstall the Cable Cover. Confidential and proprietary information of NCR Voyix. Use and disclose solely pursuant to company instructions.
