- Page 1 User Manual VERSION 2.3...
- Page 2 Register your model online [section 1.0] • Charge your battery and Remote Control [section 4.0 and 9.0] • Assemble your model [section 3.0] For Customer Support, please contact MGI directly for immediate and professional advice. www.mgigolf.com MGI AUSTRALIA Service Email: customerservice@mgigolf.com Live Chat: visit mgigolf.com...
-
Page 3: Table Of Contents
13.1 Warranty Policy 13.2 Warranty Exclusions 13.3 Parts Installed During Warranty 14.0 Preventative Maintenance Program 14.1 Cleaning Your MGI Navigator Quad 14.2 Rear Wheel Axles Maintenance 14.3 Upper and Lower Bag Strap Maintenance 14.4 Correcting the Alignment 14.5 MGI Service Schedule 15.0 Service and Repair Centres... -
Page 4: Registration
Assist us to contact you with any updates to your model To register your model, visit mgigolf.com You will need to record your MGI serial number. This is found under the battery tray. Please keep this user manual on file for your own reference and a copy of your serial number;... -
Page 5: Assembling Your Unit
3.0 Assembling Your Unit 3.1 Attaching the Front Wheels The two front wheels need to be attached to your MGI Navigator Quad. There is no difference between each front wheel so either can be placed on the left or right side. Simply line up the silver pin on the front wheel with the axle and push into the frame until you hear a click. -
Page 6: Rear Wheel Positions
3.3 Rear Wheels positions The MGI Navigator Quad is designed to allow the rear wheels to be in two positions. The position is determined by where the wheel is locked on the axle in either of the two grooves [see picture]. -
Page 7: Unfolding
Step 3: Slide fold lever 2 upwards to release the handle. Step 4: The handle is now free to pull upwards. The unit will naturally unfold as you continue to pull upwards until the unit is completely open. MGI Navigator™ Quad User Manual... -
Page 8: Folding
Step 5: Close the fold lever 2 to lock the handle into place. Step 6: Bring the top bag support brackets together, then lock together using the button. 3.5 Folding Step 1: Open the fold lever 2 to release the handle. Step 2: Press the button shown while applying pressure down to close. -
Page 9: Positioning The Seat
Step 3: You can now insert the seat into the bracket. IMPORTANT: Depress the seat with your hand before sitting. Do not use the seat on uneven surfaces. MGI does not warranty any seat support brackets that are damaged or bent. -
Page 10: Attaching The Umbrella Holder
4.0 Battery Care 4.1 Before using your MGI Navigator Quad for the first time you must fully charge fully charge you battery for 10 hours. The MGI Navigator Quad can only be used with the: •... -
Page 11: Tips And Looking After Your Battery
The Red LED will flash is there is a fault with the charger. 4.2 Tips and Important information about Charging your Battery Before using your MGI Navigator Quad for the first time you • must fully charge the battery for 10 hours. -
Page 12: Battery Lead Fuse
Step 2: Plug the battery into the model as shown. Your model has been equipped with fail safe battery connection, so the unit will not move when you plug the battery in. Your unit will only start once the speed control or remote are activated. 5.0 Battery Lead Fuse Your battery has a 40amp fuse connected to the battery lead. -
Page 13: Adjusting And Aligning The Front Wheels
(Serial Numbers starting with “ANQV”) Each unit is checked for straight tracking prior to leaving the factory. In the unlikely event the MGI Navigator Quad is not tracking straight, the front wheels can be adjusted to regain straight tracking as follows: Start the unit using the manual controls on a straight, flat path. -
Page 14: Front Wheel Maintenance
6.3 Front Wheel Maintenance During the life of the MGI Navigator Quad, you may experience wearing of the front wheel gasket. This may result in a noise coming from the front wheel during use. You can replace this gasket at home using 1 of the 4 gaskets included in the spare parts included with your model. -
Page 15: Operating The Top Box
The battery indicator is set to L for Lithium as the Navigator Quad is only compatible with the MGI 12v 26aH Lithium battery. 9.3 Remote Battery Level Indicator The MGI Navigator Quad remote is powered by a rechargeable MGI Navigator™... -
Page 16: Remote Battery Level Indicator
lithium battery. See section 10.1 for tips on recharging”. The Digital top box displays the remote control battery level on screen. 9.4 Unit measurements To toggle between kilometres and miles, press the Function Button 2 [right] 9.5 Distance Modes There are three distance measurements. To toggle between the mode, press the Function Button 1 [left]. -
Page 17: Competition Mode
In the unlikely event the club you are playing at does not allow the use of distance devices you will need to disable the distances feature on the MGI Navigator Quad. To disable the distance recording feature, simply hold down the two control buttons at the same time for 3 seconds. -
Page 18: Charging Your Remote Control
10.1 Charging Your Remote Control Before you start using your MGI Navigator Quad you must fully charge the remote control internal lithium ion battery for approximately 6 hours using the USB cord provided. The top right UNLOCK button will flash while charging. When a full charge is complete, the green light will stay on and stop flashing. -
Page 19: Keypad Unlock And Lock
10.7 Remote Range and Safety Stop The MGI Navigator Quad can be remotely controlled up to 50m. If the remote control is not touched for 150m, then the automatic safety stop will activate causing the unit to stop. This is for the protection of your unit, yourself and others. -
Page 20: Integrated Gps Holder And Compartment
12.0 Integrated GPS Holder and Compartment In the top handle compartment is an integrated GPS/mobile device holder. To open the holder the holder always press the Coloured button at the top of the holder. Place the GPS into the cradle, then close the holder by squeezing the two sides closer together. -
Page 21: Warranty
13.0 Warranty 13.1 Warranty Policy The MGI Navigator Quad Gyro is covered by a limited 3 year manufacturer’s warranty from the date of purchase. Duration of this warranty is: – 2 years on parts* – 2 years on Lithium batteries and chargers... - Page 22 ALL components simultaneously. Replacing individual components on a water-damaged Navigator Quad poses a higher risk of future failure of other components and therefore these parts will not be covered under warranty.
-
Page 23: Parts Installed During Warranty
Maintenance Program [PMP]. The PMP consists of work to be carried out by both the owner and authorised service centres. To properly maintain the warranty of your MGI Navigator Quad, it is essential that this work is carried out. If the work carried out... -
Page 24: Upper And Lower Bag Strap Maintenance
14.3 Upper and Lower Bag Strap Maintenance [See Maintenance Schedule] The bag straps should be replaced as per the Service Schedule. The upper bag strap can be replaced by: • Removing the left and right hand straps form the upper bag support •... -
Page 25: Mgi Service Schedule
Replace upper and lower bag straps BO = Navigator Quad owner can carry out this work SC = Charged work to be carried by approved service centre BO/SC = The six monthly service can be completed by either an authorised service centre or the owner of the model. -
Page 26: Service And Repair Centres
16.0 Purchasing Parts and Accessories You are welcome to service your model out of warranty, by purchasing parts direct from MGI. Please call or email to discuss the right parts and instructions. 17.0 Contacting MGI mgigolf.com... -
Page 27: Frequently Asked Questions
See section 5.3 Front wheel maintenance Q: My model is not tracking straight. A: You can do a simple realignment on the two front wheels. See section 5.2 Adjusting and aligning the front wheels MGI Navigator™ Quad User Manual... - Page 28 MGI AUSTRALIA MGI HEAD OFFICE 11 Maurice Court Nunawading 3131 Victoria Australia T +61 3 8872 6700 E sales@mgigolf.com SERVICE customerservice@mgigolf.com MGI USA T 1800 617 2990 E salesusa@mgigolf.com SERVICE 1888 391 0200 SERVICE serviceusa@mgigolf.com MGI GLOBAL E globalsales@mgigolf.com...
