Merryfair NEZ 879 KT A4S N2 Assembly Instruction

Assembly
Instruction
1
X4
M6 X25mm
2
X4
M6 X25mm
3
X8
M6 X40mm
4
5
6
X2
Models
879 KT A4S N2
878 KT A4S N2
A
User
Instructions
Seat Height Adjustable
A
Flip up lever on right-side to raise or lower seat. Adjust such that your feet
are adequately supported on floor.
Multi-Position Tilt Lock
B
Recline to desired position, and flip down lever on left-side to lock. Flip up
lever to release tilt-lock.
Tilt tension Control
C
Turn bottom knob clockwise to provide a stronger tilt tension, and vice-versa.
Adjust such that minimum effort is required to push back when recline.
Armrest Height
D
Press the button and raise or lower the armrest. Adjust height to adequately
support elbows to take strain off shoulders.
Armrest Width
E
Turn bottom knob clockwise to loosen the armrest and adjust inwards or
outwards to suite your shoulder width.
Armpad Angle
F
Grasp armpads and rotate them inwards or outwards to adjust elbow support
to suite specific tasks. An inward position works during keyboard use, while
an outward position is recommended during mousing.
Armrest Depth
G
Grasp armpads and push them forwards and backwards to suite your arm
support.
Headrest Height
(Only applicable for 879 model)
H
Adjust height by holding both sides of headrest and pull up or down to your
desired height.
H
F F
G
D
B
C C
E
