- Page 1 Assembly Assembly Instruction Instruction M8 X16mm M8 X16mm M6 X25mm M6 X25mm M6 X25mm M6 X25mm M6 X30mm M6 X30mm Models Models 891 NA A37 B 891 NA A37 B...
- Page 2 Assembly User Instruction Instructions Armrest Height Press the button and raise or lower the armrest. Adjust height to adequately support elbows to take strain off shoulders. Models Armrest Width M8 X16mm 891 NA A69 B Turn bottom knob clockwise to loosen the armrest and adjust inwards or M6 X25mm outwards to suite your shoulder width.
- Page 3 Assembly User Instruction Instructions Seat Height Adjustable Flip up lever on right-side to raise or lower seat. Adjust such that your feet are adequately supported on floor. Models Multi-Position Tilt Lock 899 YJ A37 VP Recline to desired position, and turn lever anti-clockwise to lock. Turn lever M8 X16mm clockwise to release tilt-lock.
- Page 4 Assembly User Instruction Instructions Seat Height Adjustable Flip up lever on right-side to raise or lower seat. Adjust such that your feet are adequately supported on floor. Models Multi-Position Tilt Lock 899 YJ A69 VP Recline to desired position, and turn lever anti-clockwise to lock. Turn lever M8 X16mm clockwise to release tilt-lock.
- Page 5 Assembly User Instruction Instructions VELO Seat Height Adjustable Flip up lever on right-side to raise or lower seat. Adjust such that your feet are adequately supported on floor. Models Multi-Position Tilt Lock 899 YM A69 VP M8 X 16mm M6 X 25mm Recline to desired position, and turn lever anti-clockwise to lock.
- Page 6 Assembly Assembly Instruction Instruction M6 X 20mm M6 X 20mm M6 X 20mm M6 X 20mm M6 X 20mm M6 X 20mm VELO VELO Models Models 891 NA A15 B 891 NA A15 B M8 X 16mm M8 X 16mm...
