AKO -52044 Manual

AKO -52044 Manual

Gsm alarm
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
es
fr
5204H401 Ed.05
en
de
AKO-52044
GSMAlarm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AKO-52044 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AKO AKO-52044

Summary of Contents for AKO AKO-52044

  • Page 1 5204H401 Ed.05 AKO-52044 GSMAlarm...

  • Page 2: Table Of Contents

    Complying with and enforcing the regulations applying to installations where our products are destined to be used is the responsibility of the installer and the customer. AKO Electromecànica accepts no liability for damage which may occur due to failure to comply with these regulations.

  • Page 3: Introduction

    2.- Versions and references MODEL DESCRIPTION INCLUDED GSM Alarm module AKO-52044 AKO-520441 Optional external antenna with 2 m of cable 3.- Maintenance and warnings Clean the surface of the equipment with a soft cloth, water and soap. Do not use abrasive detergents, petrol, alcohol or solvents.

  • Page 4: Equipment Description

    5204H401 Ed.04 4.- Equipment description Power supply LED LEDs for inputs/outputs SIM card cover Coverage LED LEDs for inputs Power supply input External antenna Relay outputs Digital inputs Reset 4.1.- LED indicators Coverage LED Green constant: Connected, good signal. Green flashing: Connected, weak signal. Red flashing: In the process of connecting/No signal.

  • Page 5: Installation

    5204H401 Ed.04 5.- Installation Figure 1 Fig. 1a Fig. 1b 4 8 m m Figure 2 Figure 3 Figure 4 Figure 5 IMPORTANT: Before starting to install the alarm, check that there is enough coverage in the installation place. Any manipulation of the SIM card should be done with the power supply and the battery disconnected.

  • Page 6: Wiring

    5204H401 Ed.04 6.- Wiring Always disconnect the power supply to do the wiring. The power circuit should be equipped with a switch for its disconnection of at least 2 A, 230 V, situated near the appliance.The power supply cable will be H05VV-F or H05V-K. The section tobe used will depend on current local regulations, but should never be less than 1 mm .

  • Page 7: Configuration

    For all other configuration, it is necessary only for the telephone number sending the messages to be registered on the “telephone list”. -We recommend that using the application “AKO-52044” for smartphones to carry out the configuration. It is available at www.ako.com and in the Google Play Store and Apple App Store.
  • Page 8 5204H401 Ed.04 Input configuration Allows you to configure the behaviour of the digital inputs. Send “I(n), <NC/NO>, <persistence time>, <message>” Number of the input to be configured. <n> Defines the input polarity: NO: Normally open, the alarm is activated on closing. <NC/NO>...

  • Page 9: Operation

    -No accents, umlauts or special characters may be used. -We recommend that using the application “AKO-52044” for smartphones to carry out the configuration. It is available at www.ako.com and in the Google Play Store and Apple App Store.
  • Page 10 5204H401 Ed.04 Control of relays You can activate or deactivate the output relays at will, by sending SMS messages, which allows you to remotely act on the facility. To change the status of the relays, send “RELES, <Relay 1 status>, <Relay 2 status>”. Relay statuses: Example: To activate relay 1 and deactivate relay 2, send: RELES,1,0...

  • Page 11: Queries And Errors

    5204H401 Ed.04 9.- Queries and errors Telephone list query Allows you to see the current telephone list of the alarm. Send “PHONELIST” PHONELIST SEND After a few moments, the alarm responds with a message similar to this one*: PHONELIST,5,609111111 #609222222#609333333#609444444 #609555555#609666666#609777777 #609888888#609999999#609000000 Maximum confirmation time in minutes;...
  • Page 12 5204H401 Ed.04 Status query To query the unit status at any time, send “STATUS”. Send “STATUS” STATUS SEND After a few moments, the alarm responds with a message similar to this one*: INPUT1: NO ALARM INPUT2: ALARM INPUT3: NO ALARM INPUT4: NO ALARM OUTPUT1;...
  • Page 13 5204H401 Ed.04 Alarm History query Allows the latest 40 alarms recorded by the computer, and if they have been confirmed, to be consulted. To see the last 4 alarms send "LOG,01" LOG,01 ENVIAR After a few moments, the alarm responds with a message similar to this one: 01/08/2016 15:35:15,I2,NO,666777888 01/08/2016 15:45:15,I2,OK,666555444 12/08/2016 18:02:18,AC,OF,666444888...

  • Page 14: Application

    “AKO-52044” available at www.ako.com, in Google Play Store and in Apple App Store. -Use of the application “AKO-52044” involves the sending of SMS messages by both the alarm and the user of the application. Please check the cost of this service with your operator.
  • Page 15 5204H401 Ed.04...
  • Page 16 5204H401 Ed.04...
  • Page 17 AKO ELECTROMECÁNICA , S.A.L. Avda. Roquetes, 30-38 08812 • Sant Pere de Ribes. Barcelona • Spain. www.ako.com Nos reservamos el derecho de suministrar materiales que pudieran diferir levemente de los descritos en nuestras Hojas Técnicas. Información actualizada en nuestra web.

This manual is also suitable for:

Ako-520441
