  • Page 1 5572H402 Ed.03 AKO-55624 AKO-55724 Gas Leak Detection Alarm User Manual...

  • Page 2: Table Of Contents

    Only qualified personnel should install or perform technical assistance on this product. This product is designed to be used in the applications described in the product manual. AKO Electromecánica gives no guarantee of its operation in any use not foreseen in the manual, and is not responsible for any damage resulting from improper use, configuration, installation or commissioning.

  • Page 3: Versions And References

    NIVELES POR DEFECTO 2 SET OF LEVELS DETECTOR GASES DETECTED PRE-ALARM ALARM PRE-ALARM ALARM AKO-57613 R-717 (NH / ammonia) 500 PPM 1000 PPM R-134a, R22, R-404A, R-407A, R-407C, R-407F, R-409A, R-408A, R-410A, R-422A, R-422D, R-424A, AKO-57614 500 PPM 1000 PPM...

  • Page 4: Equipment Description

    Pressing briefly deletes saved alarms (See page 11). For gas pre-alarm / alarm, pressing briefly silences the alarm tone. During the input auto-detection process (See page 10), pressing briefly alternates between the 2 or 4 area operation modes (Only AKO-55724).

  • Page 5: Warnings

    5572H402 Ed.03 3.- Warnings Transmitters / detectors measure gas concentration at a given point. If the gas leak does not reach the Ÿ transmitter / detector, the alarm will not be activated. Transmitters / detectors cannot supervise areas. If perimeter supervision is required, several transmitters / Ÿ...

  • Page 6: Alarm Station

    5572H402 Ed.03 Alarm Station -Remove the bezels (1) from the device. -Loosen the screws (2) with a 1/4 turn and open the cover (3). -Drill the holes needed for the cable entry glands using the pre-stamped centres on the sides of the housing for guidance.

  • Page 7: Wiring

    Be sure to comply with current local regulations. AKO-55624 Pre-alarm jumper Pre-alarm disabled 100 - 240 V~ Pre-alarm 50/60 Hz enabled Gas transmitter AKO-575xxx Input x RS485 Gas Fail system failure Remote Remote mute...
  • Page 8 5572H402 Ed.03 AKO-55724, configuration for 2 areas 2 or 4 area configuration is defined during initial configuration (See page 10) Pre-alarm jumper Pre-alarm disabled 100 - 240 V~ Pre-alarm 50/60 Hz enabled Gas transmitter AKO-575xxx Input x RS485 Gas Fail...
  • Page 9 5572H402 Ed.03 AKO-55724, configuration for 4 areas 2 or 4 area configuration is defined during initial configuration (See page 10) Pre-alarm jumper Pre-alarm disabled 100 - 240 V~ Pre-alarm 50/60 Hz enabled Gas transmitter AKO-575xxx Input x RS485 Gas Fail...

  • Page 10: Configuration

    5572H402 Ed.03 6.- Configuration Alarm Station AKO-55624 No configuration needed AKO-55724 input auto-detection function facilitates station configuration. It is only necessary to follow these steps: Step 1 When receiving a power supply for the first time, the alarm enters INPUT AUTO-DETECTION MODE, lighting up the input indicators sequentially in green.

  • Page 11: Operation

    5572H402 Ed.03 7.- Operation No alarms The input indicators are green. Pre-alarm / alarm activated The station emits an audible alarm sound, shows the affected input(s) in red, the general alarm indicator illuminates and the visual alarm flashes. Wiring error / malfunction The station emits 3 short beeps every two minutes and the affected input indicator flashes red.
  • Page 12 5572H402 Ed.03 Gas Relay Fail This relay will be activated if a functioning error is detected in any input with connected gas transmitters / detectors. Connecting a GSM to it is recommended, to remotely warn of the fault. Alarm Station Status Alarm level Pre-alarm...

  • Page 13: Connectivity

    Once modified, the original address indicated on the plate will no longer be valid. AKO-5012 AKO-80039 AKO-80039 Tr-: Yellow RS-485 >25 ** Tr+: Orange GND: Black CAMRegis AKOGAS AKOControl* AKOALARM SECURE AKOControl* AKOCORE CONTROL Terminating resistors are not required *AKO controller with communication **AKO-80024 Use if connecting more than 25 devices...

  • Page 14: Technical Specifications

    Sound power..........................90 dB(A) at 1 metre MODBUS address..........................Shown on label Dimensions...................290 mm (W) x 141 mm (H) x 84.4 mm (D) 10.- Accessories Calibration tool for AKO-58110 transmitters Allows for verification (bump test), field calibration and reset to zero of AKO-575xxx gas transmitters.
  • Page 15 5572H402 Ed.03 AKO-58120 protector Protects the AKO-55326 push-button / AKO-575xxx gas transmitter / AKO-5761x gas detectors from potential impact. AKO-58500 CAMM Module In combination with the application for mobile devices, it provides the device with multiple functionalities: - Data logging...
  • Page 16 AKO ELECTROMECÁNICA , S.A.L. Avda. Roquetes, 30-38 08812 • Sant Pere de Ribes. Barcelona • Spain. Tel.: +34 902 333 145 Fax: +34 938 934 054 www.ako.com We reserve the right to supply materials that might vary slightly to those described in our Technical Sheets. Updated information is available on our website.

This manual is also suitable for:

55724
