  • Page 1 .CZ`<<`.HC .CZ`Ve`.HCZ |› |ê ’ | ¼ ä¼| á qT< á qT< á qT<...
  • Page 2: Table Of Contents

    .CZ`<<`.HC Content Page The chapter entitled „Installation“ is intended for qualified contractors. General Note Intended use Read these instructions carefully Safety instructions before using the appliance and retain them 1 General CE designation Test symbols for future reference. Only a qualified contractor should carry out Instructions, standards and regulations Pass on the instructions to a new user if Appliance description...
  • Page 3: Appliance Description

    1.6 Appliance description Special features for the WPL 10 IK The appliance is an air source heat pump The WPL 10 IK includes the heat pump that operates as a heating heat pump. The manager WPM II as standard. It also includes appliance extracts heat from the outdoor air at an integral central heating circulation pump, a low temperature level and transfers it to the...
  • Page 4: Specification

    2 Specification 2.1 Specification triplephase Output details apply to new appliances with clean heat exchangers. The power consumption of the integral auxiliary drives is stated as a maximum and may vary, subjectto operating point. The power consumption of the integral auxiliary drives is already included in the output details of the heat pump, as specifi ed by the EN 14511. qT<...
  • Page 5 Flow rate, heat source side m³/h 1200 1200 1200 Internal pressure differential Total available external pressure differential 2.2 Mindestabstände Internal installation WPL 10 IK External installation WPL 10 A • • • • Internal installation WPL 10 I • • •...
  • Page 6: Installation, Connection And Sound Emissions

    2.3 Output diagram for heat pump WPL 10 A / I / IK The heat pump must be accessible from all sides. With external installations, water and electrical pipes/cables can be routed into the heat pump from below, i.e. through the knock-outs in the floor of the refrigeration...
  • Page 7 Internal installation External installation Air outlet ‘ Air inlet  Air inlet Air outlet 6FKODXFKDQVFKOXVVSODWWH Fig. 2 Fig. 3 Internal installation ‘ PD[  PLQ  Air outlet Air inlet Fig. 4...
  • Page 8: Heating Water Connection

    z The floor area of the installation room must Foundation for external installation when using pressure hoses be at least 3 m², and the room must provide a volume of 6 m³ (minimum). z When installing the heat pump in a boiler room together with other heating equipment ensure, that the operation of other heating equipment will not be...
  • Page 9 control (inside the heat pump), which automatically starts the circulation pump in the heat pump circuit at + 8 °C and thereby safeguards circulation in all water-bearing components, offers additional frost protection. The heat pump is started automatically no later than when the temperature inside the buffer cylinder drops below + 5 °C.
  • Page 10: Circulation Pump

    For the installation of a heat meter observe, that most heat meters cause a substantial pressure drop; therefore size the circulation pump larger. Heat pump WPL 10 A / I / IK Nominal volume flow m³/h Pressure drop Heat pump SBP 700 + WPKI 5 Pressure hose 1¼”...
  • Page 11: Buffer Cylinder

    Subject to wall structure, use suitable rawl cylinder pump terminal. Flow sensor connection plugs and screws to fix the wall mounted When using the WPL 10 A and the WPL 10 I, connecting plates. connect the flow sensor B1, which is an 3.7 Heat source 2 integral part of the heat pump, to the WPM II.
  • Page 12: Electrical Connection

    Use only cables suitable for outdoor use to fuses, etc. on site. VDE 0100 [or local regulations]. Connection WPL 10 A and WPL 10 I Route such cables through a conduit The terminals are located inside the WPL (protective pipe); entry into the heat pump control panel (Fig.
  • Page 13 Electrical connection WPL 10 IK 3/N/PE~400/50 1/N/PE~230/50 3/N/PE~400/50 Control Mains X26 (earth) 1/N/PE~230/50 3/N/PE~400/50 WPL 10 A WPL 10 I 3/N/PE~400/50 Control Mains Control terminals Mains supply: L, N, PE Outputs: KOKP Collector circuit pump and N, PE Mains Mixer circuit pump and N, PE...
  • Page 14 Fig. 13...
  • Page 15 Fig. 14...
  • Page 16 Electrical connection diagram for heat pumps WPL 10 A and WPL 10 I with heat pump manager WPM II Heat pump manager WPM II PD[  $ JO 1/N/PE ~ 50Hz 230 V  $ JO Supply from the domestic meter...
  • Page 17: Commissioning

    WPM II. WPM II The heat pump operates under automatic Since the WPL 10 A, I and IK are heat control and requires no specific maintenance. pumps with internal HS 2, please observe the If heat meters are installed, frequently clean WP type 2 when reading the description of their strainers, which block easily.
  • Page 18: Troubleshooting

    OFF position. The heat pump can only be error list (parameter 48) of WPM. Operation for the WPL 10 A/I/IK to 1. operated when the switch is in this position. can recommence 10 minutes after the fault has 1 Single compressor with internal HS 2 been removed;...
  • Page 22 Warranty The warranty conditions of our German companies do not apply to appliances acquired outside of Germany. In countries where our subsidiaries sell our products, it is increasingly the case that warranties can only be issued by those subsidiaries. Such warranties are only granted if the subsidiary has issued its own terms of warranty.
