Cuisinart GAS2556AS Conversion Instructions

Natural gas conversion
Hide thumbs Also See for GAS2556AS:

Advertisement

Table of Contents

Natural Gas Conversion
Instructions for Model GAS2556AS
Natural Gas Conversion Kit Sold Separately
Use Cuisinart Natural Gas Conversion Kit
PROFESSIONAL INSTALLATION MANUAL
WARNING
NOTICE TO
HAZARDOUS EXPLOSION MAY RESULT IF THESE
PROFESSIONAL INSTALLER:
WARNINGS AND INSTRUCTIONS ARE IGNORED. READ
AND FOLLOW ALL WARNINGS AND INSTRUCTIONS IN
LEAVE THESE INSTRUCTIONS WITH THE
THIS MANUAL TO AVOID PERSONAL INJURY, INCLUDING
GRILL OWNER FOR FUTURE REFERENCE .
DEATH OR PROPERTY DAMAGE.
ASSEMBLY AND OPERATING IN STRUC TIONS
SAVE THIS MANUAL FOR FUTURE REFERENCE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GAS2556AS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cuisinart GAS2556AS

Summary of Contents for Cuisinart GAS2556AS

  • Page 1 Natural Gas Conversion Instructions for Model GAS2556AS Natural Gas Conversion Kit Sold Separately Use Cuisinart Natural Gas Conversion Kit PROFESSIONAL INSTALLATION MANUAL WARNING NOTICE TO HAZARDOUS EXPLOSION MAY RESULT IF THESE PROFESSIONAL INSTALLER: WARNINGS AND INSTRUCTIONS ARE IGNORED. READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS IN...
  • Page 2 IMPORTANT SAFETY WARNINGS WE WANT YOU TO USE YOUR CONVERSION KIT FOR YOUR GRILL AS SAFELY AS POSSIBLE. THE PURPOSE OF THIS SAFETY ALERT SYMBOL IS TO ATTRACT THE ATTENTION TO POSSIBLE HAZARDS AS THE GRILL IS CONVERTED AND USED AS A NATURAL GAS GRILL. WHEN YOU SEE THE SAFETY ALERT SYMBOL PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS! READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS General Warnings ............2-3 Assembly Instructions .

  • Page 4: General Warnings

    DANGER Connection should be made by a professional service technician. Supply the technician with a copy of these instructions. Incorrect connection can result in a gas leak with possibility of fi re. GENERAL WARNINGS WARNING • Never use liquid propane gas in a unit designed for natural gas. •...

  • Page 5: Assembly Instructions

    ASSEMBLY INSTRUCTIONS YOU MUST BE A PROFESSIONAL SERVICE TECHNICIAN TO CONVERT THIS GRILL. READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR OPERATING THE CONVERTED GRILL. The following tools are required to assemble the Conversion Kit: • Phillips and Flathead Screwdrivers •...
  • Page 6 CONVERSION INSTRUCTIONS GAS2556AS CAUTION: Some parts may contain GAS MANIFOLD NUT sharp edges. Wear protective gloves if necessary. Note: Make sure all control knobs are in the off position, LP tank valve is closed and tank is disconnected from regulator and removed from grill.
  • Page 7 Step 3 Remove electrodes from each burner by unscrewing the bolt. Set aside for later BOLT use. ELECTRODE Step 4 Remove cotter pins and studs from each burner “foot” . Carefully lift each burner up STUD COTTER PIN and away from valve openings. Set aside for later use.
  • Page 8 Do not remove ORIFICE this part TOOL Step 5 Use the orifi ce tool to remove the LP gas valve orifi ce from each main burner valve through the hole in the fi rebox front panel. Note: All orifi ces of the grill are double orifi ces (LP gas and natural gas).

  • Page 9: Connecting To Natural Gas Source

    Do not remove this part Step 8 Use the gas orifi ce tool to remove the LP orifi ce from side burner valve. LP GAS ORIFICE ORIFICE TOOL Step 9 Make sure all control knobs are OFF, then remove all the control knobs. Tighten screw on each control valve.
  • Page 10 CONNECTING YOUR GRILL TO THE NATURAL GAS SOURCE 1. Coat pipe nipple with gas resistant tefl on tape or pipe dope. Tighten quick-disconnect coupling onto pipe nipple that leads to natural gas supply (Figure A). 2. After grill is completely assembled, make sure natural gas supply valve is “OFF” and then connect natural gas hose to socket.

  • Page 11: Leak Testing

    WARNING • Never use your grill without leak testing all gas connections and hoses. See the section on “Leak Testing” in this manual for proper procedures. • Visually inspect the hose assembly prior to each use for evidence of damage, excess wear or deterioration.
  • Page 12 CHECKING FOR LEAKS: 1. Create a mixture of 50% water and 50% liquid dishwashing soap. Watch For Bub bles 2. Open the lid. 3. Ensure all control knobs are set to the “OFF” position. 4. Ensure gas hose is tightly connected to gas source. 5.

  • Page 13: Pre-Start Check List

    WARNING Property damage, bodily harm, severe burns, and death could result from failure to follow these safety steps. These steps should be performed after the grill has been assembled and prior to each use. DO NOT operate this grill until you have read and understand ALL of the warnings and instructions in this manual.
  • Page 14 For replacement parts, call our customer service department at 1-866-212-3150 from 9:00am to 5:00pm Eastern time, Monday through Friday for assistance. Owner’s Manual for Model INS2556AS ©2021 Fair Game Group LLC 0721, 0923 Carrollton, Texas 75006 U.S.A. GAS2556AS...
