Cuisinart GAS0256AS Assembly Instructions Manual

Deluxe two burner gas grill
Hide thumbs

Advertisement

Table of Contents

Deluxe Two Burner Gas Grill
ASSEMBLY IN STRUC TIONS
Model GAS0256AS / GAS0256ASO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GAS0256AS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cuisinart GAS0256AS

Summary of Contents for Cuisinart GAS0256AS

  • Page 1 Deluxe Two Burner Gas Grill ASSEMBLY IN STRUC TIONS Model GAS0256AS / GAS0256ASO...
  • Page 2 READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR OPERATING YOUR GRILL. WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN AS SEM BLING THIS UNIT. The following tools are required to assemble this Cuisinart 2 Burner Gas Grill: • Phillips Screwdriver PARTS LIST:...
  • Page 4 FRONT PANEL Step 1 • Remove 4 screws • Attach FRONT PANEL parts • Install 4 screws Step 2 • Loosen 10 screws • Attach FRONT LEGS • Tighten 10 screws on FRONT LEGS NOTE: Before tightening keyhole screws, make sure panels are aligned.
  • Page 5 Step 3 • Loosen 4 screws • Attach SIDE PANELS • Tighten 4 screws on SIDE PANELS Step 4 • Remove 4 screws from FRONT LEGS Remove 2 screws Remove 2 screws...
  • Page 6 Step 5 • Remove 4 screws from CART BASE CART BASE Step 6 • Attach TANK HOLDER CART BASE with 4 screws (Removed from Step 5) CART BASE...
  • Page 7 Step 7 • Attach CART BASE FRONT LEGS • Tighten 4 screws on CART BASE (Removed from Step 4) CART BASE Front of Grill Tighten 4 screws Back of Grill Step 8 • Remove 4 screws from REAR LEGS Remove 2 screws Remove 2 screws...
  • Page 8 Step 9 • Loosen 4 screws • Attach SIDE PANELS REAR LEGS • Tighten 4 screws on SIDE PANELS Step 10 • Attach CART BASE to REAR CART BASE LEGS • Tighten 4 screws (Removed from Step 8)
  • Page 9 Step 11 • Lock CASTERS • Attach CASTERS to legs CASTERS unlocked locked Step 12 • Loosen 6 screws on all 4 legs • Rotate FRONT CART BRACKETS upwards and tighten screws • Slide REAR CART BRACKETS upwards and tighten screws Front Legs Rear Legs...
  • Page 10 Step 13 • Remove 14 screws Remove 14 screws Step 14 • Set GRILL BODY GRILL BODY on cart (Use two people)
  • Page 11 Step 15 • Tighten 3 screws (Removed in Step 13) GRILL BODY Tighten screws Step 16 • Tighten 3 screws (Removed in Step 13) GRILL BODY Tighten screws...
  • Page 12 Step 17 • Attach RIGHT SIDE TABLE BRACKETS and LEFT SIDE TABLE BRACKETS GRILL BODY • Tighten 8 screws (Removed in SIDE TABLE Step 13) BRACKETS Step 18 • Remove 4 screws from SIDE TABLE BRACKETS Remove 4 screws • Attach LEFT SIDE TABLE post and replace...
  • Page 13 Step 19 • Attach RIGHT SIDE TABLE on post and replace screws through slotted hole RIGHT SIDE TABLE Step 20 • Remove 2 screws on GREASE TRAY • Move handle to outside attach with 2 screws...
  • Page 14 Step 21 • Insert GREASE TRAY GREASE CUP Step 22 • Loosen screw on HOSE HOOK and rotate horizontal • Place hose into HOSE HOOK • Tighten screw...
  • Page 15 Step 23 • Install HEAT TENTS COOKING GRATES WARMING RACK Model GAS0256AS Assembled ©2019 The Boltz Group LLC Assembly Instructions for Models AI0256AS/ASO Carrollton, Texas 75006 U.S.A. GAS0256AS / GAS0256ASO 1019...

This manual is also suitable for:

Gas0256aso
