How to Replace the Ducted Set and PCBA
Description
Switch PCBA
LED PCBA
Internal Wire Assembly
Main PCBA
Screw
Ducted Set
Fan Baffle
Air Collector
Screw
Backboard ASSY #1
Backboard ASSY #2
Backboard ASSY #3
Ducted Set
Part Number
2830326001
2830325001
4860518001
2830304001
5620479001
2825874001
2825905001
3128926001
5620479001
2825578001
2825580001
2825579001
2825874001
LBX6000 Blower
QTY.
1
1
1
1
4
1
1
1
4
1
1
1
1
26
