Ego Power+ LBX6000 Repair Manual Line page 13

Measure the PCBA, Motor and Internal Wire Assembly
1. There is 6 contactors in the socket. Contact the black pen pin to the 6 contactors and the red pen pin
to their corresponding contactors of the two connectors.
Red wire
Yellow
Black wire
connector
White wire
3
1
2
6
4 5
Internal Wire Assembly Measurement
5,6
Black
3,4
connector
2
Connectors
LBX6000 Blower
1
