Parts List - Creation Model INFINITY IF15-II Instruction Manual

Part#
A006-40 ALUMINUM WASHER 3x6x4.0mm (Black/8pcs)
B01203S M2x3mm SLIM HEAD SCREW (4pcs)
B01205 M2x5mm BUTTON HEAD SCREW (10pcs)
B01305 M3x5mm BUTTON HEAD SCREW (10pcs)
B01306 M3x6mm BUTTON HEAD SCREW (10pcs)
B01308 M3x8mm BUTTON HEAD SCREW (10pcs)
B01308F M3x8mm FLANGE BUTTON HEAD SCREW (4pcs)
B01310 M3x10mm BUTTON HEAD SCREW (8pcs)
B01312 M3x12mm BUTTON HEAD SCREW (8pcs)
B01314 M3x14mm BUTTON HEAD SCREW (8pcs)
B02206 M2x6mm FLAT HEAD SCREW (10pcs)
B02208 M2x8mm FLAT HEAD SCREW (10pcs)
B022608 M2.6x8mm FLAT HEAD SCREW (8pcs)
B022610 M2.6x10mm FLAT HEAD SCREW (8pcs)
B02305 M3x5mm FLAT HEAD SCREW (10pcs)
B02306 M3x6mm FLAT HEAD SCREW (10pcs)
B02308 M3x8mm FLAT HEAD SCREW (10pcs)
B02310 M3x10mm FLAT HEAD SCREW (8pcs)
B02315 M3x15mm FLAT HEAD SCREW (6pcs)
B032612 M2.6x12mm CAP HEAD SCREW (8pcs)
B03310 M3x10mm CAP HEAD SCREW (8pcs)
B03315 M3x15mm CAP HEAD SCREW (6pcs)
B04303F M3x3mm SET SCREW (Flat Point/10pcs)
B04305 M3x5mm SET SCREW (Cup Point/10pcs)
B04308R M3x8mm SET SCREW (Rounded End/8pcs)
B04310 M3x10mm SET SCREW (Cup Point/10pcs)
B04315 M3x15mm SET SCREW (Cup Point/6pcs)
B04404 M4x4mm SET SCREW (Cup Point/8pcs)
B04408R M4x8mm SET SCREW (Rounded End/4pcs)
B05208 2.0x8mm PIN (10pcs)
B05210 2.0x10mm PIN (10pcs)
B05212 2.0x12mm PIN (10pcs)
B06105 5.0mm E RING (10pcs)
B07302 M3 NYLON NUT (Thin Type/Black/6pcs)
B2000 SHORT ANTENNA PIPE SET (80mm/3pcs/Black)
BB10154 BALL BEARING 10x15x4mm (2pcs)
BB3625 BALL BEARING 3x6x2.5mm (4pcs)
BB4725 BALL BEARING 4x7x2.5mm (2pcs)
BB5104 BALL BEARING 5x10x4mm (2pcs)
BB5825 BALL BEARING 5x8x2.5mm (2pcs)
BB6124 BALL BEARING 6x12x4mm (2pcs)
BB6135 BALL BEARING 6x13x5mm (2pcs)
BBT5 THRUST BALL BEARING 5mm
CM-A004-05 5x7 SHIM SET (0.1, 0.2, 0.3mm each 10pcs)
CM-A004-0510 5x10 SHIM SET (0.1, 0.2, 0.3mm each 10pcs)
CM-A004-06 6x8 SHIM SET (0.1, 0.2, 0.3mm each 10pcs)
CM-A005-10 ALUMINUM WASHER 3x6x1.0mm (Red/10pcs)
CM-A005-20 ALUMINUM WASHER 3x6x2.0mm (Red/10pcs)
G001 SUSPENSION BUSHING SET
G003 BODY MOUNT SET
G004 BEARING COLLAR SET
G005 BALL END SET

PARTS LIST

Description Part#
G006 FRONT LOWER ARM SET
G007B REAR LOWER ARM SET
G008 FRONT KNUCKLE
G009B REAR HUB
G010 UPPER ARM SET
G011 CENTER BULK SET
G012 SERVO PARTS SET A
G012-1 SERVO SAVER B SET
G013 SERVO PARTS SET B
G014 FUEL TANK
G015 2 SPEED SHOE SET
G016-59 1st SPUR GEAR 59T
G017-54 2st SPUR GEAR 54T
G018 SHOCK PLASTIC PARTS SET
G019-18BK 18T PULLEY SET (Black)
G019-19BK 19T PULLEY SET (Black)
G019-20BK 20T PULLEY SET (Black)
G019-25BK 25T PULLEY SET (Black)
G019-27BK 27T PULLEY (Black)
G020BK FRONT DIFF SET (Black)
G022BK FRONT DIFF CASE SET (Black)
G023 FRONT DIFF SHIM SET
G024 DIFF GEAR O-RING (4pcs)
G025 DIFF SHAFT (2pcs)
G026 CM10 Front Diff Joint
G027BK REAR DIFF SET (Black)
G028 REAR DIFF CASE O-RING (3pcs)
G029BK REAR DIFF CASE SET (Black)
G030 REAR DIFF BEVEL GEAR SET
G031 REAR DIFF JOINT (2pcs)
G032 REAR DIFF SHIM SET
G040 1st GEAR HOUSING
G041 2nd GEAR HOUSING
G043 2 SPEED ADAPTER
G044 2 SPEED SHAFT SET
G051 MIDDLE SHAFT SET
G052 MIDDLE SHAFT MOUNT
G054 STABILIZER JOINT SET
G058 FRONT UPPER SUSPENSION MOUNT SET
G061 FRONT WHEEL SHAFT
G062 UNIVERSAL JOINT
G063 CLUTCH SET
G064 CLUTCH DISC
G065 CLUTCH BELL
G066 CLUTCH SHOE
G067 CLUTCH WEIGHT
G068 FLY WHEEL
G069 CLUTCH SPRING
G070B TAPERED COLLAR SET
G071-16 1st PINION GEAR 16T
G072-21 2nd PINION GEAR 21T
G080 STEEL BALL SCREW φ8mm (2pcs)
44 44
Description
