Hardware Installation
1.
Connect the receiver's green mouse
connector to the computer's 6-pin
PS/2 mouse port. Connect the receiv-
er's purple keyboard connector to
the computer's 6-pin PS/2 keyboard
port.
2.
Install two AA batteries in the mouse
and two AA batteries in the key-
board.
Turn on your computer.
3.
After you open Windows, please press the button under the receiver first (RB)
4.
and then press the button under the mouse (MB) and keyboard (KB) for ID
channel setting. You only have six seconds to press the receiver, the channel
button on the keyboard (KB), then the receiver button again and the channel
button on the mouse (MB). So you press RB, KB, RB, MB to set the channel
setting.
Warning:
When you use Wireless TwinTouch+ Optical on a desk that is made of metal, try
1.
using a pad or reduce the receiving distance.
2.
Before the first installation is completed (channel setting ready), the keyboard
will not work in DOS.
The Wireless TwinTouch+ Optical channel provides 256 ID-codes, and it auto-
3.
matically selects the ID # for your keyboard and mouse. You can only set up one
TwinTouch+ Optical at a time. But if you have additional TwinTouch+ Optical
sets in an area of 10 square meters, more interference may occur between the re-
ceiver and your keyboard and mouse.
If you feel the mouse does not move smooth as usual or the keyboard does not
4.
work when typing, then the batteries have lost their charge, so please replace
them. Also, the wireless icon will be blinking "red" when there is a battery-
low situation. You should set up the channel every time you replace the bat-
terires.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Genius TWINTOUCH PLUS OPTICAL
Summary of Contents for Genius TWINTOUCH PLUS OPTICAL
- Page 1 You only have six seconds to press the receiver, the channel button on the keyboard (KB), then the receiver button again and the channel button on the mouse (MB). So you press RB, KB, RB, MB to set the channel setting.
- Page 2 (about 20 cm) away from the mouse and other electrical devices, such as the computer, monitor, and etc. Please do not use this optical mouse on a desk which is made of glass, mirror, iron, or black velvet. Also, a flat surface is necessary or the optical sensor will not work properly.
- Page 3 Roller ButtonYou can assign this button frequently used keyboard and mouse func- tions in addition to features like EasyJump, Auto-Panning, Zoom, etc. Side Buttons You can assign certain functions (Application/Document, Horizontal Scrol, Last/Next Page, and Zoom in/out) to the upper or lower side button with the roller.
- Page 4 Double Click mouse. Speed Swap Left/Right Select this option if you want to have the mouse operate with the right mouse button as the primary button. Pointers Folders This lets you change the shape of the cursor. Only supports Microsoft Office along with some new ap- Office Mode plications.
- Page 5 Press the “Ctrl” key and move the “Magic-Roller” forward (or backward) to set the Zoom In/Out function. You can also use just one hand to Zoom In/Out: set the right button to be the “Ctrl” function, press the right button and move the “Magic-Roller”...
