Chapter 1: Introduction

This new Genius TVGo A31 is the ideal medium for you to watch TV or
video or your TFT / LCD / CRT monitor in up to 1280 x 1024 pixel. This
TV/ Video box lets you enjoy different types of entertainment anywhere.
With the PIP (picture in picture) re-sizing feature, you can work on your
PC and still watch your favorite TV or video programs
It also includes great features that high-quality TV's provide. The
multi-language on screen display (OSD) can guide you through all it
functions. You can also connect the TVGo A31 to a DVD player, VCD
player, camcorder or Video Game, so you can experience more visual
and audio entertainment.
1.1 Package Contents
Please confirm the following parts are included when you open the
package. If not, please contact your distributor or dealer.
TVGo A31 TV Box.
IR remote controller
AC adapter
VGA-In loop back cable (for PIP mode use)
Audio cable for connecting to PC sound system
User's Manual
English
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the TVGO A31 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Genius TVGO A31

  • Page 1: Chapter 1: Introduction

    This new Genius TVGo A31 is the ideal medium for you to watch TV or video or your TFT / LCD / CRT monitor in up to 1280 x 1024 pixel. This TV/ Video box lets you enjoy different types of entertainment anywhere.
  • Page 2 English 1.2 System Requirements • Display unit CRT / LCD with Standard VGA connector (D-Sub 15 pin). A PC system is necessary when PIP mode is needed. • RF antenna signal or CATV signal. • Independent of OS (operating system), no software driver installation or HDD space is needed.
  • Page 3: Chapter 2: Getting Started

    English Chapter 2: Getting Started 2.1 Rear panel connectors The most typical connection is shown below; follow it to make a correct connection, make sure all systems are in power off situation. CONNECTOR TYPE DESCRIPTION 5mm, INT+, AC adapter, power in (5V,...
  • Page 4 English TV antenna TV or CATV signal in connector connector。 2.2 Right Side panel connectors CONNECTOR TYPE DESCRIPTION 5 pin Min S-VHS type external video input source. Can S-Video In connector be connected to DVD, VCR or Camcorder.。 RCA JACK...
  • Page 5 English 2.3 Wire connection It contains a built in speaker, it is designed in case you didn’t turn on the PC system’s power. If you intend to use the original sound system, the built in speaker can be automatically disabled by plugging it in the audio loop cable as above.
  • Page 6: Chapter 3: Use The Box

    It comes with one 3.5 mm to “Y” type splitter audio connector. If it is used as input cable, at the rear panel, for the audio output, users need to have an extra audio connector or use the audio loop cable to connect to the PC sound system.
  • Page 7 English the full screen program. Used as standalone TV box, it has nothing to do with the PC system VGA setting. You can manually check the CRT/ LCD display mode setting if you want, but you don’t need to worry about the PC’s VGA’s resolution setting.
  • Page 8 1024x768. 3. Click on the “Advanced” button, to select the monitor refresh rate, the recommended value is 75Hz 4. Click on OK to close the property page. 5. Windows system will change the display mode to your setting and ask whether to use this display mode or not, please click on ok to confirm the setting.
  • Page 9 Chapter 4: Using the Remote Control The Remote control allows you to operate this box, such as turning your TV on / off, viewing the TV, and changing the channels and volume. Aim the front of the Remote Control at the Remote Control Receiver and press the control buttons as you would on the infrared ray receiver.
  • Page 10 VOL+: Volume Up. VOL-: Volume Down. MENU: When in [full screen TV mode], pop out the MENU for further setting. When in [PIP PC mode], use to allocate PIP position in conjunction with CH+/-, Vol +/- key. OSD: On Screen Display.
