Chapter 1: Introduction
Introduction:
TVGo A11 turns your PC into a TV set. No need to buy an additional TV in your home as this
will save both space and electric consumption. It lets you watch TV or listen to the radio on
your PC, so it is really a great device for yourself and your family. Another outstanding
advantage is that " TVGo A11 is compatible with Windows XP Media Center Edition 2005.
TVGo A11 combines a TV tuner, video capture and video conferencing functions all in one
card. It features unparalleled control like the 16-channel preview, FM radio listening, real-time
and schedule recording in MPEG-1/2/4 format. You can also capture a video image you like
and turn it into wallpaper on your PC.
Hook up your TVGo A11 to a VCR / Video Camera and enjoy home videos and convert them
to digital format or save a snapshot for decorating your desktop. With the TVGo A11, you can
have more fun and enjoyment while you work on your PC.
Features:
•
Compatible with MCE (Media Center Edition)
•
Watch analog TV and listen to FM radio on your PC
•
Real-time recording in MPEG-1/2/4 format
•
PC auto boot function
•
Supports still image capture and channel preview
•
Supports Time Shifting and schedule recording
1
English
Advertisement
Table of Contents
Related Manuals for Genius TVGO A11
Summary of Contents for Genius TVGO A11
-
Page 1: Chapter 1: Introduction
Introduction: TVGo A11 turns your PC into a TV set. No need to buy an additional TV in your home as this will save both space and electric consumption. It lets you watch TV or listen to the radio on your PC, so it is really a great device for yourself and your family. -
Page 2: Package Contents
Quick Guide 1 .2 System Requirements • P 3 800 (for preview); P4 1.6 or above (MPEG 4 needs 2.4) (for record) • M inimum 64 MB memory • M inimum 100 MB hard disk space available •... -
Page 3: Chapter 2: Getting Started
“AUDIO IN”. Caution: Please take special care on the Remote sensor cable, don’t plug in or remove the sensor cable while the PC system is in Power on state. Otherwise, it may cause TVGo A11 hardware failure. -
Page 4: Device Driver Installation
2.3 Device Driver Installation 1. Place the CD software in the CD-ROM drive, and then prepare the driver installation. 2. Once you connect the TVGo A11 to the PCI slot, can just follow the system’s prompted message to finish the driver installation. - Page 5 English 5. Select “Search for a suitable driver for my device [recommended]” and click “Next”. 6. Select “CD-ROM driver” and click “Next” button to search driver. 7. Click “Yes” to continue the installation. 8. Click “Finish” button to finish the...
- Page 6 English 9. The system will detect one “Unknown” device. 10. Please click “Next” to continue. 11. Select the first option “Search for the best driver for your device (Recommended)”, and click “Next” to continue. 12. Select the option “CD-ROM device”...
- Page 7 English 13. Click “Next” button to copy the driver. 14. Click “Yes” to continue install the “TVGo A11 WDM TV Tuner ” driver. 15. Click “Finish” to complete the installation. 16. Check your driver from Device Manager after installation.
-
Page 8: Install Directx
2.4 Install DirectX Microsoft DirectX allows 3D hardware acceleration support in Windows 98, ME, 2000, and Windows XP. For software MPEG support in Windows 98, you must first install Microsoft DirectX, and then an MPEG compliant video player. 1. Insert the installation CD into the CD-ROM drive. - Page 9 English 2.5 Install TVGo A11 utility software. 1. Insert the installation CD into the CD-ROM drive. The setup will automatically appear. 2. Click “Setup Utility”. 3. Click “Next” button to start installing. TV Go A11 4. Please read the License Agreement and click “Next”...
- Page 10 English 6. Click “Next” button to start “Teletext” installation. 7. Click “Next” button or choose different folder for installation. 8. Click “Next” button or choose different folder for installation. 9. Click “Finish” to complete “Teletext” installation.
-
Page 11: Chapter 3: Launch The Software
11. Click “OK” to restart your system Chapter 3: Launch the Software 3.1 Running the TVGo A11 for first time. Click Start on Windows Taskbar, and then select Programs\TVGo A11\ TVGo A11 At the first time running, please choose your country and language as below... - Page 12 English 1. Although the TV tuner on your TVGo A11 is fixed, you have to set up the TV system right after the first time you launch TVGo A11. 2. Set the video and snapshot format and save as. 3. Please choose your country and Tuner Input type then click “Search”.
- Page 13 3. Channel List: This is listing all available TV channel. 4. Channel control: Set channel up or down 5. Source Switch: click it to select TV, Video In or S-Video In 6. Volume control: Adjust the Volume or mute. 7. Search TV channel: click to search available TV channel.
-
Page 14: Record Video
English 3.3 Record Video Click the “Setting” button to setup the record format. Setup the video format. Click “Record” button to start to capture video. 3.4 Snapshot Image Click the “Setting” button to setup the image format. TVGo A11 supports BMP and JPEG image... -
Page 15: Playback Video
3 Minimize: To minimize the video playback window, click "MoviePlayer" in desktop taskbar to restore display 4 Hide Control Panel: To hide video control panel, right click video window and select "Control Panel" to restore display 5 Setting: Click to pop-up setting dialog, you can test the video playback, for detailed operation, please refer to "Playback Setting"... -
Page 16: Browse Image
"Playback Setting" page 18 Play List: Click to pop-up sub panel below main panel, the default list for the record file is under the record directory, from which you can select the needed item to play. -
Page 17: Listen To Fm Radio
English Match Zoom: You can select the matched display mode in the right dropdown box. Full Size: Shows image at 100% magnification Fit Image: Magnifies image to fit screen or window Fit Width: Magnifies image to fit width of screen or window Fit Height: Magnifies image to fit height of screen or window Lock: Locks the viewer at the current magnifying level. -
Page 18: Chapter 4: Using The Remote Control
The Remote control allows you to operate TVGo A-11, such as turning your TV on/off, viewing the TV, and changing the channels and volume. Aim the front of the Remote Control at the Remote Control Receiver and press the control buttons as you would on the infrared ray receiver.
