Chapter 1 Introduction of TVGo DVB-T02Q
1.1 Introduction
The TVGo DVB-T02Q can turn your notebook or desktop PC into a personal digital TV
and let you watch high definition free-to-air DVB-T TV on your notebook or desktop PC.
The compact size design makes it easy for you to take it anywhere and real-time record
the TV programs to DVD disc in DVD format. With the remote controller, you can easily to
watch TV and record, also playback high quality digital video programs on your NB or PC
and channel preview. These functions supported by TVGo DVB-T02Q make this a
product you don't want to miss.
1.2 Package contents:
- TVGo DVB-T02Q x 1
- Remote Controller (includes battery) x 1
- Portable Digital Terrestrial TV Antenna x 1
- Software Disc x 1
- Quick Installation Guide x 1
- Switching Head x 2 (IEC Type*1 and MMXC Type*1)
Notice: We highly recommend you use the outdoor antenna for better signal reception
1.3 Features of TVGo DVB-T02Q
Watch worldwide free-to-air digital HDTV and SDTV TV programs and free-to air
digital radio
Powered by USB2.0 cable (compatible with USB1.1)
Supports time-shifting functions to avoid missing any TV programs
Supports real-time recording and schedule recording to hard disk
Supports real-time recording to DVD disc in DVD format (For using this function,
you need a DVD writer on your PC or NB)
Supports snapshot function that lets you capture your favorite images from
programs and turn it into wallpaper for your PC or NB
Supports EPG (Electronic Guide program) and Teletext function
1
English
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Genius TVGO DVB-T02Q
Summary of Contents for Genius TVGO DVB-T02Q
-
Page 1: Chapter 1 Introduction Of Tvgo Dvb-T02Q
The compact size design makes it easy for you to take it anywhere and real-time record the TV programs to DVD disc in DVD format. With the remote controller, you can easily to watch TV and record, also playback high quality digital video programs on your NB or PC and channel preview. -
Page 2: Chapter 2 Installation
TVGo DVB-T02Q to your PC or NB. 2.1 Brief introduction on hardware installation 1. USB Interface: USB port used to connect TV pen driver and PC / NB 2. Antenna RF-In: Connect to Terrestrial antenna... - Page 3 Connect the USB port and the TVGo DVB-T02Q as shown below. Step 2. Connect the antenna signal line First connect the TV antenna signal line to the IEC-MMXC switch head. Second, connect the IEC-MMXC switch head to TVGo DVB-T02Q RF-IN as shown below.
- Page 4 2. Please put into the software disc into your CD-ROM drive. The following window will pop up automatically. If you do not see this window above, please manually run “setup.exe " from the software disc. 3. After entering WINDOWS, select “Driver Setup” to install driver and application. Then the following window will pop up.
- Page 5 6. Please select “Next” to continue installing and choose the desired file folder to install and go to next step. 7. Please choose “Next” to continue installing according to the instruction, or “Back” to return to the last step and choose the suitable file folder to install. Or choose “Cancel”, to stop the installation.
- Page 6 English 8. The installation procedure is copying the driver to your PC or NB. You can choose “Cancel” to stop the installation procedure. 9. After the installation is done, click on “Yes, I want to restart my computer now.”, Then click and select “Finish” to complete the installation procedure.
-
Page 7: Chapter 3 Introduction Of The Software
English Chapter 3 Introduction of the software It offers the strong and exhaustive function for one high-level digital TV player. Through it, you can enjoy exciting high-resolution, high-quality video and audio TV play back. 3.1 Control panel Control Panel without Numerical Keypad... - Page 8 Live TV recording Record the TV program you are watching now. Be careful! You can record to DVD disc directly if you have a DVD writer. Please check the Q&A for the list of the DVD writer support. Schedule TV recording Set the TV recording schedule.
- Page 9 Note: This depends on whether the TV channel offers this information or not. You can click PageUp or PageDown to go up or down one page. Just click Pause to hold the current page. You can also click Home to jump to page 100 or fill the page number into GoTo field to select page.
- Page 10 English 3.4 Functions supported by mouse Click the right button of the mouse and you will see the following menu pop up. Function Function description Channel up TV channel up Channel down TV channel down Channel return Play the previous TV channel...
-
Page 11: Chapter 4 System Configuration
1. The digital TV has a characteristic called cliff effect. If the receiving free-to-air terrestrial signal is bad, you will not see the video image at all. This is unlike analog TV, for analog TV you can still watch TV in unclear video image. If the signal in your area is bad, you need to have an external outdoor antenna. - Page 12 4.1.2 Scan channels by single frequency 1. Please click and select "Bandwidth". 2. You can select the bandwidth you want to scan. (" 6 ", or " 7 ", or " 8 ", or " 7, 8 ", or " 6, 7, 8 ") 3.
-
Page 13: Video Setting
4.1.3 Scan channels by frequency range 1. Please click and select "Bandwidth". 2. You can select the bandwidth you want to scan. (" 6 ", or " 7 ", or " 8 ", or " 7, 8 ", or " 6, 7, 8 ") 3. - Page 14 4.3 Configuration for Record / Time shift DVD Burning You can select this option to record the program into DVD disc directly. Please configure the following option fields after you select DVD burning. Note: For using this function, you need a DVD writer on your PC or NB Path: You need to specify your DVD read/write drive in this field.
- Page 15 English DVD Menu: You can configure the DVD menu style you like through the DVD Menu. After you click this button, the following sub-menu will pop up. 1. Select Style: You can choose between NTSC and PAL for recording video format.
- Page 16 If you need to leave temporarily for some reason when watching a TV program, you can use this function to store the program at this moment and playback when you return.
- Page 17 Starting Time: You can choose to make an appointment to make video recording by filling in the starting time here. Note: You must type in a time, which is ahead more than one minute from the present time. Recording Period: You can type in the recording length here.
- Page 18 After you click "Add" button, you can set a new schedule-recording job. Once all the data is filled in correctly, you can click the “Save” button. The following window will pop up to show you the status of these jobs.
-
Page 19: Chapter 5 Uninstall Tvgo Dvb-T02Q
3. Please make sure that the application “TVGo DVB-T02Q Monitor” is running now. Chapter 5 Uninstall TVGo DVB-T02Q 1. Please put the software disc of TVGo DVB-T02Q into your CD-ROM drive. You will see this window appear automatically after you put in the disc. - Page 20 2. Click "Remove", the InstallShield will uninstall TVGo DVB-T02Q from your system. 3. Please select and click the button "Yes (Y) ". 4. After the uninstallation is done, please select “Yes, I want to restart my computer now.”, Then click “Finish” to complete the uninstallation procedure.
- Page 21 While installing the driver, please confirm TVGo DVB-T02Q installation disc is put correctly in your disc drive. b. While you manually install the driver, make sure the path to the driver files is correct. 4. How do I Install the application software? You have two ways to start the installation procedure.
- Page 22 6. When I watch TV, the screen shows nothing or an error message. a. This could be because the signal is too weak in intensity, it is unable to display the TV program correctly. Please change the antenna location or use an external antenna.
- Page 23 13. How can I find out the terrestrial TV signal coverage in the area I live? a. If you want to know whether you can watch free-to-air terrestrial digital TV in your location, you can go to the web site below to get the information.
- Page 24 This is an optional feature. Please make sure your purchase product includes this feature. b. To use this option, your system also needs to have extra CPU power (about 300MHz) compared with recording to hard disk. c. You also need to have a DVD read/write drive to support this feature. There are a lot of DVD read/write drives on the market that have compatibility issues.
