Chapter 1 Introduction of TVGo DVB-T02PRO
1.1 Introduction
The TVGo DVB-T02PRO can turn your notebook or desktop PC into a personal digital TV and let you
watch high definition free-to-air DVB-T TV on your notebook or desktop PC.
The compact size design makes it easy for you to take it anywhere and real-time record the TV programs to
DVD disc in DVD format. With the remote controller, you can easily to watch TV and record, also playback
high quality digital video programs on your NB or PC and channel preview. These functions supported by
TVGo DVB-T02PRO make this a product you don't want to miss.
1.2 Package contents:
TVGo DVB-T02PRO
Remote Controller (includes battery)
Portable Digital Terrestrial TV Antenna
Antenna connector
Software Disc
Quick Installation Guide
Notice: We highly recommend you use the outdoor antenna for better signal reception.
1.3 Features of TVGo DVB-T02PRO
Watch worldwide free-to-air digital HDTV and SDTV TV programs and free-to air digital radio
Powered by USB2.0 cable
Supports time-shifting functions to avoid missing any TV programs
Supports real-time recording and schedule recording to hard disk
Supports continuous snapshot function that lets you capture your favorite images from programs and
turn it into wallpaper for your PC or NB
Supports EPG (Electronic Guide program) and Teletext function
PIP function: watch recorded and life TV at the same time
1.4. Minimum system requirements:
P4 2.4 GHz or above for watching HDTV TV program
P4 3.0 GHz or above for watching HDTV TV program and recording
256MB system memory size
Microsoft Windows 2000 SP4, Windows XP SP1/SP2 operating system, or Windows XP Media
Center Edition 2005, Vista
Microsoft DirectX version should be 9.0c or later
100MB available hard disk space (used by the driver and software),
3GB disk space per hour needed for TV program recording
1
English
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Genius TVGO DVB-T02 PRO
Summary of Contents for Genius TVGO DVB-T02 PRO
-
Page 1: Chapter 1 Introduction Of Tvgo Dvb-T02Pro
DVB-T TV on your notebook or desktop PC. The compact size design makes it easy for you to take it anywhere and real-time record the TV programs to DVD disc in DVD format. With the remote controller, you can easily to watch TV and record, also playback high quality digital video programs on your NB or PC and channel preview. -
Page 2: Chapter 2 Installation
English Chapter 2 Installation You can install the TVGo DVB-T02PRO easily after reading this chapter. The following sections will provide you detailed information how to install the TVGo DVB-T02PRO to your PC or NB. 2.1 Brief introduction on hardware installation 1: USB Interface for USB port used to connect TV pen driver and PC / NB. - Page 3 English 2.2 Software installation The TVGo DVB-T02PRO installation includes the application and driver; just follow the sections below to install the software. After the computer and TVGo DVB-T02PRO are connected, the following window appears. Click on “Cancel" to install the driver later.
- Page 4 English Choose “Next” to continue installing. Click “Continue Anyway” to install the hardware. After the installation is done, click on “Yes, I want to restart my computer now.” Then click and select “Finish” to complete the installation procedure.
-
Page 5: Chapter 3 Launch The Software
English Chapter 3 Launch the software 3.1 Click Start on Windows Taskbar, and then select Programs\TVGo DVB-T02PRO or double click the TVGo software icon on the desktop. 3.2 Scan channels 1. Select the small icon on the control panel to enter the setting menu. - Page 6 Notice: 1. Good reception is required for watching digital TV. In case of weak signals, digital TV will not be able to produce any pictures at all, unlike analog TV where the picture is merely unclear. If the signal is weak in your room, you may need a digital TV antenna (similar to a UHF antenna mounted on the roof) that can receive digital terrestrial signals, or the portable antenna supplied with the product to watch digital TV.
- Page 7 Select video files for playback Pause/resume video playback Stop video playback/Deactivate Time-shift Fast backward video playback on pre-recorded file or Time-shift Fast forward video playback on pre-recorded file or Time-shift Live TV recording: To record the current program you are watching, select this icon.
- Page 8 This icon indicates "Mute" status. Mute Status Bilingual Toggle: If the program supports bilingual, select this icon. It depends on the availability of the channel transmitter and program. To scan channels, change image capture properties, or change the path of recording and Time-shift.
- Page 9 TV channel signal strength status Stereo Status 3.3 Image Capture Enter setting and select Image capture page to set the frames per capture and interval between each frame. Total Frames: You can use the left mouse button to change the frames you want to capture each time.
- Page 10 You can click “Capture” again to capture another frame. You can delete the selected frames by clicking “Delete”. Or, you can use “Delete All” to delete all the frames you capture. Once you finish the selection, you can click “Save”...
- Page 11 3.5 Time-shift When you are watching a real time program and need to be out for a while, select the Time-shift button on the control panel to start recording the program from this point of time.
- Page 12 English When you are back, you can use the left mouse button to click on the scroll bar to select the point you want to watch. Or you can also use Back-ward button or Forward button to review the TV program from x2 speed and up to x32 speed.
- Page 13 English 3.7 My Favorite To use my favorite feature, you need to set up your favorite channel list first. After the setting is done, you can select the small icon on the control panel to watch your favorite programs. Select the setting icon on the control panel to enter the setting menu first.
- Page 14 My Favorite window. 3.8 Video Sub-screen You can launch another video sub-screen while you are watching live TV or video file on the main screen. You can press the button on control panel to launch the video sub-screen.
- Page 15 Live TV and Video Video and Video 3.9 The multi-function remote control ICON Explanation TV On/Off POWER Records the currently viewed TV program Channel selections … Adjust volume levels Switch up/down the TV channel Back to previous TV channel/Stop RET/STOP...
- Page 16 English 3.10 Functions supported by mouse Click the right mouse button anywhere on the TV main screen. You can see the menu pop up (pg. 17). The functions are as follows: Functions Descriptions Always On Top Set TV screen always on top...
- Page 17 30 to 60 minutes, depending on the storage space available on your hard disk. (Time-shift: When you are watching a real time program and are away for a while, use this function to start recording the program from this point of time.) To configure the schedule recording, select and click the icon on control panel to open the dialog box of “Scheduled...
- Page 18 Save: Click this button to save the newly added or modified job. After you click "Add" button, you can set a new schedule-recording job. Once all the data is filled in correctly, you can click the “Save” button. The following window will pop up to show you the status of these jobs.
- Page 19 Times: It displays how many times this schedule-recording job will take (Single/Multiple) If the settings of all schedule-recording jobs are correct, you can click "OK" to save all the changes and exit. Or click "Cancel” to give up all the changes you made and exit.
- Page 20 English 2. Check the “Enable hibernation” box under the hibernate section from “Power Options Properties”. 3. Make sure that the application “TVGo DVB-T02PRO Monitor” is running now.
