  • Page 1 Owner/Operator Manual Ser # 995-55-275 MODEL 995 Custom Eliminator Custom Eliminator...

  • Page 2: Machine Parts Breakdown

    Operating Manual Overview The purpose of this Spudnik Operating Manual is to make the user familiar with this machine and to assure the machine is used for what it has been designed to do. This Operating Manual contains important information on how to...
  • Page 3 Mission Statement Our mission is to consistently provide high quality, reliable, safe and well-designed products and services to meet and exceed the needs of our customers. Service Centers Phone: (208) 785-0480 E-Mail: spudnik@spudnik.com Web Site: www.spudnik.com...

  • Page 4: Table Of Contents

    Operator's manual MODEL 995 Table of Contents Warranty Policy ..................4 Safety ......................5 General Safety Practices ................6 Hydraulics Safety Practices ...............7 Transporting Safety Practices ..............8 Operation Safety Practices ................9 Safety Labels .....................10 Maintenance ....................12 Machine Parts Breakdown ……….……………..……………………..1 Schematics ………..................Page 3...

  • Page 5: Warranty Policy

    30 days of noticing the defect and (d) make the product available to the dealer or service center within a reasonable period of time, transportation charges prepaid. The selling dealer has no authority to make any representation or promise on behalf of Spudnik, or to modify the terms or limitations of this warranty in any way.

  • Page 6: Safety

    When you see this symbol, be alert to the possibility of injury or death. You are responsible for the safe operation and maintenance of your Spudnik Eliminator. All operators and anyone doing work or maintenance on the Eliminator must be trained in the operation, maintenance procedures, and related SAFETY information contained in this manual.

  • Page 7: General Safety Practices

    Operator's manual MODEL 995 SAFETY General Safety and Accident Prevention Regulations The primary responsibility for safe operation of the Spudnik Eliminator is with the owner/operator. OSHA (Occupational Safety and Health Administration) requires that all operator’s be OSHA (Occupational Safety and Health Administration) requires that all operator s be trained at the time of initial assignment, and annually thereafter by the employer, in the safe operation of the machine.

  • Page 8: Hydraulics Safety Practices

    Operator's manual MODEL 995 SAFETY Specific Safety Instructions Risk of injury when hitching up or unhitching machines to and from the tractor. Never allow persons to stand between the tractor and the machine unless the towing vehicle is secured against rolling away by means of the parking brake and/or chocks.

  • Page 9: Transporting Safety Practices

    Operator's manual MODEL 995 SAFETY Transporting Safety Practices Check to see if all bolts on tow tongue are in good condition, in place, and secure. Remove the pin from the towable gearbox wheel drive. Release hydraulic pressure to the elevator lift cylinder.

  • Page 10: Operation Safety Practices

    Operator's manual MODEL 995 SAFETY Operating Safety Practices Eliminator should be operated on a flat secure surface. When using leveling jacks, make sure that the jacks are on secure ground. Do not lift the wheels off of the ground. Do not allow anyone to climb on or under the Eliminator while in operation.

  • Page 11: Safety Labels

    Operator's manual MODEL 995 SAFETY Safety Labels  Keep Safety labels and signs clean and legible at all times, Keep Safety labels and signs clean and legible at all times,  Replace Safety labels and signs that are missing or have become illegible.
  • Page 12 Operator's manual MODEL 995 MAINTENANCE The hydraulic system used to power auxiliary functions uses Dexron III ATF (automatic transmission fluid) for prime mover. Hydraulic reservoir fill level should be checked at start of each season, and filled as needed. Hydraulic oil reservoir has a 5-gallon capacity.

  • Page 13: Maintenance

    Operator's manual MODEL 995 OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS 1. Center any machine that feeds the Eliminator squarely to the elevator. This allows the potatoes to spread out evenly and provides better sizing and dirt elimination. 2.Adjust the elevator to the required height to eliminate drop.
  • Page 14 Operator's manual MODEL 995 8783_CHN_ELEV 995 84"x14'6" CHN ELEV 36MM NO SKID PAN Item Quantity Title Subject Item Quantity Title Subject Number Number ANGLE, CYL. STOP, 1/4"x1-1/2"x1-1/2"x12" 172608 HOPPER,DIRT,ROLL,84",BOLT ON FRONT 8783-017 ARM,TORQUE,HYD,WHL,DRV,4 HOLE 3/8x6-1/4" 901575 KNOB,CONTROL,DIE CAST DT 5/8"-11UNC 981255 ASSY,BC,84"x11MMx36MM 2D1S CUSH 4Bx32'0"...
  • Page 15 Operator's manual MODEL 995 8783_CHN_ELEV 995 84"x14'6" CHN ELEV 36MM NO SKID PAN DETAIL A 18 52 SECTION B-B 32 20 2 16 42 45 SHEET 2 OF 2 33 15 42 Page 14...
  • Page 16 Operator's manual MODEL 995 8783-805-PB SHFT,ELIM,84",ELM/FNG RL FUL S/SPR CMPLT Item Quantity Description Part # Number BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 ROLL,RUBBER,SPACER,1/2" x 1-1/2" SQ BORE 981291 SHFT,SQ,84",ELIM,1-1/2"x82-1/4" SOLID 821555 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB)
  • Page 17 Operator's manual MODEL 995 8783-820-PB SHFT,ELIM,84",ELM/FNG RL HLF S/SPR CMPLT Item Quantity Description Part # Number BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 ROLL,RUBBER,ELIM,HALF,1-1/2" SQUARE BORE 981285 ROLL,RUBBER,SPACER,1/2" x 1-1/2" SQ BORE 981291 SHFT,SQ,84",1-1/2"x82-1/4" SLD DBL JACK 821701 SPRCKT,H60BS14x1-1/4"...
  • Page 18 Operator's manual MODEL 995 8783-855-PB SHFT,ELIM,84",ELM/FNG RL FUL D/SPR CMPLT Item Quantity Description Part # Number BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 ROLL,RUBBER,SPACER,1/2" x 1-1/2" SQ BORE 981291 SHFT,SQ,84",1-1/2"x82-1/4" SLD DBL SPRKT 821605 SPRCKT,H60BS14x1-1/4" BORE 881107 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB)
  • Page 19 Operator's manual MODEL 995 8783-860-PB SHFT,ELIM,84",ELM/FNG RL HLF D/SPR CMPLT Item Quantity Description Part # Number BRNG,2BOLT,FLNG,1-1/4",BORE,DODGE 124649 231135 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,ELIM,FULL,1-1/2" SQUARE BORE 981284 ROLL,RUBBER,ELIM,HALF,1-1/2" SQUARE BORE 981285 ROLL,RUBBER,SPACER,1/2" x 1-1/2" SQ BORE 981291 SHFT,SQ,84",1-1/2"x82-1/4" SLD DBL SPRKT 821605 SPRCKT,H60BS14x1-1/4"...
  • Page 20 Operator's manual MODEL 995 8783_RET_ELEV 995 84"x17' FULL RTRN CONV 9"FS Item Quantity Description Part # Number BELT,FLAT,12" 1/32" x 1/32" 150# x 7.042 LNF 261000 BELT,FLAT,2-1/4",1/32" x 1/32" 150#x17.000LNF 261449 BELT,FLAT,84" 1/32" x 1/32" 150# x 34LNF 261766 BRNG,PB,1-7/16" BORE TAPPED BASE VTBE-123 231241 BUSHING,P1x1-7/16"...
  • Page 21 Operator's manual MODEL 995 Notes !! Page 20...
  • Page 22 Operator's manual MODEL 995 8783-500 ASSY,MULTI-SEP,HYD.DRIVE,96",6-RLR Item DESCRIPTION PART #: Item DESCRIPTION PART #: ARM,TORQUE,HYD,WHL,DRV,4 HOLE 3/8x6-1/4" 901575 MTR,HY,6.0CUIN,1"KEY,SAE-4BOLT-TB-SERIES 601238 ASSY,CLODRLR,STEEL,M-SEP,96",990-2010 133200 NUT,HEX,5/8"-11UNC 501814 ASSY,DRIVE,BOTH SIDES,M-SEP ELIM-2009 133141 PIN,ADJST,HEIGHTS,M-SEP,6440-2006 194049 BOLT,CARRIAGE,5/8"-11UNC x 2" GR 2 501359 PLATE,3/8" x 4-31/32" x 6-13/16"...
  • Page 23 Operator's manual MODEL 995 8783-500 ASSY,MULTI-SEP,HYD.DRIVE,96",6-RLR SECTION A-A SECTION E-E SECTION B-B SHEET 2 OF 4 Page 22...
  • Page 24 Operator's manual MODEL 995 8783-500 ASSY,MULTI-SEP,HYD.DRIVE,96",6-RLR Item DESCRIPTION PART #: Item DESCRIPTION PART #: ARM,TORQUE,HYD,WHL,DRV,4 HOLE 3/8x6-1/4" 901575 MTR,HY,6.0CUIN,1"KEY,SAE-4BOLT-TB-SERIES 601238 ASSY,CLODRLR,STEEL,M-SEP,96",990-2010 133200 NUT,HEX,5/8"-11UNC 501814 ASSY,DRIVE,BOTH SIDES,M-SEP ELIM-2009 133141 PIN,ADJST,HEIGHTS,M-SEP,6440-2006 194049 BOLT,CARRIAGE,5/8"-11UNC x 2" GR 2 501359 PLATE,3/8" x 4-31/32" x 6-13/16"...
  • Page 25 Operator's manual MODEL 995 8783-500 ASSY,MULTI-SEP,HYD.DRIVE,96",6-RLR SECTION D-D SECTION C-C 1 10 SECTION F-F SHEET 4 OF 4 Page 24...
  • Page 26 Operator's manual MODEL 995 133200-PB ASSY,CLODRLR,STEEL,M-SEP,96",990-2010 Item Quantity Title Subject Number ARM,PIVOT,CLODR,LH,M-SEP,6440-2006 194038 ARM,PIVOT,CLODR,RH,M-SEP,6440-2006 194043 BOLT,CARRIAGE,1/4"-20UNC x 2" GR 2 501304 BOLT,HEX,HD,1/2"-13UNC x 1-1/2" GR 5 501087 BRNG,2 BOLT,FLNG,1-3/8",SET SCREW,R SEAL 231325 BUSHING, REAR LIFT PARALLEL ARM 231153 NUT,HEX,1/2"-13UNC 501812 NUT,HEX,1/4"-20UNC...
  • Page 27 Operator's manual MODEL 995 133141-PB ASSY,DRIVE,BOTH SIDES,M-SEP ELIM-2009 Item Quantity Description Part # Number BELT,POWERBAND,1/C83 261913 BELT,POWERBAND,1/C83 261913 BELT,POWERBAND,1/C85 261914 BELT,POWERBAND,1/C85 261914 BOLT,EYE,1/2"x8" w/NUT PLATED 502410 BRNG,PB,1-3/8" , ECC LOCK, R SEAL, RAK WIDE 231121 BRNG,SLEEVE,2" ODx1.75"x1.75LG 231262 BUSHING,SFx1-3/8" 781313...
  • Page 28 Operator's manual MODEL 995 133199-PB BRUSH,M-SEP,96",990-2010 Item Quantity Description Part # Number BELT,96" M-SEP VINE BRUSH,2011 261999 WELDMENT,BRUSH,96" M-SEP 195811 Page 27...
  • Page 29 Operator's manual MODEL 995 8783-520 SCD DRIVE,M-SEP,6-RLR Item DESCRIPTION PART #: Item DESCRIPTION PART #: BELT,POWERBAND,1/C75 261913 OUTRIGGER CHAIN FOR PILERS 352253 BELT,POWERBAND,1/C83 261913 PLATE,TORQUE-ARM 174230 BOLT,EYE,1/2"x8" w/NUT PLATED 502410 SHEAVE,1GROVE,C,7.0 SF BORE 781485 BRNG,PB,1-3/8" , ECC LOCK, R SEAL, RAK WIDE 231121 SHFT CPLR,CLAMP ON,1.25BOR,3.25L,5/16KEY...
  • Page 30 Operator's manual MODEL 995 8783-800-PB SHFT,ELIM,96",12PNT FNGR FULL SPRDR ROLL Item Quantity Description Part # NOTE: Number ROTATE EVERY OTHER 12 POINT FINGER. BRNG,2BOLT,FLNG,1-1/4" BORE VF2S-120 231082 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,FINGER,12POINT,1-1/2"BORE"A" 982135 ROLL,RUBBER,FINGER,12POINT,1-1/2"BORE"B" 982136 SHFT,SQ,96",1-1/2"x94-1/4" SLD DBL SPRKT 194296 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB)
  • Page 31 Operator's manual MODEL 995 821958-PB SHFT,M-SEP,SPIRAL SEG,96",LH Item Quantity Description Part # Number BOLT,HEX,HD,1/2"-13UNC x 1-1/2" GR 5 501087 BOLT,HEX,HD,1/2"-13UNC x 1-1/4" GR 5 501251 BRNG,2 BOLT,FLNG,1-3/8",SET SCREW,R SEAL 231325 COLLAR,SHAFT,SET,SCREW,1-3/8" 502646 PLATE,MULTI-SEP SEGMENT RETAINER,1/4"PLT 174717 SEGMENT TERMNAL L/H INCREASE96" M-SEP 982122 SEGMENT TERMNAL R/H INCREASE96"...
  • Page 32 Operator's manual MODEL 995 821959-PB SHFT,M-SEP,SPIRAL SEG,96",RH Item Quantity Description Part # Number BOLT,HEX,HD,1/2"-13UNC x 1-1/2" GR 5 501087 BOLT,HEX,HD,1/2"-13UNC x 1-1/4" GR 5 501251 BRNG,2 BOLT,FLNG,1-3/8",SET SCREW,R SEAL 231325 COLLAR,SHAFT,SET,SCREW,1-3/8" 502646 PLATE,MULTI-SEP SEGMENT RETAINER,1/4"PLT 174717 SEGMENT TERMNAL L/H INCREASE96" M-SEP 982122 SEGMENT TERMNAL R/H INCREASE96"...
  • Page 33 Operator's manual MODEL 995 Page 32...
  • Page 34 Operator's manual MODEL 995 Page 33...
  • Page 35 Operator's manual MODEL 995 Page 34...
  • Page 36 Operator's manual MODEL 995 Page 35...
  • Page 37 Operator's manual MODEL 995 8783_TRANS_ROLL 990 96" TRANS. TABLE ELEV / MULTI-SEP Item Quantity Description Part # Number ARM,TORQUE,HYD,WHL,DRV,4 HOLE 3/8x6-1/4" 901575 CARTRIDGE E/H,2W 2P,10-2,12VDC, N .O.,POP 601643 COUPLING,HYD,DRV,1-1/4"x1"x4-1/4" KEYWAY 181492 CPLG,HYD,STR,2404-8-8 (8MJ-8MP) 601390 CPLG,HYD,STR,6400-8-10 (8MJ-10MB) 601749 CPLG,HYD,STR,6400-8-8 (8MJ-8MB) 601457...
  • Page 38 Operator's manual MODEL 995 8783-800-PB SHFT,ELIM,96",12PNT FNGR FULL SPRDR ROLL Item Quantity Description Part # NOTE: Number ROTATE EVERY OTHER 12 POINT FINGER. BRNG,2BOLT,FLNG,1-1/4" BORE VF2S-120 231082 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 ROLL,RUBBER,FINGER,12POINT,1-1/2"BORE"A" 982135 ROLL,RUBBER,FINGER,12POINT,1-1/2"BORE"B" 982136 SHFT,SQ,96",1-1/2"x94-1/4" SLD DBL SPRKT 194296 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB)
  • Page 39 Operator's manual MODEL 995 Notes !! Page 38...
  • Page 40 Operator's manual MODEL 995 8783_SCSSR_BX 995 96" 15 ROLL SNGL DSCHRG SCISSOR LH Item # DESCRIPTION PART #: Item # DESCRIPTION PART #: BAR,SLIDE,ELIM 1/4x2x84 SQ TUBE 8783-018 LINKAGE ARM ELIM SCISSOR ADJ 26 INCH 191380 BELT,FLAT,4",1/32" x 1/32" x 150# x 10.000 LNF...
  • Page 41 Operator's manual MODEL 995 8783_SCSSR_BX 995 96" 15 ROLL SNGL DSCHRG SCISSOR LH SECTION C-C 1 47 SECTION A-A 29 45 18 19 20 21 24 25 SHEET 2 OF 2 SECTION B-B Page 40...
  • Page 42 Operator's manual MODEL 995 8783_SCSSR_ADJ 990 96" CYLINDER HYD SCISSOR ADJ DSCHRG Item Quantity Description Part # Number ARM,HYD,SCSSR,ROLL,ADJUST,98" WIDE 194299 CPLG,HYD,90DEG,6801-6-8 (6MJ-8MB) 601323 CPLG,HYD,STR,6400-6-8 (6MJ-8MB) 601477 CYL,3.00"x12",TIE ROD,22.25",1.375",3/4 602621 VALVE,ACCESORY,STD.LEVER M8x1.25x150mm 602474 VALVE,CHECK,METRO,#409-04-1084 601213 Page 41...
  • Page 43 Operator's manual MODEL 995 8783_SCSSR_RLS 96" SCISSOR HYD ADJ FNGR SIZING 12 ROLL Item Quantity Description Part # Number SHFT,ELIM,96",ELM/FNG FL D/SPR CMPLT SS 8783-835 SHFT,ELIM,96",ELM/FNG HLF D/SPR CMPLT SS 8783-830 SHFT,ELIM,96"ELM/FNG FL D/B D/S CMPLT SS 8783-825 SHFT,ELIM,96"ELM/FNG FL D/SPR CMPLT TRN 8783-845 SHFT,ELIM,96"ELM/FNG HLF D/SPR CMPLT TRN...
  • Page 44 Operator's manual MODEL 995 8783-835-PB SHFT,ELIM,96",ELM/FNG FL D/SPR CMPLT SS Item Quantity Description Part # Number BRNG,PB,1-1/4" BORE TAPPED BASE 231085 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 RLL,RBBR,FNGR,1-1/2"SQBR,3-1/2"HUB,MLSTN RUBR045 SHFT,SQ,96",1-1/2"x94-1/4" SLD DBL SPRKT 194296 SPRCKT,DBL,HD60B14 1-1/4" BORE 881203 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911...
  • Page 45 Operator's manual MODEL 995 8783-830-PB SHFT,ELIM,96",ELM/FNG HLF D/SPR CMPLT SS Item Quantity Description Part # Number BRNG,PB,1-1/4" BORE TAPPED BASE 231085 COLLAR,SHAFT,SET,SCREW,1-1/4" 501950 RLL,RBBR,FNGR,1-1/2"SQBR,3-1/2"HUB,MLSTN RUBR045 ROLL,RUBBER,SPACER,1/2" x 1-1/2" SQ BORE 981291 ROLL,RUBBER,SPACER,1/4" x 1-1/2" SQ BORE 981912 SHFT,SQ,96",1-1/2"x94-1/4" SLD DBL SPRKT 194296 SPRCKT,DBL,HD60B14 1-1/4"...
  • Page 46 Operator's manual MODEL 995 8783-825-PB SHFT,ELIM,96"ELM/FNG FL D/B D/S CMPLT SS Item Quantity Description Part # Number BRNG,PB,1-1/4" BORE TAPPED BASE 231085 RLL,RBBR,FNGR,1-1/2"SQBR,3-1/2"HUB,MLSTN RUBR045 SHFT,SQ,96",1-1/2"x94-1/4" SLD DBL SPRKT 194296 SPRCKT,DBL,HD60B14 1-1/4" BORE 881203 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 Page 45...
  • Page 47 Operator's manual MODEL 995 8783-845-PB SHFT,ELIM,96"ELM/FNG FL D/SPR CMPLT TRN Item Quantity Description Part # Number BRNG,PB,1-1/4" BORE TAPPED BASE 231085 RLL,RBBR,FNGR,1-1/2"SQBR,3-1/2"HUB,MLSTN RUBR045 SHFT,SQ,96",1-1/2"x94-1/4" SLD DBL SPRKT 194296 SPRCKT,DBL,HD60B14 1-1/4" BORE 881203 WASHER,FLAT,1-1/4" USS ZINC PLT (4/LB) 501911 Page 46...
  • Page 48 Operator's manual MODEL 995 8783-840-PB SHFT,ELIM,96"ELM/FNG HLF D/SPR CMPLT TRN Item Quantity Description Part # Number BRNG,PB,1-1/4" BORE TAPPED BASE 231085 RLL,RBBR,FNGR,1-1/2"SQBR,3-1/2"HUB,MLSTN RUBR045 ROLL,RUBBER,SPACER,1/2" x 1-1/2" SQ BORE 981291 ROLL,RUBBER,SPACER,1/4" x 1-1/2" SQ BORE 981912 SHFT,SQ,96",1-1/2"x94-1/4" SLD DBL SPRKT 194296 SPRCKT,DBL,HD60B14 1-1/4"...
  • Page 49 Operator's manual MODEL 995 8783_RET_SIZING 995 96"x5' SIZING RETURN 7"FS HYD Item Quantity Description Part # Number ARM,TORQUE,HYD,DRV,4 HOLE 1/2" x 12" 901495 ASSY,BC,96"x.500x40MM 1.56" FLT 4Bx10'0" 352972 BRNG,PB,1-3/4" BORE,TAPPED BASE VTBE-128 231239 CONVEYOR,RET,96"x5' ELIM,CHAIN.BARE 8783-006 COUPLING,HYD,DRV,1-3/4"x1-1/4" 3/8"x5/16 8708-500 CPLG,HYD,STR,6400-8-10 (8MJ-10MB)
  • Page 50 Operator's manual MODEL 995 8783_PCK_TBL_L 995 36"x10'FULL PCK TBL ELC VR SPD LEFT Item Quantity Description Part # Number BELT,FLAT,36" 1/32" x 1/32" 150# x 20.667 LNF 261007 BRNG,PB,1-7/16" BORE TAPPED BASE VTBE-123 231241 BUSHING,P1x1-7/16" BORE SPLIT TAPER 781184 CHN,RLR,60 PITCH x 6.167 LNF 351005 GRBX,PAR,13.9:1 5HP 184TC DAVID BROWN...
  • Page 51 Operator's manual MODEL 995 8783_PCK_TBL_R 995 36"x10'FULL PCK TBL ELC VR SPD RIGHT Item Quantity Description Part # Number BELT,FLAT,36" 1/32" x 1/32" 150# x 20.667 LNF 261007 BRNG,PB,1-7/16" BORE TAPPED BASE VTBE-123 231241 BUSHING,P1x1-7/16" BORE SPLIT TAPER 781184 CHN,RLR,60 PITCH x 6.167 LNF 351005 GRBX,PAR,13.9:1 5HP 184TC DAVID BROWN...
  • Page 52 Operator's manual MODEL 995 8783_RET_CNV_L 995 30"x22'RTRN CONV PCK TBL 12"FS LEFT Item Quantity Description Part # Number BELT,FLAT,12" 1/32" x 1/32" 150#x2.542 LNF 261000 BELT,FLAT,30" 1/32" x 1/32" 150#x44.000LNF 261006 BRNG,PB,1-7/16" BORE TAPPED BASE VTBE-123 231241 BUSHING,P1x1-7/16" BORE SPLIT TAPER 781184 CHN,RLR,60 PITCH x 6.000 LNF...
  • Page 53 Operator's manual MODEL 995 8783_RET_CNV_R 995 30"x22'RTRN CONV PCK TBL 12"FS RIGHT Item Quantity Description Part # Number BELT,FLAT,12" 1/32" x 1/32" 150#x2.542 LNF 261000 BELT,FLAT,30" 1/32" x 1/32" 150#x44.000LNF 261006 BRNG,PB,1-7/16" BORE TAPPED BASE VTBE-123 231241 BUSHING,P1x1-7/16" BORE SPLIT TAPER 781184 CHN,RLR,60 PITCH x 6.000 LNF...
  • Page 54 Operator's manual MODEL 995 8783-PCK-PLTFRM 995 PICKER PLATFORM 12" x 108" w/RAIL ITEM DESCRIPTION PART #: LADDER,PICKER PLATFORM,ELIM, 2 RUNG 193614 PIN, P ICKING TABLE PLATFORM 1/2"x3" G01577 PLATE,1/4" x 8" x 9-7/8" 022948 PLATE,ELIMINATOR,PLATFORM,MOUNTING 173467 PLATFORM,PICKING TABLE 12"x96" 995 ELIM...
  • Page 55 Operator's manual MODEL 995 8783_36IN_X 995 CROSS CONV 36"x12' FLAT BELT (HYD) Item Quantity Description Part # Number ARM,TORQUE,HYD,DRV,4 HOLE 1/2" x 12" 901495 BELT,FLAT,2-1/4",1/32" x 1/32" 150#x12.000LNF 261449 BELT,FLAT,36" 1/32" x 1/32" 150# x 24.000 LNF 261006 BELT,FLAT,7" 1/32" x 1/32" 150#x3.00 LNF 261747 BRNG,PB,1-7/16"...
  • Page 56 Operator's manual MODEL 995 8783_48IN_X 995 CROSS CONV 48"x12' FLAT BELT (HYD) Item Quantity Description Part # Number 14 11 ARM,TORQUE,HYD,DRV,4 HOLE 1/2" x 12" 901495 BELT,FLAT,2-1/4",1/32" x 1/32" 150#x12.000LNF 261449 BELT,FLAT,48" 1/32" x 1/32" 150# x 24.000 LNF 261008 BELT,FLAT,7"...
  • Page 57 Operator's manual MODEL 995 8783_20IN_X 995 CROSS CONV 20"x12' FLAT BELT (HYD) Item Quantity Description Part # Number ARM,TORQUE,HYD,WHL,DRV,4 HOLE 3/8x11" 901576 BELT,FLAT,2-1/4",1/32" x 1/32" 150#x12.000LNF 261449 BELT,FLAT,20" 1/32" x 1/32" 150# x 24.000 LNF 261004 BELT,FLAT,7" 1/32" x 1/32" 150#x1.67 LNF 261747 BRNG,PB,1-1/4"...
  • Page 58 Operator's manual MODEL 995 FA5389-8708 990 MAN STEERING PIVOT TONGUE DISCHARGE Item Quantity Description Part # Number AXLE MOUNT, ELIM, PIVOT STEERING 191484 AXLE, ELIM, PIVOT STEERING, 8 HOLE HUB 8657-011 HUB,COMPLETE,8HOLE,8"BC,6"PILOT 8000# 951174 NUT,SLOTTED,HEX,1-1/4"12UNF JAM 1.05"THK 951199 PIN,COULTER,CYLINDER,1"x4.63"LONG 171369 PIN,STEERING AXLE 5/8"...
  • Page 59 Operator's manual MODEL 995 FA5134-8708 990 NO WHEEL DRIVE TANDEM AXLE Item Quantity Description Part # Number AXLE,ELIM,SUPPORT,TANDEM,PIVOT G01714 AXLE,ELIMINATOR,DRIVE,TANDEM G01720 BOLT,HEX,HD,9/16"-18UNFx1-1/2" GR5*FINE* 502250 COLLAR,SHAFT,SET,SCREW,2" 501954 HUB,ASSY,FOR 730 LONG GRBX 571123 NUT,LUG,GRBX,WHL,DRV 9/16"-18 730 UBT-4 571137 PLATE,DUMMY,UMC,GRBX SMALL 900/910/915 201040 SHAFT,HC,2"...
  • Page 60 Operator's manual MODEL 995 FA5135 990 HYDRAULIC JACKS 4 EACH Item Quantity Description Part # Number CPLG,HYD,90DEG,6801-6-8 (6MJ-8MB) 601323 CPLG,HYD,STR,6400-6-8 (6MJ-8MB) 601477 CYL,3.00"x12",TIE ROD,22.25",1.375",3/4 602621 JACK,ASSEMBLY,LEVELING,ELIMINATOR 131173 PLATE,1/4" x 5" x 5" G00598 VALVE,ACCESORY,SAFETY LEVER M8x1.25x160m 602473 VALVE,ACCESORY,SAFETY LEVERBRACKET 602472...
  • Page 61 Operator's manual MODEL 995 FA5172-8783 990 HYD UNIT 7-1/2 HP MTR 230V 3PH Item Quantity Description Part # Item Quantity Description Part # Number Number BUSHING,SH 1-3/8" BORE 781474 LABEL,HYDRAULIC,FILTER CHANGE EVERY200HR 300210 CLPG,HYD,TEE,6602-08-08-08(MJ-FJS-MJ) 602367 LABEL,OPEN CENTER HYDRAULIC SYSTEM 300120...
  • Page 62 Operator's manual MODEL 995 FA7031 990 MULTI-SEP DRIVE 230V3PH Item Quantity Description Part # Number KIT,HYDRAULIC,MULTI-SEP,990-2009 8783_M-SEP_HYD MTR,C-FACE,3PH 15HP 254TC 1-5/8" W/FT 651084 STD ELEC FOR,15HP MTR 120c240v3P EA0207 Page 61...
  • Page 63 Operator's manual MODEL 995 Notes !! Page 62...
  • Page 64 Operator's manual MODEL 995 8783_M-SEP_HYD KIT,HYDRAULIC,MULTI-SEP,995-2011 Item Quantity Description Part # Item Quantity Description Part # Number Number BODY,VALVE,ELEC,FLOW,CNTRL #12 SAE 602886 CPLG,HYD,TEE,6803-8-8-10 (8MJ-8MJ-10MB) 601750 BUSHING,HEX HEAD BRASS 1-1/4"x1" 731188 FILTER ABSOLUTE 10 MICRON ZAE10 602154 CARTRIDGE,2-WAY,N.C.,NO COIL,#12 BODY 602884 FILTER,HEAD,W/BYPASS 25psi,3/4",30gpm...
  • Page 65 Operator's manual MODEL 995 8783_M-SEP_HYD KIT,HYDRAULIC,MULTI-SEP,995-2011 45 2 36 22 22 52 11 SECTION A-A 20 21 SHEET 2 OF 2 SECTION B-B Page 64...
  • Page 66 Operator's manual MODEL 995 8783-430-PB CANOPY,ROOF CMPLT W/BRACE 12'Wx12'L ELIM Item Quantity Description Part # Number ANGLE,1/8"x1"x1" x 45" (CUT TO FIT) G00504 ANGLE,1/8"x1"x1" x 57" (CUT TO FIT) G00505 CANOPY,ROOF FRAME 10'Wx12'L ELIM LEFT 8783-450 CANOPY,ROOF FRAME 10'Wx12'L ELIM RIGHT...
  • Page 67 CURTAINS, CURTAIN FRAMES, CURTAIN HANGERS Item Quantity Description Part # Number CURTAIN,INTAKE,END,CUSTOM,140"Wx126"H 8783-990 CURTAIN,LEFT SIDE,CUSTOM,144"Wx141"H 8783-993 CURTAIN,OUTLET,END,CUSTOM,72"Wx126"H 8783-994 CURTAIN,OUTLET,END,CUSTOM,72"Wx126"H 8783-995 CURTAIN,RIGHT SIDE,CUSTOM,144"Wx126"H 8783-992 PIPE,END CURTAIN HANGER,12FT 8783-925 PIPE,END CURTAIN HANGER,4.583LNF 8783-926 PIPE,SIDE CURTAIN HANGER,12FT 174511 SIDE CURTAIN FRAME 8'Wx8'H MDL 995 8783-014 Page 66...
  • Page 68 Operator's manual MODEL 995 8783_END_X ELIM END CROSS CONV 36"x14' C-SECT BELT Item Description Part # Item Description Part # Number Number BELT,FLAT,36",1/32"x1/32" 150# "C" SECTNx28.00LNF 261528 SHLD,OVAL,HINGED,W/BACK,3"x9"x32" 841109 BRACE,ELIM,36"W,END X CONV FLAT 43"LONG 171089 SHLD,TAKEUP BEARING,#981572 TAKEUP 841286 BRNG,PB,1-7/16" BORE TAPPED BASE VTBE-123 231241 SPRCKT,H60BS18x1-1/4"...
  • Page 69 Page 68...
  • Page 70 Page 69...
  • Page 71 Operator's manual MODEL 995 Page 70...
  • Page 72 Operator's manual MODEL 995 Page 71...
  • Page 73 Operator's manual MODEL 995 Page 72...
  • Page 74 Operator's manual MODEL 995 Page 73...
  • Page 75 Operator's manual MODEL 995 Page 74...
  • Page 76 Operator's manual MODEL 995 Page 75...
  • Page 77 Operator's manual MODEL 995 Page 76...
  • Page 78 Operator's manual MODEL 995 Page 77...
  • Page 79 Operator's manual MODEL 995 Page 78...
  • Page 80 Operator's manual MODEL 995 Page 79...
  • Page 81 Operator's manual MODEL 995 Page 80...
  • Page 82 Operator's manual MODEL 995 Page 81...
  • Page 83 Operator's manual MODEL 995 Page 82...
  • Page 84 Notes !!
